Woodson Family Brochure
SINCE 1954
Woodson is Stoddart’s countertop kitchen and café equipment range that has led the market space since 1954. Designed and manufactured in Australia for Australian conditions, Woodson is renowned for its quality, functionality, and reliability. Woodson’s extensive line up offers a sleek and modern aesthetic that includes fryers, contact toasters and grillers, conveyor ovens, food displays, bain maries and more. The versatile range offers profiles that suit every application from front of house to back of house kitchens. Proudly producing Australian made products every day in our Brisbane factory, Woodson has been a reliable staple in numerous commercial kitchens around the world for over 60 years. With continuous improvement as the focus, Stoddart’s team of highly qualified engineers are consistently revolutionising the design and technology, ensuring Woodson maintains its position within the marketplace as it rapidly evolves.
ONSITE WARRANTY
2.
04
Countertop Fryers / Chip Dumps
06
Contact Grills
08
Griddles / Griddle Toasters
10
Griller's / Salamanders
12
Conveyor Toasters
14
Snackmaster / Pizza Conveyor Ovens
16
Ductless Filter Hoods
18
Countertop Bain Maries
20
Large Bain Maries
22
Pie / Food Displays
24
Hot Food Displays / Straight Glass
26
Hot Food Displays / Square Glass
Cold Food Displays / Straight Glass
28
Cold Food Displays / Square Glass
30
Induction Cook Tops
32
34
Urns
36
Accessories
3.
Countertop Fryers & Chip Dumps
Woodson countertop fryers offer a versatile line up that will fit seamlessly into any new or existing kitchen or café. All units are equipped with a splash guard and lid, drip tray, basket(s) and element cover to help prevent accidental knocking.
The FRS and FRT models offer a mechanical thermostat temperature control that is designed for 180°C frying and temperature safety cut-out as standard. Both units are supplied with an easily removable oil tank.
The autolift fryers (FAS and FRSA) feature a digital timer controlled basket lifter (1-999 seconds), providing a convenient and efficient work environment.
The bench mounted chip dumps are the perfect addition to the Woodson countertop fryers. Supplied with two heat lamps, single heater pad underneath (W.CD.B.P.11 only) and 1 x 1/1GN 100mm deep pan and perforated slide for easy scooping. These units will ensure chips stay crisper for longer.
W.FRS50 5 Litre Pan
W.FRT50
W.FAS80
550 x 483 x 335 2 x 5 Litre Pans
Autolift Fryer - 8 Litre Pan
285 x 483 x 335
285 x 530 x 431
2 x 2.2kW 2 x 10A plug & lead fitted 10kg of frozen 10mm chips per/hr
5kg of frozen 10mm chips per/hr
11.5kg of frozen 10mm chips per/hr
2.2kW 10A plug & lead fitted
2.9kW 15A plug & lead fitted
W.FRS80 8 Litre Pan
W.FRT80
W.FRSA110
550 x 483 x 384 2 x 8 Litre Pans
Autolift Fryer - 11 Litre Pan
285 x 483 x 384
272 x 666 x 456
11.5kg of frozen 10mm chips per/hr
2 x 3.2kW 2 x 15A plug & lead fitted 23kg of frozen 10mm chips per/hr
15kg of frozen 10mm chips per/hr
3.2kW 15A plug & lead fitted
4.8kW 20A plug & lead fitted
W.CD.B.11
W.CD.B.P.11
405 x 619 x 636 1.0kW 10A plug & lead fitted 1 x 1/1GN 100mm Deep Pan
600 x 390 x 664 1.0kW 10A plug & lead fitted Pass-Through - 1 x 1/1GN 100mm Deep Pan
ONSITE WARRANTY
4.
5.
Contact Grills
Australian made Woodson contact grills offer five different sized units. CT models offer a spring balanced upper plate, limiting the chance of crushing product, smooth finished aluminium plates with the option of a ribbed top plate if required.
The CT and GPC350 models have a thermostat control of 50°C – 250°C.
For a more controlled cooking operation, Woodson offer a range of computer-controlled contact grills. All inclusive, with an LED timer display, eight programmable settings and three operation modes for convenience and flexibility. A concealed adjustable thermostat control with preset of 210°C and gas strut assisted top plate with optional non-stick teflon matting, these units make for a reliable and easy cooking experience.
