FLEX-TILL 600 CHISEL PLOW SPECIFICATIONS
4
FLEX-TILL 600 CHISEL PLOW Working Widths: 26 Ft. 3 In. – 62 Ft.
SUPERIOR SOIL PENETRATION AND ACCURACY
The Case IH Flex-Till 600 meets your tillage demands for soil penetration and accuracy. Its heavy-duty tubular frame construction is designed to handle tough tillage conditions and heavy residue flow with ease. The flexible frame and floating hitch design provide unmatched land-following ability to cope with all types of terrain. You can be sure the Flex-Till 600 provides consistent tillage depth. Easy-to-set single cylinder depth control and flexible frame design ensure accurate, uniform depth across the entire working width. The durability and reliability you’ve come to expect from Case IH is an integral part of the Flex-Till 600. It’s built to last! The Flex-Till 600 has a range of shank spacing and trip load options to match your soil conditions. Shanks are available in 9-inch (229 mm) or 12-inch (305 mm) spacing in a variety of cutting widths that accommodate from 27 to 81 flexible shanks. Couple the versatility of the shank spacing options with the variety of available ground-engaging tools and optional equipment, like a 3- or 4-bar harrow, to create your custom tillage solution.
Even at its widest working width of 62-ft. (18.9 m), the Flex-Till 600 folds to 21-ft. 8-in. (6.6 m) wide for convenient transportation between fields. Narrower models fold to 18-ft. 6-in. (5.6 m).
FEATURES
A Floating hitch provides improved front-to-back land following capabilities. B Single point depth control means better stability, more accuracy and easier maintenance.
C Flexible frame design ensures exceptional ground following. D 550 or 650 lb. (250 or 295 kg) trips are available to match your needs and field conditions. E Optional mounted harrows let you control field finish.
A
C
E
TIRES AND OPTIONS
550 lb. (250 kg), 1 × 2 in. (25.4 × 50.8 mm) shanks, 2.25 in. (57.1 mm) centers fit 50˚, 9 in. (229 mm) spacing 650 lb. (295 kg), 1.25 × 2 in. (31.7 × 50.8 mm) shanks, 2.25 in. (57.1 mm) centers fit 50˚, 12 in. (305 mm) spacing
B
Tips and shanks
3-section models: 12 tires 5-section models: 18 tires
Tires
9" (229 mm) spacing, 35-53 shank, 3-section models: 11L × 15 (D) 9" (229 mm) spacing, 55-57 shank, 3-section models: 11L × 15 (F) 9" (229 mm) spacing, 5-section models: 235/75R × 17.5 (H) 12" (305 mm) spacing, 27-38 shank, 3-section models: 11L × 15 (D) 12" (305 mm) spacing, 39 & 44 shank, 3-section models: 11L × 15 (F) 12" (305 mm) spacing, 5-section models: 235/75R × 17.5 (H)
Center tires
Mounted harrows Air packages Ground engagement tools Rear tow hitches
Options
D
FLEX-TILL 600 SPECIFICATIONS
9 IN. (229 MM) SPACING* NUMBER OF SHANKS 35
37
43
45
47
49
51
53
55
57
59
61
63
65
71
73
79
81
3-SECTION MODELS
5-SECTION MODELS
Working Width ft. in. (m)
26' 3" (8.0)
27' 9" (8.5)
32' 3" (9.8)
33' 9" (10.3)
35' 3" (10.8)
36' 9" (11.2)
38' 3" (11.7)
39' 9" (12.1)
41' 3" (12.6)
42' 9" (13.0)
44' 3" (13.5)
45' 9" (13.9)
47' 3" (14.4)
48' 9" (14.9)
53' 3" (16.3)
54' 9" (16.7)
59' 3" (18.0)
60' 9" (18.5)
Transport Width ft. in. (m)
18' 8" (5.7)
18' 8" (5.7)
18' 6" (5.6)
18' 6" (5.6)
21' 8" (6.6)
21' 8" (6.6)
18' 8" (5.7)
18' 8" (5.7)
21' 8" (6.6)
21' 8" (6.6)
18' 8" (5.7)
18' 8" (5.7)
21' 8" (6.6)
21' 8" (6.6)
21' 8" (6.6)
21' 8" (6.6)
21' 8" (6.6)
21' 8" (6.6)
Transport Height ft. in. (m)
12' 6" (3.8)
12' 6" (3.8)
15' 2" (4.6)
15' 2" (4.6)
15' 2" (4.6)
15' 2" (4.6)
17' 11" (5.5)
17' 11" (5.5)
17' 11" (5.5)
17' 11" (5.5)
13' 10" (4.2)
13' 10" (4.2)
13' 10" (4.2)
13' 10" (4.2)
16' 10" (5.1)
16' 10" (5.1)
16' 10" (5.1)
16' 10" (5.1)
Overall Length ft. in. (m)
25' 4" (7.7)
25' 4" (7.7)
25' 4" (7.7)
25' 4" (7.7)
26' 2" (8.0)
26' 2" (8.0)
25' 4" (7.7)
25' 4" (7.7)
26' 2" (8.0)
26' 2" (8.0)
26' 2" (8.0)
24' 4" (7.4)
26' 2" (8.0)
26' 2" (8.0)
26' 2" (8.0)
26' 2" (8.0)
26' 2" (8.0)
26' 2" (8.0)
Total Weight † lb. (kg)
11,648 (5283)
11,881 (5389)
12,913 (5857)
13,177 (5977)
13,567 (6154)
13,831 (6274)
14,782 (6705)
15,046 (6825)
15,478 (7021)
15,742 (7141)
18,351 (8324)
18,584 (8430)
19,096 (8662)
19,329 (8768)
20,874 (9468)
21,107 (9574)
22,222 (10 080)
22,486 (10 200)
Center Frame Width ft. (m)
13' (3.96)
13' (3.96)
13' (3.96)
13' (3.96)
16' (4.88)
16' (4.88)
13' (3.96)
13' (3.96)
16' (4.88)
16' (4.88)
13' (3.96)
13' (3.96)
16' (4.88)
16' (4.88)
16' (4.88)
16' (4.88)
16' (4.88)
16' (4.88)
Inner Wing Width ft. (m)
9' (2.74)
9' (2.74)
9' (2.74)
9' (2.74)
12' (3.66)
12' (3.66)
12' (3.66)
12' (3.66)
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
Outer Wing Width - ft. (m)
6' (1.83)
6' (1.83)
9' (2.74)
9' (2.74)
9' (2.74)
9' (2.74)
12' (3.66)
12' (3.66)
12' (3.66)
12' (3.66)
6' (1.83)
6' (1.83)
6' (1.83)
6' (1.83)
6' (1.83)
6' (1.83)
9' (2.74)
9' (2.74)
*Dimensions include 12 in. (305 mm) sweeps on 9 in. (229 mm) shank spacing. † Weights based on 550 lb. (250 kg) trips and do not include ground engaging tools or harrows.
