2120 EARLY RISER ® RIGID TRAILING PLANTER SPECIFICATIONS
The 2120 Early Riser ® planter introduces innovative technology to smaller-scale producers like you’ve never seen — but always deserved. Protect your crops right from the start with precise and accurate seed placement features, while our advanced fertilizer systems put their growth in your control. Integrated precision technology improves seed placement accuracy and minimizes ground pressure between the rows, resulting in higher productivity and reduced soil compaction. Unlock the full potential of your operation with the 2120 Early Riser planter and discover what a high-tech planter can do for even the smallest farms. THE RIGHT FIT FOR YOUR FIELD The 2120 Early Riser’s factory-integrated Case IH and Precision Planting technology can be customized to match your farm’s agronomic needs. The 11-row 2120 can be configured for both 15" and 30" rows and offers liquid fertilizer control. The 6- and 8-row 30" configurations offer both liquid or dry factory installed fertilizer options. GEAR UP FOR A SUCCESSFUL PLANTING SEASON
11R15 Configuration
MORE ACCURACY
• Low-maintenance, electrically driven metering system delivers accurate and consistent seed singulation, population and in-row spacing. • Industry’s only flat-bottom seed trench provides proper depth and more consistent seed placement while improving seed-to-soil contact.
6R30 with Optional Liquid Fertilizer System
MORE PRODUCTIVITY
• Reduced maintenance and tool-free crop changes and adjustments keep you in the field to cover more acres with greater speed and efficiency. • Optimize planter performance with options for seed carrying capacity, a variety of in-cab adjustments and automatic control of vacuum, row unit downforce and more.
MORE DURABILITY
• Rugged row unit built for unrivaled accuracy and dependability — from 3 mph to 10 mph. • 26-inch toolbar clearance, plus a 60 percent increase in vertical row unit travel to accommodate terrain changes.
8R30 with Optional Dry Fertilizer System
2120 EARLY RISER RIGID TRAILING PLANTER WITH FACTORY INSTALLED HIGH-TECH OPTIONS
C
B
A PREMIUM TIRE PACKAGE
VF Tires offer enhanced flotation and minimize compaction.
B ON-ROW HOPPER
A
Choose from standard 1.9 bu. on-row hopper or optional 3.0 bu. hopper.
HOSE & HARNESS ROUTING
C VACUUM SYSTEM
Optimized hose & harness routing minimizes pinching and material build-up.
Integrated vacuum plumbing with standard in-cab automated speed adjustment.
FOLDABLE STORAGE HITCH DESIGN
WEIGHT BRACKETS
Markers are optional or select weight brackets as optional for high down force scenarios.
• Minimizes storage space. • Allows for storage with row units off the ground.
D ELECTRONIC COMPONENTS
Steel enclosure protects vital electronic components.
E COMPRESSOR
Deluxe hydraulic drive air compressor with in-cab control of 2-stage closing, row unit air down pressure and floating residue managers.
D
E
F FACTORY INSTALLED FERTILIZER SYSTEMS
F
• Industry leading dry and liquid fertilizer capacities. • Optional liquid fertilizer system with individual row shutoffs and variable rate control. • Optional dry fertilizer system with up to 6,000 lbs carrying capacity.
G FRAME
• Robust 7 x 7-in. main frame toolbar. • Integrated vacuum plumbing.
G
UNIQUE CARRYING WHEEL DESIGN
The 11R15 with its unique carrying wheel design allows for row unit accessibility and provides positive tongue weight during transport.
2120 EARLY RISER PLANTER AVAILABLE CONFIGURATIONS
ROW UNIT GAUGE WHEELS
15 IN.
30 IN.
Optional Open Spoke Gauge Wheel for easy clean out.
