POWER KITS FOR LOCKER SYSTEMS From mobile office workers and healthcare staff, to factory employees and students, you don’t need a dedicated desk to be productive. But you do need a place to park your stuff. And a place to safely plug in. That’s locker power. With different mounting options for metal or wood construction and multiple pack sizes to choose from, Byrne’s Power Kits For Locker Systems make it a cinch to deliver charging right where it’s needed while tech stays secure. UL Listed and corded, our powerful kits can configure up to 20 cubbies – all with just one outlet needed! Power the way we actually work today with Locker Power Kits from Byrne.
©2022 Confidential Byrne Electrical Specialists
byrne.com | 1.800.999.3567
Power Kits For Locker Systems
V0523
Page 1 of 6
SYSTEM FEATURES
EACH KIT INCLUDES
• 120”, 15 Amp Corded, Plug & Play Infeed • Modular connections distribute power from one locker to the next • Preconfigured solutions for Tall, Medium and Cubby sized storage • Available in standard kits for 4, 6, 8 and 20 pack layout • Choose between under mounted power and charging USB (Miki) or in-surface installed Snap In Duplex • Grommets for metal or composite cutouts included
• Corded Infeed • Jumpers • Distribution Blocks • Power Accesssory (Miki or Snap In Duplex) • Grommets and Cord Management
*Exact Kit Solution depends on Locker Size and Layout Selected
POWER ENTRY
CODES
ETL LISTED
NEW YORK Pattern can be used in the New York City, per the official NYC Electrical Code. CHICAGO Pattern can be used on Listed freestanding furnishings in Chicago. Limitations apply.
V0523
Page 2 of 6
TALL LOCKERS
Component specifications on Page 6.
TALL 4-PACK
Metal Part Numbers
Wood Part Numbers
Miki - 1 Power, 1 USB-A+C
Miki - 1 Power, 1 USB-A+C
Black - BE06523-0000760 White - BE06523-0000766
Black - BE06523-0000772 White - BE06523-0000778
Snap In Duplex - 2 Power
Black - BE06523-0000784
(1) 120” Power Infeed (2) Gray Distribution Blocks with Mounts (4) Accessories with 72” cord (60” Snap In Duplex) (1) 12” Jumper Cable (12) Cord Management Clips (4) Grommets/Rubber Rings (Miki Only)
TALL 6-PACK
Metal Part Numbers
Wood Part Numbers
Miki - 1 Power, 1 USB-A+C
Miki - 1 Power, 1 USB-A+C
Black - BE06523-0000761 White - BE06523-0000767
Black - BE06523-0000773 White - BE06523-0000779
Snap In Duplex - 2 Power
Black - BE06523-0000785
(1) 120” Power Infeed (3) Gray Distribution Blocks with Mounts (6) Accessories with 72” cord (60” Snap In Duplex) (2) 12” Jumper Cables (18) Cord Management Clips (6) Grommets/Rubber Rings (Miki Only)
V0523
Page 3 of 6
MEDIUM LOCKERS
Component specifications on Page 6.
MEDIUM 4-PACK
Metal Part Numbers
Wood Part Numbers
Miki - 1 Power, 1 USB-A+C
Miki - 1 Power, 1 USB-A+C
Black - BE06523-0000762 White - BE06523-0000768
Black - BE06523-0000774 White - BE06523-0000780
Snap In Duplex - 2 Power
Black - BE06523-0000786
(1) 120” Power Infeed (2) Gray Distribution Blocks with Mounts (4) Accessories with 48” cord (36” Snap In Duplex) (1) 12” Jumper Cable (12) Cord Management Clips (4) Grommets/Rubber Rings (Miki Only)
MEDIUM 6-PACK
Metal Part Numbers
Wood Part Numbers
Miki - 1 Power, 1 USB-A+C
Miki - 1 Power, 1 USB-A+C
Black - BE06523-0000763 White - BE06523-0000769
Black - BE06523-0000775 White - BE06523-0000781
Snap In Duplex - 2 Power
Black - BE06523-0000787
(1) 120” Power Infeed (3) Gray Distribution Blocks with Mounts (6) Accessories with 48” cord (36” Snap In Duplex) (2) 12” Jumper Cables (18) Cord Management Clips (6) Grommets/Rubber Rings (Miki Only)
V0523
Page 4 of 6
*Accessory and Jumper cord length are determined by the table size.
CUBBY LOCKERS
Component specifications on Page 6.
CUBBY 8-PACK
Metal Part Numbers
Wood Part Numbers
Miki - 1 Power, 1 USB-A+C
Miki - 1 Power, 1 USB-A+C
Black - BE06523-0000764 White - BE06523-0000770
Black - BE06523-0000776 White - BE06523-0000782
Snap In Duplex - 2 Power
Black - BE06523-0000788
(1) 120” Power Infeed (4) Gray Distribution Blocks with Mounts (8) Accessories with 24” cord (12” Snap In Duplex)
(1) 12” Jumper Cable (2) 24” Jumper Cable (12) Cord Management Clips (8) Grommets/Rubber Rings (Miki Only)
CUBBY 20-PACK
Metal Part Numbers
Wood Part Numbers
Miki - 1 Power, 1 USB-A+C
Miki - 1 Power, 1 USB-A+C
Black - BE06523-0000765 White - BE06523-0000771
Black - BE06523-0000777 White - BE06523-0000783
Snap In Duplex - 2 Power
Black - BE06523-0000789
(1) 120” Power Infeed (10) Gray Distribution Blocks with Mounts (20) Accessories with 24” cord (12” Snap In Duplex)
(4) 12” Jumper Cable (5) 24” Jumper Cable (60) Cord Management Clips (20) Grommets/Rubber Rings (Miki Only)
V0523
Page 5 of 6
*Accessory and Jumper cord length are determined by the table size.
LOCKER POWER SPECIFICATIONS
INFEED
WOOD DISTRIBUTION BLOCK
72”
2-15/16”
2-13/16”
1-7/8”
JUMPER
1-11/16”
2-13/16”
2-13/16”
1-1/2”
Length varies per kit
ACCESSORY CORD (POWER UNIT)
METAL DISTRIBUTION BLOCK
1-1/2”
2-13/16”
Length varies per kit
1-11/16”
ACCESSORIES
MIKI LOCKER MOUNT
SNAP IN DUPLEX
METAL GROMMET
2-11/16”
1-3/8”
3-13/16”
1-9/16”
2-1/8”
3-1/4”
2-5/16”
3-1/8”
1-1/2”
1-3/4”
WOOD GROMMET
4-1/2”
2-1/8”
2-3/8”
9/16”
3”
1-3/4”
3”
