POWER: 89 KWH BATTERY RANGE: ~140 MILES BATTERY TYPE: LITHIUM-ION BATTERY FORD Pro E-TRANSIT INFORMATION
CHARGING SUPPORT: CCS TYPE 1 (AC/DCFC) SEATING CAPACITY: 10 INCLUDING ATTENDANT ADA: BRAUNABILITY LIFT (800LBS) SENSING AND PERCEPTION: LIDAR, CAMERA VISION, AND RADAR LIDAR: 4 RADAR: 7 CAMERAS: 10 GNSS: 2 REAL-TIME KINEMATIC (RTK), 3 ANTENNAS GLOBAL NAVIGATION SATELLITE SYSTEM FEDERAL MOTOR VEHICLE SAFETY STANDARDS (FMVSS) COMPLIANT BUY AMERICA COMPLIANT MAX SPEED IN AUTO: 35 MPH MANUAL: ~90 MPH ONBOARD USB CHARGING FOR CUSTOMERS
2
Oxa E-Transit Sensor Layout
MAINTENANCE BAY
Radar
Oxa E-Transit Sensor Layout
Surround Cameras
Oxa E-Transit Sensor Layout
Primary Cameras
Radar
Lidar GPS
Surround Cameras
Primary Cameras
Lidar GPS
Accessibility Features
3
CHARGING STATION
The AIC facility has 12 Level 2 EV chargers, each with the capacity for 19 kW of power. These will be used during normal operations to charge the AVs overnight in approximately 6-8 hours. There are two Level 2 chargers in the maintenance bays which are capable of providing 9 kW of power that will be used to charge vehicles during maintenance operations. The Level 3 DC Fast Charger in the parking lot is capable of providing 120 kW of power to one vehicle or 60 kW of power to two vehicles simultaneously and will be used when fast charging is required to supplement the Level 2 charging. The Level 3 charger can fully charge a vehicle in approximately 30 minutes.
