TRUE-TANDEM ™ 335 VT & BARRACUDA VERTICAL TILLAGE

Whether it’s spring or fall, Case IH vertical tillage equipment delivers a fast and efficient way to cover lots of acres , manage crop residue, level the soil and achieve optimal field conditions. And our industry-exclusive vertical tillage blades deliver the consistency you need for uniform germination, rapid emergence and increased yield. Available on True-Tandem vertical tillage tools, AFS Soil Command™ tillage technology lets producers optimize the agronomic quality of their seedbed — right from the tractor cab. With site-specific precision and total implement control , you can create a high-efficiency seedbed that is optimized for productivity. TRUE-TANDEM ™ 335VT & BARRACUDA 2 Models | Working Widths: 22 – 47 Ft. 2 In.

TRUE-TANDEM 335 VT & BARRACUDA VERTICAL TILLAGE

Agronomic Design™: Cut, Size and Level�� 4 – 5 Durable Design Levels the Growing Field�� 6 – 7 AFS Soil Command�� 8 – 9 Optimize Every Pass�� 10 – 11 Keep Your Edge with Earth Metal ® Blades �� 12 – 13 Achieve Seedbed Perfection�� 14 True-Tandem Hitch Options�� 15 Productivity, Connectivity and Profitability�� 16 – 17 Specifications �� 18 – 19

AGRONOMIC DESIGN: CUT, SIZE AND BURY MORE RESIDUE Case IH vertical tillage equipment lets you slice through tough residue, uproot root balls and level out the soil to create the best possible seedbed for your next growing season. Our vertical tillage lineup, which includes the True-Tandem 335VT and the True-Tandem 335 Barracuda, is built on proven Agronomic Design principles with industry-exclusive blades, so you can more effectively control soil and residue. Our patented system moves material up, over and out, stratifying soil particles and increasing aeration for improved soil tilth and seedbed conditioning.

CROP RESIDUE MANAGEMENT

Heavy corn stalks, soybean stubble or wheat stubble are controlled from the tractor cab with the True-Tandem’s patented TigerPaw™ Crumbler ® roller-active hydraulic down force. Its double-edged Crumbler puts the final touches on the seedbed in spring or fall. Precise single- point depth adjustment provides greater control over soil residue cover at planting and fits a wide range of soil types, topographies and management objectives. At speeds of up to 6 to 9 miles per hour, shallow blade concavity helps dig up stubborn root balls and properly mix residue for greater nutrient cycling. Robust frames accommodate higher ground speeds and provide balanced weight distribution over tough, fast-changing conditions. This improves soil leveling and creates an environment for accurate seed placement and positive seed-to-soil contact.

SOIL TILTH

Soil tilth functionality breaks through crusty, sealed-over soils to achieve the proper balance of minerals, air and water. Our True-Tandem vertical tillage lineup features exclusive concave wavy blades that send soil and residue up, over and out , promoting a better seedbed finish without the excessive compaction typical of heavier disks and other vertical tillage tools. In addition, hair-pinning is reduced, resulting in improved stand establishment.

SEEDBED CONDITIONS

Properly indexed front and rear blades mounted to an 18-degree gang angle allow unmatched seedbed consistency both on the surface and sub-surface floor. Blade spacing on each gang provides a flat surface with ideal residue sizing. Uniform seedbed depth and temperature contribute to early, even plant emergence. Our patented TigerPaw Crumbler maintains steady contact with the ground and uses rifled, double-edged bars to break up clods and leave a level surface. The rolling Crumbler promotes maximum decomposition and reduced wind erosion.

DON’T JUDGE A SEEDBED BY ITS SURFACE A level seedbed is key to maximizing yields, and it’s the reason why producers spend time and money creating a smooth seedbed surface. However, a seedbed consists of more than just the soil surface. It’s comprised of the entire layer of soil where the seed is placed and germinates, including the seedbed floor. It’s the seedbed floor that impacts the planter’s ability to place seeds at the desired depth and spacing — ultimately affecting yield. Now, with seedbed sensing technology, you can identify what’s hidden below the surface to optimize the seedbed floor.

