Axial-Flow Combine Header Spec Sheet 08-24 CIH24081502 pages

AXIAL-FLOW ® COMBINE HEADERS SPECIFICATIONS

AXIAL-FLOW COMBINE HEADERS Corn Head | Grain Head | Pickup Head | Draper Head

DESIGNED TO MATCH THE CAPACITY OF AXIAL-FLOW COMBINES

Case IH header options deliver consistent performance and durability, regardless of crop or conditions, allowing you to harvest more of what you grow. Just like the combines behind them, Case IH headers are simple to set and adjust, intuitive to operate and help deliver the highest-quality grain to the hopper. With heads as wide as 61 feet, they deliver a steady stream of grain to match the high capacity of machines like the Axial-Flow AF series.

AXIAL-FLOW COMBINE HEADERS

Recommended Combine + Header Pairings.�� 7

Axial-Flow Combine Headers.�� 4 – 5

Product Specifications.�� 8 – 11

C500 Series Corn Head.�� 6

RowGuide Pro.�� 6

THE GREATEST CHOICE OF HEADS TO GIVE YOU THE GREATEST YIELDS

CORN HEADS

GRAIN HEADS

Case IH Corn Heads are designed to pick cleaner, harvest faster, grab more down corn and save more grain. The corn heads incorporate the latest innovations in harvest technology, with features that maximize your time in the field and minimize your yield loss. Case IH 6 to 18 row corn heads–available in narrow or folding configurations– provide increased corn harvesting speeds and consistent chop lengths to help increase productivity without sacrificing chop quality.

The Case IH rigid auger grain head is designed to match the high horsepower combines of today, offering faster harvesting speeds and the adaptability to tackle different crop conditions effectively. It can handle a range of challenging situations, including tangled and downed crops as well as uneven terrains.

PICKUP HEADS

DRAPER HEADS

The Case IH pick up head is ideal for small-grain harvesting like cereal, grass seed, and more. Our simple, proven design helps minimize seed loss, while extra picking fingers and adjustable belt speeds allow for increased performance in tough conditions.

FD2 Series FlexDraper By MacDon offer both rigid and flexible cutterbar configurations, variable draper speeds, a wide range of cutting widths, and a head-first feeding design for unmatched harvesting efficiency.

C500 SERIES CORN HEAD

ROWGUIDE PRO

Experience the enhanced power and precision of new RowGuide Pro,™ now optimized for the 260 & AF series combines. With significant improvements to the vehicle’s hydraulics and steering systems, you’ll enjoy a smoother, more responsive operation. RowGuide Pro removes manual corrections and interventions by combining GPS and advanced software for seamless row tracking, even in crop gaps like waterways. An enhanced steering system ensures smooth and efficient movement through the field. Elevate your harvesting performance with the latest advancements in agricultural technology.

The C500 series corn head is designed to pick corn cleaner and faster while delivering exceptional downed corn performance and grain savings.

A spring-free, self-adjusting deck plate linkage system, an industry first, offers up to 6mm of optimal variation and its rubber-based design eliminates common buildup issues found in spring-adjusted alternatives, significantly reducing maintenance time and costs. Independent drive lines for row unit and chopper drives with dedicated slip clutch protection ensure optimal performance and reduce the risk of damage to the entire drive system. Header-mounted automatic slip clutch detection utilizes in-cab alerts through the Pro 1200 or Pro 700 display to identify problems before a major failure occur. The C512 and C516 feature the industry’s largest auger offering higher capacity to align with the newly released AF series and 260 series combines, ensuring maximized capacity and throughput.

RECOMMENDED COMBINE + HEADER PAIRINGS

CORN HEADS

SUB- MODEL

SPACING (IN INCHES)

ROWS

CONFIGURATION

 – – –

C508



C512 12 20, 22, 30

– – – –

Chopping / Non- chopping

C500 Series Corn Heads**



C516 16 20, 22, 30

–––––––––––––––––––



C518 18

20, 22

–––––––––––––––––––



4406

6 30, 36, 38

––––––––––––––––––

 – – –

4408

8 30, 36, 38

4400 Series Corn Heads



4412 12 20, 22, 30

– – – –

Chopping / Non- chopping



4416 16 20, 22, 30

–––––––––––––––––––



4418 18

20, 22

–––––––––––––––––––

 – – –

4408

4400 Series Folding Corn Heads



4412 12

– – – –

OVERALL WIDTH (IN FEET)