W.CT6
W.CT8
W.GPC350
415 x 518 x 231 2.2kW 10A plug & lead fitted 4-6 Slice Capacity
495 x 473 x 231 2.2kW 2 x 10A plug & lead fitted 6-8 Slice Capacity W.CT8R 495 x 473 x 231 2.2kW 10A plug & lead fitted Ribbed Top Plate
412 x 628 x 331 2.2kW 10A plug & lead fitted Stainless Steel Plates
W.CT6R
415 x 518 x 231 2.2kW 10A plug & lead fitted Ribbed Top Plate
W.GPC62SC
W.GPC61SC
W.GPC61SC.R.A
Computer Controlled - 2 Top Stainless Steel Plates
Computer Controlled - Stainless Steel Plates
Computer Controlled - Anodised Ribbed Top Plate - Stainless Steel Bottom Plate
474 x 578 x 331 2.2kW 10A plug & lead fitted
362 x 578 x 331 2.2kW 10A plug & lead fitted
362 x 578 x 331 2.2kW 10A plug & lead fitted
ONSITE WARRANTY
6.
7.
Griddles & Griddle Toasters
Woodson countertop griddles have been designed with an integrated splashback, front grease gutter that drains to a large removable grease drawer and a thermostat control of 80°C - 280°C. With two different sizes and three different power capabilities, this range will be the perfect addition for all desired applications. The griddle toasters are an efficient, space saving solution to any line-up. Equipped with a combination countertop griddle and toaster underneath, toasting rack with adjustable height settings, integrated splashback, independent top and bottom controls and a thermostat control of 80°C - 280°C.
W.GDA50.10
W.GDA50.15
W.GDA60
525 x 474 x 230 2.2kW 10A plug & lead fitted 8mm thick steel Griddle Plate
525 x 474 x 230 3.2kW 15A plug & lead fitted 8mm thick steel Griddle Plate
672 x 621 x 230 4.4kW 20A plug & lead fitted 10.5mm thick steel Griddle Plate
W.GDT65.20
W.GDT65.15
W.GDT75
8mm thick steel Griddle Plate
8mm thick steel Griddle Plate
8mm thick steel Griddle Plate
540 x 417 x 338 6 slice capacity
540 x 417 x 338 6 slice capacity
687 x 564 x 338 8 slice capacity 6.6kW 30A lead only
3.3kW 15A plug & lead fitted
4.3kW 20A plug & lead fitted
ONSITE WARRANTY
8.
9.
Griller's & Salamanders
Experience fast and exceptionally even grilling and toasting with Woodson’s large range of griller's and salamander's. All are feature packed, with multiple position slides and rack for safer loading. Easy to clean removable crumb trays, stainless steel construction and the convenience of wall mounting brackets are ideal for small space applications.
Woodson griller's offer energy efficient ‘instant’ heat ceramic top coated glass infrared elements and timer-controlled operations.
The GTQI8 Supertoast model has variable top and bottom independent temperature controls with a timer bypass switch, providing extreme flexibility.
The GTSQI.15 salamander is equipped with energy efficient 'instant' heat glass infrared top elements and two operation modes - timer or simple "in is on" mode, this function uses a rack activated toggle switch that allows all power to the top elements only.
W.GTQI4.CUB
W.GTQI15
W.GTQI8.10
412 x 339 x 363 2.2kW 10A plug & lead fitted 4 Slice Capacity Griller
673 x 429 x 363 3.3kW 15A plug & lead fitted 15 Slice Capacity Griller
563 x 339 x 363 2.2kW 10A plug & lead fitted 8 Slice Capacity Griller
W.GTQI8.15
563 x 339 x 363 3.3kW 15A plug & lead fitted 8 Slice Capacity Griller
W.GTSQI15
15 Slice Capacity Salamander
673 x 429 x 372
3.3kW 15A plug & lead fitted 1/1GN pan compatible
ONSITE WARRANTY
10.
11.
