® A Gorman-Rupp Company Self-Priming Sprinkler/Booster Pumps
Pump Dimensional & Specification Data
Voltage @ 60 Hz + SUC* DIS*
Ship Wt. (Lbs.)
Model
Curve HP PH ENC
A
B
C
D
E
F
G
J
K
L**
W**
H
3790-95 A 3/4 1 ODP 115/230 1½ 1½ 2.2 [5.5] 2.1 [5.3] 2.9 [7.3] 4.4 [11.1] 4.7 [11.9] 3.1 [7.8] 6.2 [15.7] 0.5 [1.2] 0.7 [1.7] 18.1 [46.0] 8.0 [20.3] 9.1 [23.1] 66 379A-95 1 1 TEFC 115/230 1½ 1½ 2.2 [5.5] 2.1 [5.3] 2.9 [7.3] 4.4 [11.1] 4.7 [11.9] 3.1 [7.8] 6.2 [15.7] 0.5 [1.2] 0.7 [1.7] 18.6 [47.2] 9.3 [23.6] 9.1 [23.1] 67 379F-95 1 3 TEFC 230/460 1½ 1½ 2.2 [5.5] 2.1 [5.3] 2.9 [7.3] 4.4 [11.1] 4.7 [11.9] 3.1 [7.8] 6.2 [15.7] 0.5 [1.2] 0.7 [1.7] 17.1 [43.4] 9.3 [23.6] 9.1 [23.1] 63 3791-95 B 1 1 ODP 115/230 1½ 1½ 2.2 [5.5] 2.1 [5.3] 2.9 [7.3] 4.4 [11.1] 4.7 [11.9] 3.1 [7.8] 6.2 [15.7] 0.5 [1.2] 0.7 [1.7] 18.3 [46.4] 8.0 [20.3] 9.1 [23.1] 70 379B-95 1½ 1 TEFC 115/230 1½ 1½ 2.2 [5.5] 2.1 [5.3] 2.9 [7.3] 4.4 [11.1] 4.7 [11.9] 3.1 [7.8] 6.2 [15.7] 0.5 [1.2] 0.7 [1.7] 19.1 [48.5] 9.3 [23.6] 9.1 [23.1] 77 379J-95 1½ 3 TEFC 230/460 1½ 1½ 2.2 [5.5] 2.1 [5.3] 2.9 [7.3] 4.4 [11.1] 4.7 [11.9] 3.1 [7.8] 6.2 [15.7] 0.5 [1.2] 0.7 [1.7] 18.8 [47.7] 9.3 [23.6] 9.1 [23.1] 72 3792-95 C 1½ 1 ODP 115/230 1½ 1½ 2.2 [5.5] 2.1 [5.3] 2.9 [7.3] 4.4 [11.1] 4.7 [11.9] 3.1 [7.8] 6.2 [15.7] 0.5 [1.2] 0.7 [1.7] 18.8 [47.7] 8.0 [20.3] 9.1 [23.1] 70 379C-95 2 1 TEFC 115/230 1½ 1½ 2.2 [5.5] 2.1 [5.3] 2.9 [7.3] 4.4 [11.1] 4.7 [11.9] 3.1 [7.8] 6.2 [15.7] 0.5 [1.2] 0.7 [1.7] 19.8 [50.3] 9.3 [23.6] 9.1 [23.1] 79 379E-95 2 3 TEFC 230/460 1½ 1½ 2.2 [5.5] 2.1 [5.3] 2.9 [7.3] 4.4 [11.1] 4.7 [11.9] 3.1 [7.8] 6.2 [15.7] 0.5 [1.2] 0.7 [1.7] 19.3 [49.0] 9.3 [23.6] 9.1 [23.1] 71 3793-95 D 2 1 ODP 115/230 1½ 1½ 2.2 [5.5] 2.1 [5.3] 2.9 [7.3] 4.4 [11.1] 4.7 [11.9] 3.1 [7.8] 6.2 [15.7] 0.5 [1.2] 0.7 [1.7] 18.8 [47.7] 8.0 [20.3] 9.1 [23.1] 79 379D-95 3 1 TEFC 230 1½ 1½ 2.2 [5.5] 2.1 [5.3] 2.9 [7.3] 4.4 [11.1] 4.7 [11.9] 3.1 [7.8] 6.2 [15.7] 0.5 [1.2] 0.7 [1.7] 20.3 [51.5] 9.3 [23.6] 9.1 [23.1] 87 379L-95 3 3 TEFC 230/460 1½ 1½ 2.2 [5.5] 2.1 [5.3] 2.9 [7.3] 4.4 [11.1] 4.7 [11.9] 3.1 [7.8] 6.2 [15.7] 0.5 [1.2] 0.7 [1.7] 19.8 [50.3] 9.3 [23.6] 9.1 [23.1] 76 3657-95 E 5 1 