ECOLO-TIGER ® 875 DISK RIPPER
The Ecolo-Tiger 875 sizes and mixes crop residue for nutrient release that’s in sync with crop demands. It reestablishes pore space, improves internal drainage and increases water-holding capacity. And it creates level soil conditions to provide a high-yield environment for plants. The result is industry-leading productivity and agronomic advantages for a superior soil finish you expect from Case IH. Available on the Ecolo-Tiger 875, AFS Soil Command™ tillage technology allows producers to optimize the agronomic quality of their seedbed — right from the tractor cab. With site-specific precision and total implement control, you can match variable tillage treatments to the specific conditions of your field like never before. ECOLO-TIGER 875 4 Models | Working Widths: 14 – 26 Ft.
“ We needed prescription tillage 30 years ago. I would not allow a disk- ripper in this field if it was not capable of on-the-go adjustment. ” Doug Radcliffe, Circleville, OH
2
ECOLO-TIGER 875 DISK RIPPER
Agronomic Design��������������������������������������������������������������������������������������������������������������� 4 – 7 AFS Soil Command����������������������������������������������������������������������������������������������������������� 8 – 11 Productive Performance�������������������������������������������������������������������������������������������������� 12 – 13 Productivity, Connectivity and Profitability������������������������������������������������������������������������� 14 – 15 Product Specifications���������������������������������������������������������������������������������������������������������� 16
3
CREATING A POSITIVE ENVIRONMENT FOR AGRONOMIC PERFORMANCE
More than 40 years of mulch-till leadership stands behind the Case IH Ecolo-Tiger 875 with its Agronomic Design ™ features for ideal seedbed conditions. And now, with AFS Soil Command agronomic control technology, you have the tools to know what’s hidden in your fields, so you can make agronomic adjustments.
4
SEEDBED CONDITIONS
SOIL TILTH
CROP RESIDUE MANAGEMENT
Case IH disk rippers give you the flexibility to finish the field to match your farming practices. Creating a first-pass soil surface that settles level prior to secondary tillage and planting maximizes each plant’s yield potential leading to a more uniform plant stand. See pages 8-11 for more information on AFS Soil Command agronomic control technology.
Ideal soil composition — known as soil tilth — is 50 percent soil and 50 percent pore space, with water and air equally distributed within the pore space. Soil compaction eliminates this needed pore space and is a common yield-robbing culprit. Proper primary tillage using a Case IH disk ripper effectively fractures compaction to increase soil tilth encouraging vigorous root development which promotes better stands and higher-yielding plants. You will see soil warm faster and more evenly for earlier spring planting, increased water absorption and a reduction in ponding.
Case IH disk rippers help you cut, size and mix crop residue to reduce erosion and increase production capacity. This effective crop residue management allows you to increase organic-matter content in the soil. This provides a soil/residue mixture that allows moisture to penetrate the subsoil faster and decreases erosion through improved porosity and drainage.
5
MAKING THE PERFECT SEEDBED
After years of extensive field research, Case IH found that a stand can be in jeopardy if soil clods are too big or if the holes they roll out of are left in the field. Clod and valley sizes should be 6 inches or less in prairie soils and 4.5 inches or less in forest soils when coming out the back of a tillage pass in the fall.
SOIL QUALITY FOR STAND AND PLANT PERFORMANCE
Maximizing yield potential starts at the time of primary tillage, one of the most critical elements is soil output. Case IH has discovered that growers can dramatically reduce the risk of emergence problems in the spring by reducing both clod and valley sizes out the back of a tillage pass in the fall. Large clods leave holes, which are detrimental to seeds. The different heights in the soil surface result in variable moisture and temperature levels, with the holes staying wet and cold — one of the reasons for slow, uneven germination of seeds. The Ecolo-Tiger handles today’s realities of high plant population, tough Bt corn residue and earlier planting dates, providing aggressive residue sizing and mixing for more rapid nutrient cycling.