Conveyor Toasters
Woodson CVT.D conveyor toasters have been engineered with long life metal elements for continuous use. With the ability to operate as either a front or rear exiting unit with variable speed belt control and tamper proof cover for speed controller. These units provide an ideal solution for toasting sliced bread and are perfect for buffet style kitchens. The CVT.BUN conveyor ovens are ideal for hamburger buns. Each unit has front loading and front exiting capabilities with an efficient touchpad “set and forget” control system. A variable speed belt control and top and bottom independent temperature controls are all packed in a compact, stainless-steel footprint. These units provide an efficient and even cooking process.
W.CVT.D.10
W.CVT.BUN.25 510 x 570 x 485 6kW 25A lead only 250 buns per/hr*
W.CVT.BUN.30 630 x 908 x 485 7.2kW 30A lead only 420 buns per/hr*
379 x 502 x 446 2.1 kW 10A plug & lead fitted 300 slices per/hr*
W.CVT.D.15
379 x 502 x 446 3.3kW 15A plug & lead fitted 500 slices per/hr*
*Variation may occur due to bread types
ONSITE WARRANTY
12.
13.
Snackmaster & Pizza Conveyor Ovens
Ideal for toasting and cooking open snacks, pizza’s and a variety of other foods, the Woodson Snackmaster and pizza conveyor series have been specifically engineered with long life metal elements ensuring durability for continuous use. Featuring a long inlet conveyor for easy loading and high production, fan cooled dial controls and heat technology. Woodson conveyor ovens are fully insulated top and body to retain heat and variable speed belt control with automatic tensioning. The CVS.S model offers independent temperature controls for top and bottom elements. The CVS.SE, CVS.M, CVS.L and CVP.C models incorporate an efficient touchpad “set and forget” control system paired with energy efficient pulse power independent temperature controls for top and bottom elements.
Enjoy the efficiency and flexibility of the range with the optional stacking kits (excluding CVS.S.15) and mobile trolleys for the CVP.C.18 and CVP.C.24 conveyor ovens.
W.CVS.SE.20 305mm belt width 1000 x 445 x 465
W.CVS.S.15
W.CVS.M.25 356mm belt width 1200 x 505 x 465 12 x 12" pizzas per/hr*
1000 x 445 x 465 3.6kW 15A plug & lead fitted 305mm belt width
4.8kW 20A plug & lead fitted 10 x 12" pizzas per/hr*
6.0kW 25A lead only
W.CVP.C.18
W.CVS.L.30
W.CVP.C.24
1500 x 610 x 440 457mm belt width
1200 x 610 x 465 450mm belt width 15 x 12" pizzas per/hr*
1500 x 765 x 440 610mm belt width
10.8kW 3Ø + N + E - lead only 20 x 12" pizzas per/hr*
14.4kW 3Ø + N + E - lead only 25 x 12" pizzas per/hr*
7.2kW 30A lead only
*Variation may occur depending on type of pizza base and topping.
ONSITE WARRANTY
14.
15.
Ductless Filter Hoods The unique Woodson ductless filter hoods are available in both mobile and countertop footprints. Ideal for kiosk operations or where a ducted system is impractical or uneconomical. Engineered with a unique ductless design, using a three-way filtering system, this includes a stainless-steel baffle to remove larger oil particles, a polyester filter to remove finer oil particles and activated carbon filters to provide a clean, safe and odour-controlled environment. The easily removable filters are ideal for cleaning (except carbon filter). These units are designed for use with countertop electrical cooking appliances that do not exceed limits defined in the NCC (NCC- 2019 Part F4.12) ie: - The total maximum electrical power input of the cooking apparatus does not exceed 8kW; or - The total maximum power input of more than one apparatus does not exceed 0.5kW electrical power per m 2 of the floor area of the room or enclosure
Mobile units come supplied with a storage area below the cooking zone, adaptable rack slides and lockable swivel castors to front and fixed castors on the rear for extra mobility.
The countertop unit features fluorescent lighting and a variable speed fan for efficiency and ease of use.