SEEDBED ASSUMPTION

The seedbed surface is the most important aspect of seedbed preparation. When properly set, nearly all vertical tillage tools provide a smooth surface appearance. So, what makes the Case IH True-Tandem vertical tillage lineup different from the competition? The difference lies beneath the surface.

UNEVEN

SEEDBED REALITY

The seedbed floor impacts even plant emergence and is fundamental in maximizing yields. Nearly all vertical tillage tools leave an uneven seedbed floor—it’s a matter of to what degree. The bumpy sub-surface minimizes planter performance and leads to uneven seed placement.

ADVANTAGES

• The True-Tandem vertical tillage lineup delivers an even, smooth seedbed by leveling the entire soil layer — including the seedbed floor. • Front and rear gang blades are precisely indexed to each other to remove any unevenness in the floor. • The smooth sub-surface maximizes planter productivity to place seeds at the desired depth and spacing. • Achieve uniform germination, rapid emergence and increased yields.

EVEN

The True-Tandem 335VT and Barracuda help you cover more ground in less time so your fields are ready to go when your planting window approaches. Our industry-leading vertical tillage technology enhances operator control, reduces maintenance and extends component life. DURABLE DESIGN LEVELS THE GROWING FIELD

LED LIGHTING

LED lights provide superior brightness, improving visibility during transport, and last longer than traditional incandescent light bulbs. Additionally, a Class 3 powder coat paint finish provides more resistance to impact and fading.

GANG ASSEMBLY

The 18-degree gang angle paired with each blade’s concavity and crimped center results in even cutting and mixing action for a superior finish. With a dynamic duo of Earth Metal and cast-iron components, the gang is assembled with crimp-center blades and cast-iron nodular spools, reducing maintenance, such as tightening bolts or adding additional weight kits. A U-shaped scraper design decreases the likelihood of bending from rocks and debris. Arbor bolts hold torque more consistently and durable parts provide the necessary weight to cut residue and penetrate hard soil, while standard cushion c-springs absorb the shock load when blades hit an obstruction.

SINGLE-POINT HYDRAULIC DEPTH CONTROL Easily adjust operating depth with a single hand crank, conveniently located at the front of the machine to meet your needs.

GREASELESS BEARINGS

Greaseless bearings on wheels and TigerPaw Crumbler reduce routine maintenance and keep you in the field longer. These are featured on wing pivots, rockshafts and the TigerPaw Crumbler.

MAINFRAME AND WINGS

FRAME-MOUNTED GAUGE WHEELS

The rugged, low-maintenance pull-through frame eliminates drift and accommodates higher ground speeds, resulting in uniform weight per blade and improved balance in heavy residue and a wide range of soil moisture conditions. Symmetrical True-Tandem design pulls straight and levels soil.

Our IF 210/75R15 Radial gauge wheels feature an adjustable one-way-pivot design. Stabilizer wheels are bolted directly to the frame for less wobble in normal field-operating conditions. Operators can quickly and easily set the gauge wheels for wing leveling with no wrenches. And stubble-resistant tires help prevent flats caused by tough residue.

FORE AND AFT LEVELING

WALKING TANDEMS

Adjust levelness from the cab using hydraulics and view the gauge from the cab to easily return to your pre-adjusted position.

Standard walking-tandem design offers balance and stability for a more consistent seedbed.

UNLOCK YOUR SEEDBED’S AGRONOMIC POTENTIAL WITH AFS SOIL COMMAND In any field condition, AFS Soil Command tillage technology adds site-specific precision to soil management, unlocking more of a field’s agronomic potential. The industry-leading True-Tandem vertical tillage creates an ideal seedbed, and AFS Soil Command helps operators further maximize their environmental, economic and agronomic performance with total implement control, as-tilled mapping and the ability to create and execute tillage prescriptions.