Maximum Clod Size After Primary Tillage MAXIMUM CLOD SIZE AFTER PRIMARY TILLAGE*
Maximum Clod Size After Primary Tillage
4.8" 4.8"
Ecolo-Tiger 875
Ecolo-Tiger 875
8.3" 8.3"
Competitive Model
Competitive Model
Max Valley Size In. (mm)
4 (102) Max Valley Size In. (mm) 6 (152) 8 (203)
0
2 (51)
10 (254)
12 (305)
0
2 (51)
4 (102)
6 (152)
8 (203)
10 (254)
12 (305)
Maximum Valley Size After Primary Tillage Maximum Valley Size After Primary Tillage MAXIMUM VALLEY SIZE AFTER PRIMARY TILLAGE*
2.5" 2.5"
Ecolo-Tiger 875
Ecolo-Tiger 875
3.8" 3.8"
Competitive Model
Competitive Model
Max Valley Depth In. (mm)
4 (102) Max Valley Depth In. (mm) 6 (152) 8 (203)
0
2 (51)
10 (254)
12 (305)
0
2 (51)
4 (102)
6 (152)
8 (203)
10 (254)
12 (305)
6
*2007 Case IH tillage agronomy research conducted in Central, IL.
HIGH-DENSITY TIGER POINTS
Redesigned Tiger Points run 1 inch under the compaction layer and deliver the proven Case IH lift-twist-roll soil action. This is accomplished with fewer drafts, creating smoother fields, better soil tilth for improved drainage and water-holding capacity, and extending the point life. Three tip options are available:
• 2-inch welded chromium carbide capped tip • 7-inch welded chromium carbide capped tip • 7-inch replaceable tip
UNIQUE DOUBLE-EDGE TIGERPAW™ CRUMBLER ®
Each bar on the Crumbler has two edges which provides industry-leading soil leveling output to reduce clod size to 6 inches or less. This results in less risk of emergence problems and the ability to maintain adequate soil structure. The optional Crumbler can also be positioned hydraulically from the cab. Three positions are available: Spring Downforce Applied, Float (moist/wet conditions) and Raised.
TWO DISK OPTIONS
Individual 24-inch Earth Metal ® disk blades on 15-inch centers for 7.5-inch index spacing. This combination allows soil and residue cutting and flow in heavy, wet soils while protecting the blades in rocky conditions. Disk gangs feature 26-inch Earth Metal blades that resist warping and are spaced 12 inches apart for maximum mixing, cutting and residue sizing.
7
8
In any field condition, AFS Soil Command tillage technology adds site-specific precision to soil management, unlocking more of a field’s agronomic potential. The industry-leading Ecolo-Tiger 875 Disk Ripper creates an ideal seedbed, and AFS Soil Command helps operators further maximize their environmental, economic and agronomic performance with total implement control, as-tilled mapping and the ability to create and execute tillage prescriptions. UNLOCK YOUR SEEDBED’S AGRONOMIC POTENTIAL WITH AFS SOIL COMMAND
COORDINATED CONTROL
AFS Soil Command agronomic control technology allows the operator to precisely coordinate control of every component of their Ecolo-Tiger 875 Disk Ripper to optimize all machine settings as field conditions change. With AFS Soil Command , when the shank depth is adjusted, all other functions of the machine — such as Crumbler pressure and stabilizer wheel position (constant-level only) — react to remain optimized for peak agronomic performance.
TILLAGE PRESCRIPTIONS
Prescription technology takes the same variable rate approach you use for seed and fertilizer rates with site-specific tillage to create a high-efficiency seedbed. Through AFS Connect , you can easily create and export tillage prescriptions sending wirelessly to connected tractor or export to a USB for traditional data sharing. For example, when completing your final spring tillage pass with the Ecolo-Tiger 875 Disk Ripper, AFS Soil Command tillage prescriptions give producers the ability to adjust to properly incorporate fertilizer or chemicals, or run shallower to create a perfect seedbed for the planter.
9
ADD SITE-SPECIFIC PRECISION TO SOIL MANAGEMENT
With AFS Soil Command tillage prescription technology, now you can tailor residue management, residue cover, and clod sizing according to each field’s varying conditions and agronomic needs.
SITE-SPECIFIC TILLAGE
• From conservation to conventional , prescription technology takes the same variable rate approach you use for seed and fertilizer rates with site-specific tillage and zone management. • Vary your practices based on changing soil types, field conditions and topography. • Address a range of soil management challenges to make every inch of the field an optimal environment for plants, and minimize erosion and preserve moisture where needed. • Create a record of your tillage passes to build a complete picture of your field work for future reference in AFS Connect.