W.MVS
W.MVS850
700 x 775 x 1200 0.48kW 10A plug & lead fitted 700mm wide unit
850 x 800 x 1200 0.48kW 10A plug & lead fitted 850mm wide unit
W.CHD1000 1000 x 660 x 1150 1.0kW 10A plug & lead fitted 1000 wide unit
W.CHD750
750 x 660 x 1150 0.5kW 10A plug & lead fitted 750mm wide unit
ONSITE WARRANTY
16.
17.
Countertop Bain Maries
Available in 1/1GN and 2/1GN sizes, all units fit gastronorm pans up to 150mm deep in a specifically engineered air insulated water tank with double skinned stainless-steel construction for durability.
The countertop bain maires are designed and recommended for wet operation, operating between 70°C – 80°C with a mechanical thermostat control and temperature gauge.
W.BML21
W.BMS11
706 x 645 x 282 1.5kW 10A plug & lead fitted 2/1GN size bain marie
371 x 645 x 282 0.75kW 10A plug & lead fitted 1/1GN size bain marie
ONSITE WARRANTY
18.
19.
Large Bain Maries
The large bain maries offer six footprints, two, three, four, five and six bay 1/1GN and 2/1GN units, all designed and recommended for wet operation. Offering an air insulated water tank with double skin stainless steel construction, with multiple element design for ongoing operation and even temperature control. Mechanical thermostat temperature control between 70°C – 80°C and in-tank temperature probes allows for accurate measurement and lower running costs. With extreme versatility in countertop and drop in installation options, these units make for the perfect addition to any new or existing kitchens.
W.BMA23
W.BMA24
W.BMA22
1030 x 669 x 237 1.8kW 10A plug & lead fitted 2 Rows, 3 Bays
1355 x 669 x 237 2.4kW 10A plug & lead fitted 2 Rows, 4 Bays
705 x 669 x 237 1.2kW 10A plug & lead fitted 2 Rows, 2 Bays
W.BMA25
W.BMA26
2005 x 669 x 237 2.4kW 10A plug & lead fitted 2 Rows, 6 Bays
1680 x 669 x 237 2.4kW 10A plug & lead fitted 2 Rows, 5 Bays
ONSITE WARRANTY
20.
21.
Pie & Food Displays
The Woodson pie and food displays are designed to hold product between 70°C – 80°C with a mechanical thermostat control and temperature gauge, allowing products to stay fresher for longer. Removable wire racks and crumb trays make for easy and efficient cleaning. Available in four different sizes and six variations, Woodson provides the perfect display for any space.
The PIA series offer toughened glass front panels with toughened glass sliding rear doors and a double skinned stainless steel cabinet.
The PIP pro series suits 16” & 18” size baker trays with eight adjustable shelves for flexibility. The internal heat resistant high impact oven lighting provides outstanding illumination paired with a humidity tray to keep products looking fresh. Available in various combinations of doors and panels to suit all desired requirements. The PIM series comes standard with a modern black powder coated steel construction and toughened glass sliding door to front and back. Offering the perfect combination of functionality and attractive appeal with it's angled display racks, lightbox for branding, full internal lighting to improve the display and separate illuminated power and light switches.
W.PIA100 / W.PIA100G
W.PIP200
W.PIA50 / W.PIA50G
755 x 350 x 637 1.25kW 10A plug & lead fitted 100 Pie Capacity
871 x 531 x 912 2.03kW 10A plug & lead fitted 200 Pie Capacity
591 x 350 x 487 1.25kW 10A plug & lead fitted 50 Pie Capacity
G models are supplied with glass sliding doors on both sides. *
ONSITE WARRANTY
22.
23.
Hot Food Displays - Straight Glass
The straight glass profile hot food display’s offer an air insulated tank, double skin stainless steel construction and rear sliding doors on rollers for convenience. Available in two to six module sizes, each model has an in-tank temperature probe for accurate measurement and lower running costs. Multiple element design and mechanical thermostat control provides reliable and even heating between 70°C – 80°C. Designed with a rectangular base to easily drop into a bench cut-out, these units have been engineered to suit a range of desired applications.
Available accessories include pan kits, tray race, cutting boards, sneeze guards, trolleys, trolley panel kits and drop in kits.