COORDINATED CONTROL

AFS Soil Command agronomic control technology allows the operator to precisely coordinate control of every component of their True-Tandem vertical tillage to optimize all machine settings as field conditions change. With AFS Soil Command , when the shank depth is adjusted, all other functions of the machine — such as Crumbler pressure and stabilizer wheel position (constant-level only) — react to remain optimized for peak agronomic performance.

TILLAGE PRESCRIPTIONS

Prescription technology takes the same variable rate approach you use for seed and fertilizer rates with site-specific tillage to create a high-efficiency seedbed. And through AFS Connect™ , you can easily create and export tillage prescriptions wirelessly to a connected tractor or export to a USB for traditional data sharing. For example, when completing your final spring tillage pass with the True-Tandem vertical tillage, AFS Soil Command tillage prescriptions give producers the ability to adjust to properly incorporate fertilizer or chemicals, or run shallower to create a perfect seedbed for the planter.

ADD SITE-SPECIFIC PRECISION TO SOIL MANAGEMENT

With AFS Soil Command tillage prescription technology, now you can tailor residue management, residue cover and clod sizing according to each field’s varying conditions and agronomic needs.

SITE-SPECIFIC TILLAGE

• From conservation to conventional , prescription technology takes the same variable rate approach you use for seed and fertilizer rates with site-specific tillage and zone management. • Vary your practices based on changing soil types, field conditions and topography. • Address a range of soil management challenges to make every inch of the field an optimal environment for plants, minimize erosion and preserve moisture where needed. • Create a record of your tillage passes to build a complete picture of your field work for future reference in AFS Connect.

SIMPLE OPERATION

• Developed by the farm manager or an agronomist with the AFS Connect prescription creation tool, predetermined prescription maps indicate variable conditions as they occur , prompting automatic machine adjustments. • With agronomic control technology, coordinated adjustments ensure the entire machine is set for peak performance — no matter the operator. • Gather and visualize tillage data for better agronomic insights into your operation with AFS Connect.

PRODUCTIVE & EFFICIENT

• Automatic adjustments are made quickly and efficiently as the operator travels across the field. • Cover more acres by varying and increasing speed as conditions allow. • Minimize equipment wear and tear — and maximize fuel efficiency — as the machine adjusts to conditions that require little to no tillage treatment.

Proven and dependable AFS components match the performance and ruggedness of True-Tandem vertical tillage tools for increased durability. Tillage prescriptions technology and in-cab controls for each system component help operators make every inch of the field an ideal crop environment. OPTIMIZE EVERY PASS

Hydraulic fore/aft control: maintain consistent agronomic output.

Disk gang depth: slice, cut and bury residue to the producer’s desire.

Internally mounted sensing technology: precise control and feedback.

SITE-SPECIFIC TILLAGE

• With AFS Soil Command tillage prescription technology, you can match variable tillage treatments to your fields’ specific conditions — from residue management and surface compaction removal to improved soil conservation and minimized erosion. • Address a range of soil management challenges to make every inch of the field an optimal environment for planting. • Developed by the farm manager or agronomist, predetermined prescription maps indicate variable conditions as they occur to prompt automatic machine adjustments.

Crumbler pressure: achieve consistent clod sizing and finish.

Preset adjustments: maximize every acre.

Coordinated control: optimize all tillage components.

AGRONOMICALLY CORRECT ADJUSTMENTS

• Properly set disk frame depth lets the True-Tandem 335VT or 335 Barracuda vertical tillage tool precisely condition the seedbed to create an ideal environment for each seed. • Fore and aft levelness delivers a consistent seedbed finish to complement seed placement during planting. • Adjustable Crumbler pressure allows for consistent clod sizing and finish, soil particle stratification and surface leveling. • Up to four presets allow the operator to return to settings optimized for specific field conditions.

The Earth Metal VT Wave blade runs on its edge, causing soil to explode off the front side of the blade and level without back-side pressure, resulting in maximum penetration and reduced compaction when compared with other vertical tillage blades. KEEP YOUR EDGE WITH EARTH METAL BLADES

THE EARTH METAL ADVANTAGE

OVER

Our industry-exclusive Earth Metal blades let you cover rocky terrain and uneven ground with confidence — even at high speeds. Earth Metal blades are engineered and manufactured using a raw boron-based steel formula and precise heat treating process with automation, making them tough and breakage-resistant. Proven more durable than other blades that often contain recycled material, these blades penetrate hard, dry soils and break through surface compaction with ease.