• With agronomic control technology, coordinated adjustments ensure the entire machine is set for peak performance — no matter the operator. • Gather and visualize tillage data for better agronomic insights into your operation with AFS Connect.
PRODUCTIVE & EFFICIENT
• Automatic adjustments are made quickly and efficiently as the operator travels across the field. • Cover more acres by varying and increasing speed as conditions allow. • Minimize equipment wear and tear — and maximize fuel efficiency — as the machine is adjusted in conditions that require little to no tillage treatment.
SIMPLE OPERATION
• Developed by the farm manager or an agronomist with the AFS Connect prescription creation tool, predetermined prescription maps indicate variable conditions as they occur , prompting automatic machine adjustments.
10
Disk gang pressure: reduce pressure on frame
New hydraulic fore/aft positioning: maintain consistent agronomic output
Disk gang depth: create agronomic residue cover
Shank depth: target the compaction layer
Crumbler pressure: achieve consistent clod sizing
Coordinated control: optimize all components
11
PRODUCTIVE PERFORMANCE, AGRONOMIC RESULTS As the most aggressive disk ripper on the market, the Ecolo-Tiger 875 offers excellent residue flow thanks to impressive disk-cutting power and shank positioning. The high, 38-inch underframe and minimum 36-inch spacing between shank points maximizes material flow and minimizes plugging. Because of the shank fore/aft positioning on the 875 Ecolo-Tiger, the actual spacing between each shank is 36 inches, and in many cases, it’s 48-inches, for maximum throughput and productivity.
STRONGER FRAME CONNECTIONS
Overlapping weld joints and gussets add additional support to stress point.
ACHIEVE IDEAL SOIL TILTH
HYDRAULIC DISK LEVELER
DOUBLE-EDGE TIGERPAW CRUMBLER
Opposing leveling disks mounted on a common mount fill in the shank paths for a smooth finish.
Spring reset or shear bolt shank spaced at 24-in. (610 mm) matches your field conditions.
Size clods and put the finishing touches to the fall seedbed for an ideal spring condition for high-efficiency planting. Other options include: • No harrow (Leveler only)
• 5-bar spike harrow • HD Coil Tine harrow
12
X-DISK FRAME EASILY HANDLES CROP RESIDUE
LONG LIFE, DURABLE TIGER POINTS
Aggressively size and mix residue for rapid nutrient cycling. Soil and residue are cut and mixed by the first rank, followed by the rear rank to leave a uniform mixture of soil and residue. Disks are set at a 15-degree angle, allowing for more soil turning and machine stability.
High-strength, high-wearing Tiger Points deliver the proven Case IH lift-twist-roll soil action. They deliver three times the point life and are up to five times more durable than previous designs.
MORE IMPACT RESISTANT
Full-coverage powder coat paint finish provides more resistance to impact, scratching and paint fading.
GET MORE DONE
EASE OF TRANSPORT
EARTH METAL DISK GANGS
7 mph operating speed saves time and optimizes the power of your tractor.
Narrow transport widths make it possible to get from field to field faster. It’s also easy to change tractors thanks to a welded pull-hitch design that eliminates the need for complex clevis hitches with multiple holes and positions.
Spools between the Earth Metal blades add weight to increase cutting pressure and clearance for residue flow to the gangs. The scraper assembly keeps the gang flowing free and prevents plugging with mud and other accumulations.
13
PRODUCTIVITY, CONNECTIVITY AND PROFITABILITY Understanding every aspect of your operation is the key to improving your bottom line. With AFS Connect, view your equipment data and agronomic layers in one place to help you make informed decisions – both in the planning stages for the year and those critical in-season pivots. Plus, with the AFS Connect app, you can successfully manage your operation anytime, anywhere.
KEEP MOVING IN SEASON
WORK SMARTER BY TRACKING EQUIPMENT
PLAN YOUR SEASON
Using all the tools available to you keeps your operation running at top speed. • Create scouting reports through the AFS Connect mobile app to keep an eye on certain areas all season long. • With AFS Connect equipped-machines, add AFS AccuSync to share machine data in field, reducing skips and overlaps.
Having every pass planned before the year starts can help when it’s time to get to the field to begin the work. • Review previous years’ data to develop your approach for a new season. • Develop tillage prescriptions for AFS Soil Command- equipped tools to work every acre exactly how you want. • Send field data, guidance lines and prescriptions to connected equipment.