W.HFS23
W.HFS24
W.HFS22
1030 x 600 x 722 2.4kW 10A plug & lead fitted 2 Rows, 3 Bays
1355 x 600 x 722 3.0kW 15A plug & lead fitted 2 Rows, 4 Bays
705 x 600 x 722 1.5kW 10A plug & lead fitted 2 Rows, 2 Bays
W.HFS26
W.HFS25
2005 x 600 x 722 3.6kW 15A plug & lead fitted 2 Rows, 6 Bays
1680 x 600 x 722 3.3kW 15A plug & lead fitted 2 Rows, 5 Bays
ONSITE WARRANTY
24.
25.
Hot Food Displays - Square Glass
Just like the straight and curved glass hot food displays, the square profile display offers two to six sized modules. With the modern square design, these units are guaranteed to create a sleek line-up whether that be countertop, drop in or mobile applications. Constructed of double skin stainless steel, an air insulated tank, rear sliding doors on rollers as well as improved infra-red heat lamps providing optimum heat and light throughout the display. Operating at 70°C-80°C with a mechanical thermostat control and multiple elements, these units are designed for wet operation.
Available accessories include pan kits, tray race, cutting boards, sneeze guards, trolleys, trolley panel kits and drop in kits.
W.HFSQ23
W.HFSQ24
W.HFSQ22
1030 x 600 x 696 2.4kW 10A plug & lead fitted 2 Rows, 3 Bays
1355 x 600 x 696 3.0kW 15A plug & lead fitted 2 Rows, 4 Bays
705 x 600 x 696 1.5kW 10A plug & lead fitted 2 Rows, 2 Bays
W.HFSQ25
W.HFSQ26
2005 x 600 x 696 3.6kW 15A plug & lead fitted 2 Rows, 6 Bays
1680 x 600 x 696 3.3kW 15A plug & lead fitted 2 Rows, 5 Bays
ONSITE WARRANTY
26.
27.
Cold Food Displays - Straight Glass
The straight glass cold food displays by Woodson offer exceptional display with LED lighting for an illuminated interior. Available in three to six module variations, each unit is equipped with an adjustable digital controller designed to hold temperature between 2°C-5°C and operates in ambient temperatures up to 32°C. Constructed from double glazed toughened glass to both front and sides, insulated tank with double skin stainless steel to improve performance and efficiency. Each unit is refrigerated by a 90mm deep cold plate well with cross fin coil over.
Available accessories include pan kits, tray race, cutting boards, sneeze guards, trolleys, trolley panel kits and drop in kits.
WR.CFS23
WR.CFS24
1030 x 608 x 690 0.6kW 10A plug & lead fitted 2 Rows, 3 Bays
1355 x 608 x 690 0.72kW 10A plug & lead fitted 2 Rows, 4 Bays
WR.CFS26
WR.CFS25
2005 x 608 x 690 0.84kW 10A plug & lead fitted 2 Rows, 6 Bays
1680 x 608 x 690 0.84kW 10A plug & lead fitted 2 Rows, 5 Bays
ONSITE WARRANTY
28.
29.
Cold Food Displays - Square Glass
The square glass profile, cold food display provides optimal product display with a modern look. Identical to the straight glass profile each unit is equipped with an adjustable digital controller designed to hold temperature between 2°C-5°C and operates in ambient temperatures up to 32°C. Constructed from double glazed toughened glass to both front and sides, insulated tank with double skin stainless steel to improve performance and efficiency. Each unit is refrigerated by a 90mm deep cold plate well with cross fin coil over. Also available in three to six modules, the square glass display will provide a seamless addition to any line-up.
Available accessories include pan kits, tray race, cutting boards, sneeze guards, trolleys, trolley panel kits and drop in kits.
WR.CFSQ23 1030 x 608 x 660 0.75kW 10A plug & lead fitted 2 Rows, 3 Bays
WR.CFSQ24 1355 x 608 x 660 0.75kW 10A plug & lead fitted 2 Rows, 4 Bays
WR.CFSQ26 2005 x 608 x 660 0.84kW 10A plug & lead fitted 2 Rows, 6 Bays
WR.CFSQ25 1680 x 608 x 660 0.84kW 10A plug & lead fitted 2 Rows, 5 Bays
ONSITE WARRANTY
30.