GRAIN HEADS

CONFIGURATION

Rigid Auger Head 2030

 – – –

17, 20, 24, 30

Single Knife

Terraflex Auger Head 3020



20, 25, 30, 35

OVERALL WIDTH (IN FEET)

PICKUP HEADS

CONFIGURATION



1-piece belt

Pickup Head 3016



3-piece belt

OVERALL WIDTH (IN FEET)

DRAPER HEADS

CONFIGURATION

Macdon FD2 Series FlexDraper

Hydraulic cutting knife



25, 30, 35, 40, 41, 45, 50, 61

*Work with your local Case IH dealer for the best combine and header pairing for your operation. **The C500 series does not offer a folding configuration. † AF series when hooked to a 4400 series corn or prior to MY24 auger, draper and pick-up heads require lower retainer adapter kit.

4400 SERIES CORN HEADS

4406

4408

4408F

4412

GENERAL Divider Type

Hinged and floating

Plastic Metal

Yes No

Number of Rows

Row Spacing

30 in. (762 mm) / 36 in. (914 mm) / 38 in. (965 mm)

30 in. (762 mm)

Number of Gathering Chains

Type of Chain

Endless special chromed pins

OVERALL DIMENSIONS Width (Max. Row Spacing) 30 in. (762 mm)

16 ft. (4870 mm)

21 ft. (6394 mm)

31 ft. (9442 mm)

36 in. (914 mm) 38 in. (965 mm)

18 ft. 8 in. (5682 mm) 19 ft. 2 in. (5836 mm)

24 ft. 8 in. (7511 mm) 25 ft. 6 in. (7766 mm)

N/A N/A

Height (Level Ground) Length with Dividers Length without Dividers

4 ft. 2 in. (1258 mm) 9 ft. 11 in. (3010 mm) 7 ft. 6 in. (2272 mm)

WEIGHTS Approximate Weight — Non Chopping Header 30 in. (762 mm)

3,988 lb. (1809 kg) 4,288 lb. (1945 kg) 4,290 lb. (1946 kg)

5,484 lb. (2488 kg) 5,837 lb. (2648 kg) 5,842 lb. (2650 kg)

6,726 lb. (3051 kg)

8,058 lb. (3655 kg)

36 in. (914 mm) 38 in. (965 mm)

N/A N/A

Chopping Units Additional Weight ROW UNITS Point-to-Point Knife Type Stalk Rolls

Add an additional 75 lb. per row

Standard

Number of Knives per Roll Weed Knives (Single Piece)

4 - single edge

Adjustable

Row Unit Drive Stalk Roll Length Stalk Roll Diameter

Enclosed in gearbox – spur/bevel gears

23.4 in. (594 mm) 4.25 in. (108 mm)

Stalk Roll Speed (Nominal)

1,058 rpm

Gathering Chain Speed (Nominal)

349 fpm

SLIP CLUTCHES Row Units

1 per row radial pin 1 per auger radial pin

Auger Drive

STRIPPER PLATES Hydraulic

Hydraulic adjustable

Stalk Stompers (Available Through Part Marketing) Automatic Front Height Control/Lateral Tilt

Optional

Optional/pre-wired in main harness

HEADER DATA Header Jackshaft Speed 4400 CH on 7010/8010/20 Series

575 rpm

Auger Diameter

15.75 in. (400 mm) 6.3 in. (160 mm) 19.7 in. (500 mm)

Auger Tube Dimension

Flighting Pitch Reverse Flighting

4400 SERIES CORN HEADS

4412 NARROW ROW

4412F

4416

4416 NARROW ROW

4418 NARROW ROW

GENERAL Divider Type

Hinged and floating

Plastic Metal

Yes No

Number of Rows

Row Spacing

20 in. (508 mm) / 22 in. (559 mm)

30 in. (762 mm)

20 in. (508 mm) / 22 in. (559 mm)

Number of Gathering Chains

Type of Chain

Endless special chromed pins

OVERALL DIMENSIONS Width (Max. Row Spacing) 20 in. (508 mm)