Knowing the status of all your equipment helps you cover more acres in a day. • Track equipment location with minute-by-minute updates to plan your next move. • Receive push notifications when a tractor enters or exits a set geofence for up-to-date status on job completion. • View and compare machine information, such as operating speed and fuel usage, to learn how machines are being used in the field. • Access the AFS Pro 1200 display remotely with Remote Display Viewing to coach operators through setup and operation.
• View and share reports and other relevant information with your landlord, agronomic consultant or Case IH dealership.
14
THE AFS CONNECT APP
View and monitor your equipment and field information in one place, all on your mobile device or tablet.
CASE IH KNOWLEDGE BASE
MY.CASEIH.COM
EQUIPMENT INFORMATION AT YOUR FINGERTIPS
When you have questions about Case IH equipment maintenance, there’s no time to lose getting back in the field. My.CaseIH.com is your destination for Case IH product support, including free operators manual downloads, AFS training videos, how-to tutorials and maintenance tips to help you through questions or situations you encounter every day. Create a free MyCaseIH account and use the same login credentials to access the features of AFS Connect and the AFS Connect app today!
SHARE WITH TRUSTED PARTNERS
D
15
WEIGHT
7-SHANK MACHINE
9-SHANK MACHINE
11-SHANK MACHINE
13-SHANK MACHINE
Approximate with Disk Gangs, S/R Shanks and Reels
14,470 lb. (6 560 kg)
20,000 lb. (9 070 kg)
25,220 lb. (11 440 kg)
28,200 lb. (12 790 kg)
TRANSPORT STYLE Main Frame (Overall Length with Crumbler)
33 ft. 4 in. (10.19 m)
33 ft. 9 in. (10.59 m)
Working Width
14 ft. (4.27 m)
22 ft. (6.71 m)
26 ft. (7.92 m)
18 ft. (5.49 m)
Transport Width
16 ft. (4.88 m)
16 ft. 9 in. (5.10 m)
18 ft. (5.5 m)
Single 425 / 65R × 22.5 recapped truck tires; Optional Single VF 445-65R22.5 stubble resistant radial tires
Walking tandem 16.5L×16.1 Fl, Load Range E, with tubes. Option walking tandem 440/55R18 stubble resistant radial tires
Wheels
TRACTOR REQUIREMENTS PTO Horsepower per Foot
18 to 20 Hp (44 to 49 kW/m)
PTO Horsepower per Shank
35 to 40 Hp (86 to 98 kW/m)
Operating Speed
5 to 7 mph (8 to 11 km/h) recommended
BLADES Blade Protection
Cushion mounted blades plus a frame that lifts against a spring loaded relief that automatically resets when obstruction is cleared
Individual Mounted Blades
1 C-hanger per blade (Optional C-hanger flex protection)
Gang Mounted Blades
Multiple C-hangers per gang with scrapers
EARTH METAL ® DISK BLADES Individual Option
24 in. (610 mm) diameter individually mounted on 15 in. (381 mm) centers
Trunion Gang Option
26 in. (660 mm) diameter concave gang mounted on 12 in. (305 mm) centers , 1.5 in. (38 mm), round spring steel
SHANK MOUNT ASSEMBLY Shear Bolt Shank Protection
24 in. (610 mm) effective spacing, ideal for rock-free fields. (Optional reversible shank shin available)
Auto-Reset Shank Protection
24 in. (610 mm) effective spacing, ideal for rocky conditions. (Optional reversible shank shin available)
Auto-Reset
13 in. (330 mm) of trip clearance, hardened pins and composite bushings
Auto-Reset and Shear Bolt
5/8 in. (16 mm) diameter grade 5 shear bolt
GROUND-ENGAGING SHANKS AND POINTS Shanks
1-1/4×4 in. (32×102 mm), optional wear shin
Shank Points
Chromium carbide capped Tiger Points
SOIL FINISHING OPTIONS Hydraulic Disk Leveler
Opposing blades on a common arm for general all-purpose leveling
Excels in well-drained soil conditions: TigerPaw ™ Crumbler ® is available with mechanical or hydraulic positioning
Hydraulic Disk Leveler plus Optional Double-edge, Mounted Crumbler
Hydraulic Disk Leveler plus Optional Spike Harrow or Coil Tine Harrow
Choose option that’s right for your prevailing soil and weather conditions