DIRECTION

BARRACUDA BLADE

OUT

The True-Tandem 335 Barracuda features 22-inch serrated blades for aggressive crop residue and soil management, effectively sizing and evenly incorporating even the most stubborn crop residue for faster nutrient cycling. • More concavity to leave behind a blacker surface finish than other vertical tillage blades and tools. • Rugged, serrated “chisel tip” blades stay sharper longer. • Cut residue up to 4 inches deep in one pass, allowing break up of hard, dry soils for increased nutrient cycling.

VT WAVE BLADE

The True-Tandem 335VT features two different options of shallow concavity, fluted 20-inch blades to more effectively cut residue and super charge the soil for better clod sizing, mixing and placing small soil particles in the seed placement zone. The indexed and fluted blades provide the smoothest, most uniform seedbed at depths up to 3 inches deep. • 20×0.256 in. (508×6.5 mm) VT Wave shallow concavity blades. • Rugged blade thickness of 0.256 in. (6.5 mm) provides protection from rock damage. • Longer edge life 20×0.197 in. (508×5 mm) VT Wave shallow concavity blade. – The 0.197 in. (5 mm) thick blade provides the same agronomic benefits as the 0.256 in. (6.5 mm) blade but stays sharper throughout its life – Ideal for areas without rocks

ACHIEVE SEEDBED PERFECTION

PUT THE FINISHING TOUCHES ON YOUR SEEDBED WITH THE DOUBLE-EDGED TIGERPAW CRUMBLER.

TIGERPAW CRUMBLER OPTION

• The TigerPaw Crumbler is mounted directly to the main frame, making it a more stable, long-lasting and reliable tool. • Each TigerPaw Crumbler bar has two edges to hit large clods twice and tuck residue in the surface for improved leveling and better seed-to-soil contact. • The bars are rifled for consistent down pressure on the soil. Hydraulic cylinders provide quick and easy adjustability and settings to match field conditions. • Down force adjustment is made from the hydraulic valve block found near the front of the tool. The Crumbler position is controlled from the cab and can be run in three different modes: active down pressure, float or raised up to get through wet spots. • AFS Soil Command agronomic control technology can be used to optimize Crumbler pressure for maximum agronomic performance.

HOOK TO YOUR TRACTOR AND GO

The rugged True-Tandem frame provides two height options for the hitch, depending on the tractor’s drawbar. Whether going across rugged, rolling terrains or field to field, you’ll be able to easily maneuver the equipment.

HITCH OPTIONS

• Front T-Bone Hitch/Pull Frame: Engineered to maximize rear tractor tire clearance during tight turns, the Front T-Bone Hitch is spring cushioned and features the “Perfect Hitch” clevis for tractor pin compatibility and extra safety during hook-up. • Swivel Hose Stand: Mounted on the pull hitch, the Swivel Hose Stand keeps hydraulic hoses and wires out of the way during hook-up and transport. • Rear Hitch: This optional feature allows for pull-type attachments for additional soil conditioning. Equipped with a 9-pin electronic connector for lighting and one set of hydraulic couplers, the Rear Hitch has a vertical capacity of 1,000 pounds.

PRODUCTIVITY, CONNECTIVITY AND PROFITABILITY Understanding every aspect of your operation is the key to improving your bottom line. With AFS Connect, view your equipment data and agronomic layers in one place to help you make informed decisions—both in the planning stages for the year and those critical in-season pivots. Plus, with the AFS Connect app, you can successfully manage your operation anytime, anywhere.

KEEP MOVING IN SEASON

WORK SMARTER BY TRACKING EQUIPMENT

PLAN YOUR SEASON

Using all the tools available to you keeps your operation running at top speed. • Create scouting reports through the AFS Connect mobile app to keep an eye on certain areas all season long. • With AFS Connect-equipped machines, add AFS AccuSync ® to share machine data in field, reducing skips and overlaps. • View and share reports and other relevant information with your landlord, agronomic consultant or Case IH dealership.

Having every pass planned before the year starts can help when it’s time to get to the field to begin the work. • Review previous years’ data to develop your approach for a new season. • Develop tillage prescriptions for AFS Soil Command- equipped tools to work every acre exactly how you want. • Send field data, guidance lines and prescriptions to connected equipment.

Knowing the status of all your equipment helps you cover more acres in a day. • Track equipment location with minute-by-minute updates to plan your next move. • Receive push notifications when a tractor enters or exits a set geofence for up-to-date status on job completion. • View and compare machine information, such as operating speed and fuel usage, to learn how machines are being used in the field. • Access the AFS Pro 1200 display remotely with Remote Display Viewing to coach operators through setup and operation.

THE AFS CONNECT APP

View and monitor your equipment and field information in one place, all on your mobile device or tablet.

CASE IH KNOWLEDGE BASE

MY.CASEIH.COM

EQUIPMENT INFORMATION AT YOUR FINGERTIPS

When you have questions about Case IH equipment maintenance, there’s no time to lose getting back in the field. My.CaseIH.com is your destination for Case IH product support, including free operators manual downloads, AFS training videos, how-to tutorials and maintenance tips to help you through questions or situations you encounter every day. Create a free MyCaseIH account and use the same login credentials to access the features of AFS Connect and the AFS Connect app today!

SHARE WITH TRUSTED PARTNERS

TRUE-TANDEM 335 BARRACUDA SPECIFICATIONS

SPECIFICATIONS

22 FT. (6.7 M)

25 FT. (7.6 M)

28 FT. (8.5 M)

31 FT. (9.4 M)

34 FT. (10.4 M)

42 FT. (12.8 M)

47 FT. (14.3 M)

PTO Horsepower

220 –330 hp (164 – 246 kW)

250 –375 hp (186 – 280 kW)

280 –420 hp (209 – 313 kW)

310 –465 hp (231 – 347 kW)

340 –510 hp (254 – 380 kW)

360 –545 hp (268 – 406 kW)

400 –600 hp (298 – 447 kW)

Remote Hydraulic Valves

Four hydraulic remote valves

Four hydraulic remote valves plus 3/4" motor return

Remote Hydraulic Valves - w/ AFS Soil Command

Power Beyond Valve + up to 3 remote valves

Operating Depth/Speed

1 – 4 in. (25.4 – 101.6 mm), at 6 – 9 mph

FRAME

6 × 8 in. (152 × 204 mm) and 4 × 4 in. (102 × 102 mm) fore-aft tubes 6 × 6 in. (152 × 152 mm) fore-aft tubes

6 × 8 in. (152 × 204 mm) and 4 × 6 in. (102 × 152 mm) fore-aft tubes 4 × 6 in. (102 × 152 mm) and 6 × 6 in. (152 × 152 mm) fore-aft tubes

Main Frame

6 × 6 in. (152 × 152 mm) and 4 × 6 in. (102 × 152 mm) fore-aft tubes

Wing Frame

6 × 6 in. (152 × 152 mm) and 4 × 6 in. (102 × 152 mm) fore-aft tubes

Gang Frame

3 × 5 in. (76 × 127 mm) rectangular tube

Gang Angle

18 degrees front and rear

Fold

Single Fold

Double Fold

WHEELS AND TIRES

8-bolt, 16.5 × 16.1 (load range E)

Main Frame

8-bolt, 12.5 × 15 Fl standard, 340/55-16 radial stubble resistant optional

8-bolt, 380/60 R16.5 radial

10-bolt, 440/55R18

6-bolt, 11L × 15 8-ply standard; 8-bolt 380/60 R16.5 radial stubble resistant optional

Wing Frame

6-bolt, 11L × 15 8-ply standard; 8-bolt 340/55-16 radial stubble resistant tires optional

6-bolt, 12.5L – 15 FI (load range D)

Gauge Wheels

Pivoting wing stabilizer 6-bolt, 7.60 × 15 8-ply

Castoring wing stabilizer 9.5L × 15 FI (load range E)

ARBOR BOLT Size

1.5 in. (38 mm), round spring steel

CUSHION GANG BLADES AND BEARINGS Spacing

7.5 in. (191 mm)

22 × 0.256 in. (559 × 6.5 mm) Barracuda blade; Taper blades - 20 × 0.256 in. (508 × 6.5 mm) Barracuda blade; End blades 18 × 0.256 in. (457 × 6.5 mm) VT Wave blades

Blade Diameter/Thickness

Number of Blades

106

114

142

158

Number of Bearings

Tillage Width

22 ft. 5 in.

24 ft. 9 in.

28 ft. 4 in.

31 ft. 10 in.

34 ft. 3 in.

42 ft. 5 in. (12.9 m)

47 ft. 2 in. (14.4 m)

REAR ATTACHMENTS TigerPaw Crumbler

Standard, with double-edge formed flat bars and active hydraulic down pressure

3-Bar Rigid Coil Tine Harrow

US Delta rice only

SCRAPERS Rigid

Spool scraper; gang-to-gang scraper; and trunnion bearing shield all standard

TRANSPORT SIZE (WITH CRUMBLER RAISED) Transport Width

14 ft. 6 in. (4.4 m)

17 ft. 4 in. (5.3 m)

18 ft. 0 in. (5.5 m)

18 ft. 6 in. (5.64 m)

Transport Height

10 ft. 5 in. (3.2 m)

11 ft. 7 in. (3.5 m)

11 ft. 8 in. (3.6 m)

13 ft. 3 in. (4.0 m)

13 ft. 7 in. (4.1 m)

13 ft. 4 in. (4.06 m)

WEIGHT Total Weight

15,600 lb. (7 076 kg)

16,500 lb. (7 484 kg)

18,000 lb. (8 165 kg)

19,600 lb. (8 890 kg)

21,900 lb. (9 934 kg)

28,500 lb. (12 927 kg)

33,370 lb. (15 136 kg)

TRUE-TANDEM 335VT SPECIFICATIONS

SPECIFICATIONS

22 FT. (6.7 M)

25 FT. (7.6 M)

28 FT. (8.5 M)

31 FT. (9.4 M)

34 FT. (10.4 M)

42 FT. (12.8 M)

47 FT. (14.3 M)

PTO Horsepower

110 – 220 hp (82 – 164 kW)

125 – 250 hp (93 – 186 kW)

140 – 280 hp (104 – 209 kW)

155 – 310 hp (116 – 231 kW)

170 – 340 hp (127 – 254 kW)

250 – 420 hp (186 – 313 kW)

280 – 470 hp (209 – 350 kW)

Four hydraulic remote valves plus 3/4 " motor return

Remote Hydraulic Valves

Four hydraulic remote valves

Remote Hydraulic Valves - w/ AFS Soil Command

Power Beyond Valve + up to 3 remote valves

Operating Depth/Speed

1 – 3 in. (25 – 76 mm), at 6 – 8 mph

FRAME

6 × 8 in. (152 × 204 mm) and 4 × 4 in. (102 × 102 mm) fore-aft tubes 6 × 6 in. (152 × 152 mm) fore-aft tubes

6 × 8 in. (152 × 204 mm) and 4 × 6 in. (102 × 152 mm) fore-aft tubes 4 × 6 in. (102 × 152 mm) and 6 × 6 in. (152 × 152 mm) fore-aft tubes

Main Frame

6 × 6 in. (152 × 152 mm) and 4 × 6 in. (102 × 152 mm) fore-aft tubes

Wing Frame

6 × 6 in. (152 × 152 mm) and 4 × 6 in. (102 × 152 mm) fore-aft tubes

Gang Frame

3 × 5 in. (76 × 127 mm) rectangular tube

Gang Angle

18 degrees front and rear

Fold

Single fold

Double fold

WHEELS AND TIRES (STUBBLE-RESISTANT TIRE OPTION, SHOWN IN PHOTO)

8-bolt, 16.5 × 16.1 (load range E)

10-bolt, 440/55R18

Main Frame

8-bolt, 12.5 × 15 Fl standard, 340/55-16 stubble resistant optional

8-bolt, 380/60 R16.5

Wing Frame

6-bolt, 11L × 15 8-ply standard, 8-bolt w/stubble resistant tires optional

6-bolt, 12.5L – 15 FI (load range D)

Gauge Wheels

Pivoting wing stabilizer 6-bolt, 7.60 × 15 8-ply

Castoring wing stabilizer 9.5L × 15 FI (load range E)

ARBOR BOLT Size

1.5 in. (38 mm), round spring steel

CUSHION GANG BLADES AND BEARINGS Spacing

7.5 in. (191 mm)

Standard blades: 20 × 0.256 in. (508 × 6.5 mm); Taper blades 18 × 0.256 in. (457 × 6.5 mm); End blades 16 × 0.256 in. (406 × 6.5 mm)

Standard blades: 20 × 0.256 in. (508 × 6.5 mm); Taper blades 18 × 0.256 in. (457 × 6.5 mm); End blades 16 × 0.256 in. (406 × 6.5 mm) Optional: 20 × 0.197-in (508 × 5 mm); Taper blades 18 × 0.197-in (457 × 5 mm); End blades 16 × 0.197 in. (406 × 5 mm)

Blade Diameter

Number of Blades

106

114

142

158

Number of Bearings

Tillage Width

22 ft. 2 in. (6.8 m)

24 ft. 7 in. (7.5 m)

28 ft. 2 in. (8.6 m)

31 ft. 8 in. (9.6 m)

34 ft. 1 in. (10.4 m)

42 ft. 5 in. (12.9 m)

47 ft. 2 in. (14.4 m)

REAR ATTACHMENTS TigerPaw Crumbler

Standard, 14 in. diameter with double-edge formed flat bars with hydraulic positioning and active down pressure

3-Bar Rigid Coil Tine Harrow

US Delta rice only

SCRAPERS-RIGID

Spool scraper; gang-to-gang scraper; and trunnion bearing shield all standard

TRANSPORT SIZE (WITH CRUMBLER RAISED) Transport Width

14 ft. 6 in. (4.4 m)

17 ft. 4 in. (5.3 m)

18 ft. 0 in. (5.5 m)

18 ft. 6 in. (5.64 m)

Transport Height

10 ft. 5 in. (3.2 m)

11 ft. 7 in. (3.5 m)

11 ft. 8 in. (3.6 m)

13 ft. 3 in. (4.0 m)

13 ft. 7 in. (4.1 m)

13 ft. 4 in. (4.06 m)

WEIGHT Total Weight

19,600 lb. (8 890 kg)

16,208 lb. (7 367 kg)

17,743 lb. (8 065 kg)

19,233 lb. (8 742 kg)

21,543 lb. (9 792 kg)

28,000 lb. (12 700 kg)

32,815 lb. (14 885 kg)

SAFETY NEVER HURTS!™ Always read the Operators Manual before operating any equipment. Inspect equipment before using it, and be sure it is operating properly. Follow the product safety signs, and use any safety features provided. CNH Industrial America LLC reserves the right to make improvements in design and changes in specifications at any time without notice and without incurring any obligation to install them on units previously sold. Specifications, descriptions and illustrative material herein are as accurate as known at time of publication, but are subject to change without notice. Availability of some models and equipment builds varies according to the country in which the equipment is used. ©2023 CNH Industrial America LLC. All rights reserved. Case IH is a trademark registered in the United States and many other countries, owned by or licensed to CNH Industrial N.V., its subsidiaries or affiliates. Any trademarks referred to herein, in association with goods and/or services of companies other than CNH Industrial America LLC, are the property of those respective companies. Printed in U.S.A. www.caseih.comCIH23011702