TEFC 230 2 2 3.7 [9.4] 2.1 [5.3] 5.5 [13.9] 4.5 [11.4] 4.7 [11.9] 3.1 [7.8] 15.9 [40.3] 0.4 [1.0] 0.4 [1.0] 27.4 [69.6] 13.4 [34.0] 10.0 [25.4] 165 3655-95 5 3 TEFC 230/460 2 2 3.7 [9.4] 2.1 [5.3] 5.5 [13.9] 4.5 [11.4] 4.7 [11.9] 3.1 [7.8] 15.9 [40.3] 0.4 [1.0] 0.4 [1.0] 25.0 [63.5] 12.3 [31.2] 10.0 [25.4] 157 3656-95 F 7½ 3 TEFC 230/460 2 2 3.7 [9.4] 2.1 [5.3] 5.5 [13.9] 5.2 [13.2] 4.7 [11.9] 3.1 [7.8] 15.9 [40.3] 0.4 [1.0] 0.7 [1.7] 25.0 [63.5] 12.3 [31.2] 10.0 [25.4] 160 4782-95 G 3 1 ODP 115/230 1½ 1½ 2.2 [5.5] 2.1 [5.3] 2.9 [7.3] 4.4 [11.1] 4.7 [11.9] 3.1 [7.8] 6.6 [16.7] 0.5 [1.2] 0.7 [1.7] 19.7 [50.0] 8.0 [20.3] 9.1 [23.1] 91 4786-95 3 3 TEFC 230/460 1½ 1½ 2.2 [5.5] 2.1 [5.3] 2.9 [7.3] 4.4 [11.1] 4.7 [11.9] 3.1 [7.8] 6.6 [16.7] 0.5 [1.2] 0.7 [1.7] 19.9 [50.5] 8.0 [20.3] 9.1 [23.1] 86
(*) Standard NPT (Female) pipe thread. (**) This dimension may vary due to motor manufacturer’s speciifcations. (+) 3-Phase motors can also operate on 50 Hz. (this will change full load amps, service factor and RPM) NOTE: Dimensions are in inches (centimeters) and have a tolerance of ± 1/4”. NOTE: Electric supply for ALL motors must be within ± 10% of nameplate voltage rating (e.g 230V ± 10%=207 to 253)
Standard Features
• Cast Iron Construction with 300 Series Investment Cast Stainless Steel Impeller • Buna-N Mechanical Seal and O-ring • ODP & TEFC Motors Available on 1-1⁄2" NPT Single-stage Models
• Removable/Replaceable Volute/Diffuser • Maximum Solids:
• Maximum Working Pressure to 150 PSI • Maximum Temperature 180° F • Optional Mounting Base for Pumps with JM Motors (Model 365x Series) • QSP – Quick Ship Pump for Many Models
• 365X Series—5/16" • 379X Series—1/16" • 478X Series—1/16"
• Single Stage Models Feature Removable Dual Volute Design • Self-priming to 20 Feet
Manufacturer of AMT & IPT Pumps 400 Spring Street • Royersford, PA 19468 USA
®
www.amtpump.com • 888-amt-pump (268-7867) The Gorman-Rupp Company reserves the right to discontinue any model or change specifications at any time without incurring any obligation. ©2012 American Machine and Tool Company. All rights reserved.
A Gorman-Rupp Company
0522
SPE-20