6-ROW 8-ROW 11-ROW
EARLY RISER 2120 RIGID TRAILING PLANTER SPECIFICATIONS
CONFIGURATION Rows
6
8
11
Spacing
30 in. (762 mm)
15 in. (381 mm)
Frame Size
7 in. × 7 in. (17.8 cm × 17.8 cm)
Toolbar Operating Height
26 in. (660 mm)
Approximate Transport W×H×L (Includes Markers)
16 ft. 6 in. × 9 ft. 1 in. × 17 ft. 8 in. (5.05 m × 2.77 m × 5.43 m)
24 ft. 6 in. × 9 ft. 1 in. × 17 ft. 8 in. (7.46 m × 2.77 m × 5.43 m)
16 ft. 6 in. × 12 ft. 2 in. × 17 ft. 8 in. (5.05 m × 4.02 m × 5.48 m)
HITCH 2-Point Drawbar
N/A
Category III with folding hitch
Rear Tow Hitch FLOTATION Tire Arrangement SEED DELIVERY Seed Capacity
N/A
Four IF 245/70R19.5 (rearward mounts on 30 in. & forward mounts on 15 in. Configurations)
Standard – 1.9 bu on Row Hoppers, Available – 3.0 bu on Row Hoppers
3.0 bu on Row Hoppers
Electric Drive Vacuum Seed Meter
Standard – vSet ® 2 vacuum seed meter with vDrive ® electric drive motor, row by row overlap control capable & curve compensated spacing
Seed Tube/Hy Rate Plus ™ / Available WaveVision ™
Standard – 10 LED seed sensor, Available – WaveVision ™ seed sensor for improved accuracy in high dust conditions
Advanced Seed Delivery ™ (ASD ™ )
Available – SpeedTube ™ belt delivery system for high accuracy at any speed up to 10 mph **
ROW UNIT Parallel Links
Standard – Cast lower parallel links with 16 in. (406 mm) total vertical row unit travel Standard – 15 in. (381 mm) diameter, 0.18 in. (4.5 mm) width, opener disks with external scrapers Standard – Cast row unit frame with 1/4 in. (6.4 mm) or 1/8 in. (3.2 mm) depth increments
Offset Opener Disks/Opener Disk Scrapers Frame with Zero Index Depth Adjustment
ROW UNIT DOWN FORCE Air Down Force
Standard – Air down force with gauge wheel load feedback
Hydraulic Down Force with Automatic Control
Available – DeltaForce ™ adds or removes weight automatically, row by row
WING DOWN FORCE Hydraulic Wing Down Force
N/A
CLOSING SYSTEM 2-Stage with Spring Closing Disk & Spring Press Wheel
Standard – Independent 9 in. (228 mm) diameter inverted closing disks & rubber press wheel Available – 12 in. (305 mm) diameter × 1 in. (25 mm) width rubber V-press wheels
V-Press Wheel with Spring
Air Closing MARKERS Markers
Available – In-cab pneumatic adjustment
Standard – Wing weight brackets for mounting up to 6 suitcase weights, Available – Single Fold, Automatic Alternating Markers
HYDRAULIC / ELECTRICAL / AIR SYSTEM Hydraulic Direct Drive with Alternator
Standard – 11 row configuration, Available – 6 & 8 row Available – Tractor mounted 22 GPM (83 LPM) PTO Pump ^
Auxiliary PTO Hydraulic Pump
Compressed Air
Planter – Mounted hydraulic drive compressor with wet lube, 5 gal. (18.92 L) air tank & 2 micron air filter
DISPLAY SYSTEM AFS Pro 700; AFS Pro 1200; ISOBUS Compliant FERTILIZER & CHEMICAL DELIVERY Liquid Fertilizer Electronic Individual Row Liquid Fertilizer Shutoff
Available – AFS Pro 700 ^ , Available – AFS Pro 1200, or supported ISOBUS Compliant Display – Choose 1 for operation, Available – 1 or 2 integrated planter mounted cameras
Available – Planter mounted 2 × 250 (500 gal.) (1 892 L) (6 & 8 row only), Tractor mounted supply tanks (not supplied) (11 row only), variable rate with standard single section shutoff
Available – Automated overlap control in sync with the seed meter ^
Liquid Fertilizer Delivery
Available – In-furrow applicator or frame mounted single disk or double disk opener
Dry Fertilizer
Available – Planter mounted 6,000 lb. (2 721 kg) or 4,500 lb. (2 041 kg) capacity dry tanks (6 & 8 row only), single section control, variable rate hydraulic drive
Dry Fertilizer Delivery ROW UNIT TILLAGE Fixed Residue Managers Floating Residue Managers
Available – Frame mounted single disk or double disk opener
Available – Tine or No-Till dual wheel ^
Available – Tine or No-Till with depth band dual wheel ^ , Available – In-Cab position control & up or down pressure using CleanSweep ™ air cylinders
TRACTOR RECOMMENDATIONS Engine Horsepower Range **
85 – 200 HP
100 – 250 HP
150 – 250 HP
Hydraulic System **
Standard flow, High flow hydraulic pump 3 required and hydraulic motor case drain
Number of Hydraulic Remotes
Standard = In base price of the planter Available = Multiple options available ** = Varies based on planter configuration, speed, operating conditions, etc. ^ = Factory-supplied dealer-installed attachment only