31.
Induction Cook Tops Woodson single hob models offer an energy efficient commercial cooktop with a high impact SCHOTT CERAN glass ceramic top. Minimising transferable heat around the unit allows for the heat to directly transmit to pots and pans, eliminating the risk of potential burns. Both cooktop’s and wok bowls are equipped with a clear LED display for power setting, temperature and time. The choice of precise power settings from 0-10 in single digit increments or temperature control from 60°C – 240°C and timer control from 1-180 minutes provides extreme flexibility to the user. Additional features include, audio alert after timed cooking, whereby unit transitions into standby mode, integral replaceable grease filters to ensure cleaner and cooler air intake and ducted twin integral cooling fans helping keep electronics cool during high demand.
WI.HBCT.1.2400 340 x 440 x 122 2.4kW 10A plug & lead fitted 2400w Single Hob
WI.HBCT.1.3500 340 x 440 x 122 3.5kW 15A plug & lead fitted 3500w Single Hob
WI.HBCT.1L.3500 440 x 540 x 122 3.5kW 15A plug & lead fitted 3500w Single Hob Large
Pan Size - Ø120mm x Ø260mm
Pan Size - Ø120mm x Ø260mm
Pan Size - Ø120mm x Ø360mm
WI.WKCT.1.3500.W
WI.WKPN
340 x 440 x 126 3.5kW 15A plug & lead fitted 3500w Induction Wok Bowl
360mm Diameter 14" Stainless steel induction compatible wok Wok Pan
Supplied with 14” induction Wok
ONSITE WARRANTY
32.
33.
Urns
Hot water urns by Woodson are available in both brushed stainless steel and matte black finishes as well as 10, 20 and 30 litre capacities. With quality stainless steel construction and double skinned insulated tank for increased safety, these units provide an efficient solution to any application. Feature packed with a sight glass to check water levels, heat resistant handles with a twist lock lid for added safety, thermostat control, indicator lights, concealed elements for ease of cleaning and a non-drip tap.
W.URN20
W.URN10
W.URN30
325 x 500 2.2kW 10A plug & lead fitted 20 Litre Capacity - Stainless Steel
235 x 475 2.2kW 10A plug & lead fitted 10 Litre Capacity - Stainless Steel
325 x 630 2.2kW 10A plug & lead fitted 30 Litre Capacity - Stainless Steel
W.URN10B
W.URN20B
W.URN30B
235 x 475 2.2kW 10A plug & lead fitted 10 Litre Capacity - Matte Black
325 x 500 2.2kW 10A plug & lead fitted 20 Litre Capacity - Matte Black
325 x 630 2.2kW 10A plug & lead fitted 30 Litre Capacity - Matte Black
ONSITE WARRANTY
34.
35.
36.
A large variety of accessories are available for the whole Woodson range:
• • • • • • • • • • •
Fryer baskets
• • • • • • • • • •
Stacking kits
Teflon clamping system and sheets
Pan kits
Wok pan GN pans
Pan support bars
Drop in kits
Cutting boards Sneeze guards
Pizza pans and trays
Non-stick aluminium pans and food pins Polyester and activated carbon filters
Trolleys
Panel kits
Hob covers
Drop down work shelves
Round steam pans
Tray races
Heat lamps
Chrome wire shelves
For more information on compatibility and specifications please visit www.stoddart.co.nz
37.
38.
39.
Brisbane
Sydney
Melbourne
Perth
Adelaide
1300 79 1954 www.stoddart.com.au
Auckland
0800 79 1954 www.stoddart.co.nz
Manufactured or Imported & distributed exclusively by:
Page 1 Page 2 Page 3 Page 4 Page 5 Page 6 Page 7 Page 8 Page 9 Page 10 Page 11 Page 12 Page 13 Page 14 Page 15 Page 16 Page 17 Page 18 Page 19 Page 20 Page 21 Page 22 Page 23 Page 24 Page 25 Page 26 Page 27 Page 28 Page 29 Page 30 Page 31 Page 32 Page 33 Page 34 Page 35 Page 36 Page 37 Page 38 Page 39 Page 40Made with FlippingBook - Online Brochure Maker
