The 2020 Edition of Stoddart Standard Products Pricing
™
™
THE OUTDOOR BARBEQUE RANGE Stoddart Town and Park proudly manufactures quality outdoor furniture solutions for a range of small to large outdoor projects here in Australia. Flexibility, experience and commitment are at the forefront of the rigorous research and development process.
The hotplate can also be supplied pre-fitted into Stoddart’s own custom DDA-compliant cabinet, which has been constructed for those in wheelchairs who can use the cantilevered design to position themselves close to the hotplates for easy cooking. Larger frames also have the flexibility to be fitted with a fully welded sink bowl or a second hot plate to suit any desired application. Operated via an easy-to-use, sleek control panel with vandal-resistant piezoelectric start button and dual “power on” and “ready” indicator lights. This new barbeque unit can be customised with any colour selection from the Dulux powdercoat range.
The new Town and Park barbeque range offers a heavy duty, fully welded, 3mm thick stainless steel hotplate and three layers of insulation to assist with heat retention. While providing higher thermal mass, the hotplates innovative design allows for flow control with a rear drain hole, ensuring an easier cooking and cleaning experience. Town and Park prioritise both simplicity and flexibility for the end user. The hotplate has been engineered to fit seamlessly into any standard or non-standard bases currently used in councils throughout Australia.
™
3mm thick Stainless Steel Hotplate
Rear drain hole for cleaning & cooking eiciency
“Power On” button, “Ready” indicator lights & “Shutto” button
15 Amp Plug 1Ø + N + E
Vandal resistant piezoelectric start button
240V / 50Hz 3.2kW
Thick plate providing a higher thermal mass
Wheelchair Accessible DDA-Compliant Frame
Access doors & Service Panels
SWITCHBOARD ORANGE ‡ Gloss 9844207G
X15 ORANGE Gloss 9844461G
RapidCure Technology enables a possible reduction in energ COLORBOND® steel and ® colour names are registered trade ‡ Recommended if overcoating with white to minimise discolo
Popular solid colours including COLORBOND® steel colou powder. Recommended usage includes exterior residentia
LEXICON ® QUARTER Matt 2721378M
PEARL WHITE Gloss 2721114G Gloss
CLASSIC PEARL WHITE Gloss 27281880
WHISPER WHITE Matt 2721376M
Gloss 2601228G
RC
OYSTER Matt 27236858
SURFMIST ® Matt 2722266M Satin 2721137S
Matt 26036858
Matt 2 Satin 2
RC
APO GREY Satin 27232786
SHALE GREY™ Matt 2607557M Matt 2727557M Satin 26083246 Satin 27283246 RC RC
CB
Optional fully welded 400 x 400 x 174mm Sink (on 2200 & 3100 models)
Heavy duty materials with high quality stainless steel finishes
Range of Tapware Accessories
Architectural Colour S Fun, bright solid colours that produce a big impact , deliver includes commercial fitouts, furniture and electrical switch retention is paramount, we recommend the Duratec® Intens St
Large range of Powdercoat colours (Dulux Powdercoat Range)
Fully welded construction to avoid buckling
LEMON YELLOW Gloss 98432120
PINK SPELL Gloss 9844480G
YELLOW GOLD Gloss 98433617
R13 SIGNAL RED Gloss 9844481G
SAFETY YELLOW Gloss 9842015G
FLAME RED Gloss 98419959
SWITCHBOARD ORANGE ‡ Gloss 9844207G
X15 ORANGE Gloss 9844461G
RapidCure Technology enables a possible reduction in energy COLORBOND® steel and ® colour names are registered trade m ‡ Recommended if overcoating with white to minimise discolou
Popular solid colours including COLORBOND® steel colour powder. Recommended usage includes exterior residential
LEXICON ® QUARTER Matt 2721378M
PEARL WHITE Gloss 2721114G Gloss 26
™
POWER
MODEL
3.2kW 15 Amp plug 1Ø + N + E
SPTP-BBQ-EHP1-3200
600 x 600 x 296mm
3.2kW 15 Amp plug 1Ø + N + E
SPTP-BBQ-1P-1000
1000 x 1000 x 904mm
3.2kW 15 Amp plug 1Ø + N + E
1400 x 1000 x 904mm
SPTP-BBQ-1P-1400
3.2kW 15 Amp plug 1Ø + N + E
SPTP-BBQ-1P-1800
1800 x 1200 x 904mm
Left hand BBQ model shown, option for right hand model.
(x2) 3.2kW
2200 x 1000 x 904mm
SPTP-BBQ-2P-2200
15 Amp plug 1Ø + N + E
3.2kW 15 Amp plug 1Ø + N + E
3100 x 1000 x 1000mm
SPTP-BBQ-1PS-3100
Left hand BBQ with right hand sink model shown, option for right hand BBQ with left hand sink, dual BBQ or dual sink available.
™
Brisbane
Sydney
Melbourne
Perth
Adelaide
1300 782 101 www.stoddart.com.au
Auckland
0800 79 1954 www.stoddart.co.nz
Manufactured or Imported & distributed exclusively by:
