GES Biotek - Enhanced Cell-Max™ microbiological odor-control solution for Bio-Scrubbers® and Biofilters - spec sheet
Enhanced Cell-Max ™ Microbiological Odor-Control Solution FOR BIO-SCRUBBERS® AND BIO-FILTERS
SPECIFICATIONS Bulk Density (Dry) 15.6 lb/ft 3 (249.9 kg/m 3 ) Bulk Density (Operating) 30.9 lb/ft 3 (495.0 kg/m 3 ) Typical EBRT Project specific Face Velocity 5 – 15 fpm (0.03 – 0.08 m/s) Water Holding Capacity 21.8 lb/ft 3 (349.2 kg/m 3 ) Particle Size (>90%) 0.5 to 1.5 in (12.7 to 38.1 mm) Surface Area 14,935,200 ft 2 /ft 3 (49,000,002 m 2 /m 3 ) Total Pore Volume 80 to 90% Total Pore Space 85 to 90% Fractional Open Pores 51.9% ( + ⁄ – 5%) Fractional Close Pores 48.1% ( + ⁄ – 5%) Crushing Load (>80% of Product Supplied) 1,340 lb/in 2 (9,239 kPa) Standard Packaging 50 ft 3 / 100 ft 3 (1.42 m 3 / 2.83 m 3 ) Super Sacks
GES Enhanced Cell-Max™ media is an engineered, inorganic substrate designed to maximize surface area and serve as part of the ecosystem for the growth of a diverse colony of microorganisms. A proprietary formula of nutrients, adsorbents, minerals, and food sources is applied to the media structure. The treated media establishes an ecosystem for a natural occurring selection of fungal and bacterial microorganisms for the capture and consumption of complex odors and VOCs. The GES Enhanced Cell-Max’s substrate is manufactured from post-consumer recycled glass, is rigid, lightweight, and will not degrade or decompose over time. KEY FEATURES Ecologically Friendly The media serves as part of an
Locally Produced All media and components are products of the USA. Full Service Media is installed on-site by the contractor. Acid Resistant The media is acid resistant and able to tolerate a low-pH (<1) environment over its entire lifespan. Warranty Enhanced Cell-Max™ media carries a 20-year pro-rated warranty.
ecosystem for the growth of a diverse colony of micro-organisms for the treatment of foul odors. Environmentally Sound The media contains no shale or mined products. Pre-formulated All media surfaces are pre-formulated with a blend of nutrients, adsorbents, minerals, and food sources. Stable The media will not compact, degrade, or decompose over its lifespan. 100% Recycled The media substrate is manufactured entirely from post-consumer recycled glass.
*Details at gesbiotek.com/terms
VIEW ONLINE
1540 Louis Bork Dr., Batavia, IL 60510 • (630) 473-3874 • sales@GESBiotek.com • GESBiotek.com