12 IN. (305 MM) SPACING** NUMBER OF SHANKS 27
29
33
35
36
38
39
41
42
44
45
47
48
50
54
56
60
62
3-SECTION MODELS
5-SECTION MODELS
Working Width ft. in. (m)
27' 0" (8.2)
29' 0" (8.8)
33' 0" (10.1)
35' 0" (10.7)
36' 0" (11.6)
38' 0" (11.6)
39' 0" (11.9)
41' 0" (12.5)
42' 0" (12.8)
44' 0" (13.4)
45' 0" (13.7)
47' 0" (14.3)
48' 0" (14.6)
50' 0" (15.2)
54' 0" (16.5)
56' 0" (17.1)
60' 0" (18.3)
62' 0" (18.5)
Transport Width ft. in. (m)
18' 8" (5.7)
18' 8" (5.7)
18' 6" (5.6)
18' 6" (5.6)
21' 8" (6.6)
21' 8" (6.6)
18' 8" (5.7)
18' 8" (5.7)
21' 8" (6.6)
21' 8" (6.6)
18' 8" (5.7)
18' 8" (5.7)
21' 8" (6.6)
21' 8" (6.6)
21' 8" (6.6)
21' 8" (6.6)
21' 8" (6.6)
21' 8" (6.6)
Transport Height ft. in. (m)
12' 6" (3.8)
12' 6" (3.8)
15' 2" (4.6)
15' 2" (4.6)
15' 2" (4.6)
15' 2" (4.6)
17' 11" (5.5)
17' 11" (5.5)
17' 11" (5.5)
17' 11" (5.5)
13' 10" (4.2)
13' 10" (4.2)
13' 10" (4.2)
13' 10" (4.2)
16' 10" (5.1)
16' 10" (5.1)
16' 10" (5.1)
16' 10" (5.1)
Overall Length ft. in. (m)
25' 4" (7.7)
25' 4" (7.7)
25' 4" (7.7)
25' 4" (7.7)
26' 2" (8.0)
26' 2" (8.0)
25' 4" (7.7)
25' 4" (7.7)
26' 2" (8.0)
26' 2" (8.0)
26' 2" (8.0)
24' 4" (7.4)
26' 2" (8.0)
26' 2" (8.0)
26' 2" (8.0)
26' 2" (8.0)
26' 2" (8.0)
26' 2" (8.0)
Total Weight ‡ lb. (kg)
11,145 (5055)
11,417 (5179)
12,400 (5625)
12,686 (5754)
13,002 (5898)
13,288 (6027)
14,037 (6367)
14,323 (6497)
14,682 (6660)
14,967 (6789)
17,443 (7912)
17,715 (8035)
18,136 (8226)
18,408 (8350)
19,669 (8922)
19,941 (9045)
21,007 (9529)
21,293 (9658)
Center Frame Width ft. (m)
13' (3.96)
13' (3.96)
13' (3.96)
13' (3.96)
16' (4.88)
16' (4.88)
13' (3.96)
13' (3.96)
16' (4.88)
16' (4.88)
13' (3.96)
13' (3.96)
16' (4.88)
16' (4.88)
16' (4.88)
16' (4.88)
16' (4.88)
16' (4.88)
Inner Wing Width ft. (m)
9' (2.74)
9' (2.74)
9' (2.74)
9' (2.74)
12' (3.66)
12' (3.66)
12' (3.66)
12' (3.66)
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
Outer Wing Width ft. (m)
6' (1.83)
6' (1.83)
9' (2.74)
9' (2.74)
9' (2.74)
9' (2.74)
12' (3.66)
12' (3.66)
12' (3.66)
12' (3.66)
6' (1.83)
6' (1.83)
6' (1.83)
6' (1.83)
6' (1.83)
6' (1.83)
9' (2.74)
9' (2.74)
**Dimensions include 16 in. (410 mm) sweeps on 12 in. (305 mm) shank spacing. ‡ Weights based on 650 lb. (295 kg) trips and do not include ground engaging tools or harrows.
