Giorik Salamanders Brochure
+
ESSENCE OF EVOLUTION SALAMANDERS
Giorik HI TOUCH and HI LITE high-performance salamanders with exclusive patented heating system, generates downward radiant heating which is ideal for browning, grilling and toasting. Uniquely designed height adjustable grilling elements allow the user to effortlessly increase or decrease the distance between food and heat source to achieve perfect results.
2
High Performance
Giorik carried out extensive research and development to deliver an innovative and economical solution to commercial kitchens with its Salamander range. Giorik HI TOUCH and HI LITE deliver measurable cost-savings, productivity gains and less environmental impacts.
Key features valued when comparing Giorik HI TOUCH and HI LITE to traditional salamanders include:
1. 2. 3. 4.
High speed, heat-yield elements rapidly reach optimum cooking temperature
Up to 79% energy saving - Less impact on the environment
Reduced cleaning and maintenance time
Significant cost savings
-42 %
-50 %
-70 %
-79 %
Giorik Salamanders
Traditional Salamanders
Heating Time
Energy Consumption
Cleaning and Maintenance Time
Cost Savings
3
HI-LITE Electric Adjustable Salamander
Dimension (WxDxH)
Model
Cooking Plate Size Capacity
Voltage
Power
mm
mm
GN
V (50Hz opz.60Hz)
kW
SH20T
400 x 544 x 518
390 x 300
2/3 GN 230V 1Ø + N + E 15A Plug & Lead Fitted
3
SH30T
570 x 581 x 519
560 x 358
1/1GN
415V 3Ø + N + E 4.5
*SH30T also available in 230V 1Ø + N + E upon request
4
Features & Benefits
• High performance ultra-rapid salamander unit with GIORIK exclusive patented heating system • Digital display for setting of cooking times from 5 seconds to 15 minutes • Class leading elements heat up in just 8 seconds
• Up to 79% energy saving compared to traditional salamanders • Full power mode, or alternating mode for more gentle cooking • Robust easy glide fully adjustable top • Automatic repetition feature • Easy to clean unit • Stainless Steel wall mount included as standard (adjustable feet supplied in cases where wall mount is not being used) • 24-month warranty
5
Heating Elements
Giorik HI-LITE Salamander features two different heating element combinations:
SH20T
SH20T can operate at maximum temperature with elements used together or in alternating mode
SH30T
In the larger SH30T model, all the elements can be operated at the one time, or with just central element alone. When operated at maximum temperature the central element is electronically regulated into an alternating mode to guarantee even cooking and avoid over-heating
6
Control Panel
1. Heating element on/off button 2. Start-up/repeat button for pre-set cooking cycle 3. Stop cooking/audible alarm signals the end of the pre-set cycle 4. Digital display showing the remaining cooking time 5. Set-timer knob, from 5 seconds to 15 minutes in 5-seconds steps 6. On/Off Switch
6
4
1 2
3
5
7
HI-TOUCH Electric Adjustable Salamander
Dimension (WxDxH)
Model
Cooking Plate Size Capacity
Voltage
Power
mm
mm
GN
V (50Hz opz.60Hz)
kW
ST30T
570 x 581 x 519
560 x 358
1/1GN
415V 3Ø + N + E
4.5
ST40T
735 x 581 x 519
725 x 358
1/1GN
415V 3Ø + N + E
6
*ST30T & ST40T also available in 230V 1Ø + N + E upon request
8
Features & Benefits
• High performance ultra-rapid salamander unit with GIORIK exclusive patented heating system • Touch Screen panel that responds instantly to the touch of a finger • 3 Operation Modes: - Cook Mode for cooking food from 1 second – 20 minutes - Hold Mode to maintain dish at a stable temperature utilising 8 settings from 40ºC to 80ºC - Program Mode (P1,P2,P3) that cooks & then holds food at a required set temperature • Automatic pan/plate detection for maximum energy savings • Class leading elements heat up in just 8 seconds • Up to 79% energy saving compared to traditional salamanders • Full power, or alternating mode for more gentle cooking • Robust easy glide fully adjustable heating rack • Automatic repetition feature • Extremely easy to clean unit • Stainless Steel wall mount included as standard (adjustable feet supplied in cases where wall mount is not being used) • 24-month warranty
9
Heating Elements
ST30T
ST40T
Manufacturing and Operating Features
Touch-screen panel responds instantly to the slightest touch A choice of 3 different operating modes:
1. COOK: for cooking food according to the timer settings 2. HOLD: to maintain the dish at a stable temperature. 1 to 8 settings for temperatures between 40 and 70°C 3. PROGRAM (P1, P2 and P3): cooks and then maintains food at the set temperature. Settings can be stored in the memory
10
Control Panel
6
5
4
3
2
1
1. Appliance on/off 2. Cook / hold cycle start / stop
3. Selector for timed cook mode or indefinite hold mode, manual operation. When the program has been changed, this can be used to switch from the cook to the hold setting and vice-versa 4. Set cooking time, a maximum of 20 minutes in cook mode and select the hold temperature, with 8 temperature settings between 40-70°C 5. Select and set cooking programs. Appliance in ON or STOP position. A quick touch selects the program. Hold down longer to enter program change mode, then another quick touch saves the current settings 6. Heating elements on/off
11
Brisbane
Sydney
Melbourne
Perth
Adelaide
1300 79 1954 www.stoddart.com.au
Auckland
0800 79 1954 www.stoddart.co.nz
Manufactured or Imported & distributed exclusively by:
