Midigate material wasteage with a true 1.2x1.2m half-sheet or 1.2x2.4m full-sheet cut size. The gantry will travel 1.23x1.22m on the Stealth 1200 CNC, and 1.23x2.44m on the Stealth 2400 CNC, so you can guarantee you’ll get the full size of the table to cut across. TRUE CUT SIZE
MINIMAL ASSEMBLY REQUIRED The Stealthv 1200 and 2400 arrive near fully assembled and are pre-calibrated for rapid and precise deployment. This significantly reduces the time typically required for assembly and calibration of CNC systems.
BUILT IN WATER BED The built-in water bed on the Stealth CNC table works to absorb fumes and sparks, giving you a cleaner workspace. With laser welded joints, the water bed is completely leak-free. It comes with two ball valve controlled drainage points with standard hose fittings for quick and easy draining. Additionally, the tables come with laser-cut mild steel slats, and the slat slots mean you can easily replace slats that become warped or damaged.
LOW MAINTENANCE RACK & PINION The rack and pinion systems on the X & Y axes provide consistent and precise linear movement. Made from hardened steel, they’re resistant to wear and deformity, prolonging their lifespan and minimising the need for maintenance. The rack’s teeth are straight cut, which distributes the load uniformly across the tooth face and contributes to their precision and reliability. Plus, their inverted position helps protect them from dust, chips, and other contaminants, preventing downtime.
ADJUSTABLE LEVEL CASTER FEET Easily move the table using the swivel caster wheels and achieve easy and precise table level across most surfaces with the adjustable levelling feature on the wheels.
ADJUSTABLE SIGHTING LASER Each Stealth CNC table is equipped with an adjustable o set sighting laser, ensuring precise alignment and eliminating the guesswork for pierce locations and plate alignment. No need for expensive add-on accessories, the Stealth CNC tables come fully equipped with all necessary features right from the start, providing you with a clear, constant visual of where the cut will start every time.