22.1 ft. (9442 mm) 23 ft. (7010 mm)

N/A N/A

27.8 ft. (8484 mm) 30.3 ft. (9246 mm)

31.2 ft. (9500 mm) 34 ft. (10363 mm)

22 in. (559 mm) 30 in. (762 mm) 36 in. (914 mm) 38 in. (965 mm)

N/A

30 ft. 11 in. (9410 mm)

42.5 ft. (12954 mm)

N/A N/A N/A

N/A N/A

Height (Level Ground) Length With Dividers Length Without Dividers

4 ft. 2 in. (1258 mm) 9 ft. 4 in. (2870 mm) 7 ft. 9 in. (2405 mm)

4 ft. 7 in. (1338 mm)

4 ft. 2 in. (1258 mm)

9 ft. 11 in. (3010 mm) 7 ft. 6 in. (2272 mm)

9 ft. 4 in. (2870 mm) 7 ft. 9 in. (2405 mm)

WEIGHTS Approximate Weight 20 in. (508 mm) Standard/Chopping

7,231 lb. (2725 kg)/ 7,931 lb. (3597 kg) 7,360 lb. (2774 kg)/ 8,530 lb. (3869 kg)

7,860 lb. (3535 kg)/ 9,363 lb. (4217 kg) 8,145 lb. (3665 kg)/ 9,944 lb. (4481 kg)

8,697 lb. (3915 kg)/ 10,469 lb. (4719 kg) 8,820 lb. (3971 kg)/ 10,646 lb. (4799 kg)

N/A

22 in. (559 mm) Standard/Chopping

N/A

30 in. (762 mm) 36 in. (914 mm) 38 in. (965 mm)

N/A

9,686 lb. (4393 kg)

11,515 lb. (5223 kg)

N/A

N/A N/A

Chopping Units Additional Weight ROW UNITS Point-to-Point Knife Type Stalk Rolls

Add an additional 75 lb. per row

Standard

Number of Knives per Roll Weed Knives (Single Piece)

4 - single edge

Adjustable

Row Unit Drive Stalk Roll Length Stalk Roll Diameter

Enclosed in gearbox – spur/bevel gears

23.4 in. (594 mm) 4.25 in. (108 mm)

Stalk Roll Speed (Nominal)

1,062 rpm

1,058 rpm

1,062 rpm

Gathering Chain Speed (Nominal)

348 fpm

349 fpm

348 fpm

SLIP CLUTCHES Row Units

1 per row radial pin 1 per auger radial pin

Auger Drive

STRIPPER PLATES Hydraulic

Parallel linkage; hydraulic adjustable

Hydraulic adjustable

Parallel linkage; hydraulic adjustable

Stalk Stompers (Available Through Part Marketing) Automatic Front Height Control/Lateral Tilt HEADER DATA Header Jackshaft Speed 4400 CH On 7010/8010/20 Series

Optional

Optional/pre-wired in main harness

575 rpm

Auger Diameter

15.75 in. (400 mm) 6.3 in. (160 mm) 19.7 in. (500 mm)

Auger Tube Dimension

Flighting Pitch Reverse Flighting

GRAIN HEADERS

2030 RIGID AUGER HEADER 3020 FLEXIBLE AUGER HEADER

PICKUP HEADERS

3016 GRASS SEED SPECIAL

3016 GRAIN

CUTTER BAR

FLOATING AUGER

17, 20, 24, 30 ft. (5.1, 6.1, 7.62, 9.14 m)

20, 25, 30, 35 ft. (6.1, 7.62, 9.14, 10.6 m)

Actual Pickup Widths

12 ft. (3.7 m)

15 ft. (4.6 m)

Cutting Widths

WEIGHT – APPROX. 17 ft. (5.1 m)

Diameter

26 in. (660 mm)

2,998 lb. (1360 kg) 3,351 lb. (1520 kg) 3,880 lb. (1760 kg)

4,242 lb. (1924 kg) 4,242 lb. (1924 kg)

20 ft. (6.1 m) / 21 ft. (6.4 m)

Speed

187 rpm (160 Opt)

24 ft. (7.3 m) 25 ft. (7. m) 30 ft. (9.1 m) 35 ft. (10.6 m) 40 ft. (12.2 m) 45 ft. (13.7 m)

N/A

PICK-UP

N/A

5,302 lb. (2405 kg) 6,362 lb. (2886 kg) 6,760 lb. (3066 kg)

4,982 lb. (2260 kg)

Hydraulic

Drive – RPM

N/A N/A

Hydraulic

Wind Guard Lift

N/A

WEIGHT WITH BELT PICKUP

AUGER Diameter

12 ft. (3.7 m) Width

3,090 lb. (1401 kg)

N/A

24 in. (610 mm)

26 in. (660 mm)

Speed

Std. 178 rpm/Opt. 152 rpm Std. 147 rpm/Opt. 164 rpm

15 ft. (4.6 m) Width

N/A

3,180 lb. (1442 kg)

Full Fingered

Standard

Standard 25, 30 and 35 ft.

DRAPER BELTS – 19 IN. (48.3 CM)

REEL Reel

6 bat

14 ft. (4.27 m) Width

Pickup Reel (Tines)

Plastic

6 (plastic)

Diameter

42 in. (1067 mm)

16 ft. (4.9 m) Width

Drive

Hydraulic / 12 to 60 rpm

Hydraulic / 5 to 61 rpm

WIDTH

SICKLE/KNIFE Type

Overserrated “sta-sharp”/ “super sta-sharp”

Overall Width to Tire Edges

13.5 ft. (4.11 m)

16.5 ft. (5.0 m)

Drive Knife

Section to wobble box Std. 3 in. (76.2 mm)

FD2 FLEXDRAPER ® BY MACDON*

FD225

FD230

FD235

FD240

FD241

FD245

FD250

FD261

CUTTER BAR Cutting Width

25 ft. (7.6 m)

30 ft. (9.1 m)

35 ft. (10.6 m)

40 ft. (12.2 m)

41 ft. (12.5 m)

45 ft. (13.7 m)

50 ft. (15.2 m)

61 ft. (18.6 m)

WEIGHT** Single Knife Drive without FM200

5016 lb. (2 276 kg)

5851 lb. (2 655 kg) 6311 lb. (2 863 kg) 6495 lb. (2 947 kg)

Double Knife Drive without FM200

6487 lb. (2 943 kg) 6759 lb. (3 063 kg) 7136 lb. (3 238 kg)

Double Knife Drive with Triple Reel without FM200

7079 lb. (3 212 kg) 7912 lb. (3 590 kg) 8382 lb. (3 803 kg) 8798 lb. (3 991 kg)

KNIFE Type / Drive / Speed

Single or Double knife / Hydraulic, MacDon design enclosed oil bath knife drive box(es) / 1200-1400/1500 spm, varies depending on header size

REEL

Pick-up reel, five bats, one-piece (single),two-piece (double) or three-piece (triple), flip-over design, cam-leading finger control / Hydraulic / 0 to 67 rpm (varies depending on combine model) / 11.4" (290 mm) length, wear-resistant HD plastic, 4" (102 mm) spacing

Type / Drive / Speed / Fingers

CONVEYOR Type / Drive / Speed

50" (1 270 mm) deep, reversible, rubber skim-coated drapers, double V-guide with tracking, integral seal on leading edge / 0 to 209 m/min (0 to 687 ft./min)

GENERAL

ClearCut™ Pointed Guards - Forged and Double Heat Treated (DHT) with Forged, Single Bolt Adjustment Hold-Down; ClearCut™ PlugFree™ Short Guards - Forged and Double Heat Treated (DHT) with Forged, Dual Bolt Adjustment Hold-Down Fits most current model combines, hydraulic fore-aft reel positioner, hydraulic header tilt, in-cab side draper speed control, cutterbar poly wear plates, auto-header height with header angle and ground pressure indicators EasyMove™ Transport System, ContourMax™ Contour Wheels, Upper Cross Auger, VertiBlade™ Vertical Knife, stabilizer wheels, lateral tilt automatic header height control, Sunflower attachment

Guard Types Available

Standard Features

Field-Installed Options***

Check with your dealer for combine ratings. *Product size availability varies by market. ** All listed weights are approximations and will vary depending on options installed. *** EasyMove™ Transport System is not available for the FD261. 10

C500 SERIES CORN HEADS

C512-20

C512-22

C516-20

C516-22

C518-20

C518-22

C508-30

C512-30

C516-30

GENERAL Number of Rows

Row Spacing

20" or 22"

30"

Number of Gathering Chains

Type of Chain

Endless special chromed pins

OVERALL DIMENSIONS Max Width

253 in. (6,420 mm) 275 in. (6,979 mm) 333 in. (8,452 mm) 364 in. (9,238 mm) 373 in. (9,469 mm) 407 in. (10,333 mm) 247 in. (6,254 mm) 366 in. (9,289 mm) 487 in. (12,360 mm)

Height Ground Level

52 in. (1,308 mm)

55 in. (1,391 mm)

Length (Dividers Down)

113 in. (2,879 mm) 113 in. (2,879 mm) 113 in. (2,879 mm) 113 in. (2,879 mm) 113 in. (2,879 mm) 113 in. (2,879 mm) 113 in. (2,879 mm) 121 in. (3,086 mm) 121 in. (3,086 mm)

Length (Dividers Up)

86 in. (2,186 mm) 86 in. (2,186 mm) 86 in. (2,186 mm) 86 in. (2,186 mm) 86 in. (2,186 mm) 86 in. (2,186 mm) 86 in. (2,186 mm) 96 in. (2,433 mm)

96 in. (2,433 mm)

WEIGHTS Non-Chopping

6,560 lb. (2 976 kg) 6,660 lb. (3 021 kg) 8,170 lb. (3 706 kg) 8,750 lb. (3 969 kg) 8,790 lb. (3 987 kg) 9,010 lb. (4 087 kg) 5,260 lb. (2 386 kg) 8,080 lb. (3 665 kg) 10,490 lb. (4 758 kg)

Chopping

7,730 lb. (3 506 kg) 7,800 lb. (3 538 kg) 9,780 lb. (4 436 kg) 10,370 lb. (4 704 kg) 10,530 lb. (4 776 kg) 10,770 lb. (4 885 kg) 6,480 lb. (2 939 kg) 9,740 lb. (4 418 kg) 12,530 lb. (5 684 kg)

ROW UNITS Point-to-Point Knife Type Stalk Rolls

Standard

Number of knives per roll

4 - single edge

Weed knives (single piece)

Adjustable

Row Unit Drive

Full gearbox drive

Chopper Drive (optional)

Full gearbox drive

Stalk Roll Length

19.25 in. (488 mm)

Stalk Roll Diameter

4.25 in. (108 mm)

Stalk Roll Speed (Nominal)

1061.5 RPM

Gathering Chain Speed (Nominal) SLIP CLUTCHES Row Unit Gearboxes

440 RPM

1 per gearbox - radial pin design

Chopper Gearboxes (if equipped)

1 per gearbox - radial pin design

STRIPPER PLATES In-cab hydraulic control Spring-free self-adjusting feature

Standard

HEADER DATA Auger Diameter

15.75 in. (400 mm)

23.6 in. (600 mm)

Auger Tube Dimension

6.3 in. (160mm)

10.75 in. (273 mm)

Flighting Pitch

19.7 in. (500 mm)

24.6 in. (625 mm)

Reverse Flighting

Yes

SAFETY NEVER HURTS!™ Always read the Operators Manual before operating any equipment. Inspect equipment before using it, and be sure it is operating properly. Follow the product safety signs, and use any safety features provided. CNH Industrial America LLC reserves the right to make improvements in design and changes in specifications at any time without notice and without incurring any obligation to install them on units previously sold. Specifications, descriptions and illustrative material herein are as accurate as known at time of publication, but are subject to change without notice. Availability of some models and equipment builds varies according to the country in which the equipment is used. ©2024 CNH Industrial America LLC. All rights reserved. Case IH is a trademark registered in the United States and many other countries, owned by or licensed to CNH Industrial N.V., its subsidiaries or affiliates. Any trademarks referred to herein, in association with goods and/or services of companies other than CNH Industrial America LLC, are the property of those respective companies. Printed in U.S.A. www.caseih.com CIH24081502
