Super-Pak Series 1 — 4 | SP-Pump
Unmatched Performance Clean Resources Super-Pak oil-water separator series sets the bar for condensate management on large, compressed air systems. Whether you’re running 200 HP or 2000 HP, there’s a Super-Pak configuration to match your system or compressor room. Using our proprietary alumina silicate substrate media, the Super-Pak oil-water separator beds adsorb ALL compressor-based lubricants, including silicone, polyalkylene glycol (PAGs), and food grade. No other oil-water separator company has the data to make this claim.
Standard features • All units are factory pre-plumbed, primed, and leak tested • Super-Pak 3 & 4’s are strapped to a 48” x 48” heavy-duty plastic pallet reinforced with three fiberglass rods and ¾” plywood decking • Custom decompression chamber/pump system • Inline Y-strainer captures large particle debris from the compressor before entering the unit, eliminating sludge build-up. • Six inlets for multiple compressors or other downstream components • 10 ppm or less carryover throughout the life of the unit (lowest in the industry) • Ships in a custom reinforced crate to prevent damage during transit. Maintenance-free—technician approved • No heavy, messy bag change-outs • No exposure to algae, black mold, bacteria or e-coli • Reduces or eliminates illness and allergic reactions Recycle program • Dispose of in accordance with state and local regulations or, • Ship registered unit to Clean Resources for free recycling
Have more than one compressor using different types of lubricants? No problem. All Clean Resources products can handle multiple systems connected simultaneously with just one unit. What Makes Clean Resources the Best OWS? How it works • Media utilizes molecular sieve technology and chemical bonding • Lubricant molecules attract to the proprietary substrate media bed like a magnet, permanently bonding and eliminating groundwater contamination
Environmental conditions • Works in all conditions—contact your distributor for extremely cold climates • Specific gravity, emulsification, relative humidity, and temperature do not affect performance
Guaranteed Compliance When properly sized, installed, and registered , our systems are guaranteed to reduce contaminants in your compressor condensate to 10 ppm or less* for the life of the unit. If your unit fails under these conditions, Clean Resources will replace the failed unit or provide a refund through your distributor.
* Methods tested: EPA1664b, EPA8270, EPA624 & EPA625 EPA8015c
SUPER-PAK | SERIES 1 – 4 | SP PUMP
Premium Features
1
1 Anti-Siphon Line
Any excess pressure in the system is returned to the pump
2
3
4
2 Outlet Hose
10ppm or less of filtered condensate exits to sanitary or floor drain
5
3 Cam Lock
Quick connect cam lock for easy and secure pump connection to the unit.
4 Flow Reducer
Regulates higher water flow from pump down to 10 GPM to restrict condensate intake
5 Y-Strainer
Inline filter for catching large particles from compressor or other downstream devices. The removable and reusable screen should be checked and rinsed every 1 – 3 months
6 Pump Line
Condensate exits the SP-Pump and enters the Super-Pak via the Y-Strainer
7 Decompression lines
Relieves any excess pressure build-up preventing air lock
7
8 Vent
6
Pressure is decompressed and vented before entering the OWS unit, preventing air locks
9
8
9 Condensate Inlet Hub
Replace red caps with supplied push to connect fittings and insert compressor lines
Sizes and Specifications
Maximum inlet pressure
Timer drain power requirement 120 Volt, 20 Amp
Decompression lines
Timer drain in/out poly tube
Drum-connecting hoses
Inlets
Anti-siphon line
Pump line
Discharge hose
Six 1/4”
175 psi
1/4”
1/4”
1/4”
3/4”
3/4”
3/4”
SUPER-PAK | SERIES 1 – 4 | SP PUMP
New Timer Drain All new Super Series Oil-Water Separators come equipped with
We’re Here to Help! Need a custom solution to fit your specific needs? No problem! Clean Resources works with distributors and end-users to engineer and test specific requirements on a client-by-client basis. One example, a client needed to monitor and test water samples regularly. On all of their Super-Pak 4 units, a designated test port was added between units 3 and 4 and another at the outlet hub. Have a special request? Give us a call! Product Installation and Recycling Most Clean Resources products are shipped with printed installation instructions attached to the unit or printed on the label. We know they get tossed out, “lost,” or sometimes you’d just rather not read the instructions. Not to worry. Each unit’s product label has a QR code that takes you to our installation series of videos. Here you can watch Jerry, our Clean Resources installation expert, talk you through installation and recycling, step-by-step. You will be up and running in no time, and EPA compliant.
a timer drain. This drain prevents the formation of a sludge mat that can occur in a small number of applications. Super-Paks arrive with the timer drain already installed. All you need to do is connect a clean shop air source and plug in the timer drain.
For full installation instructions, go to CleanResources.com/Super-series-video.html
Product Specifications
SUPER-PAK
HP ACFM
1
2
3
4
Works With ALL Compressor Lubricants
Unit Life in Hours* †
150 30,000 200 1,000 22,000 33,000 250 1,250 18,000 27,000 300 1,500 14,000 750
Diester-based PAO-based POE-based Glycol-based
Mineral-based
Quincy
Anderol
Atlas Copco
Ultra Chem
Sullivan-Palatek
21,000 35,000 18,000 29,000 15,000 25,000
350 1,750 12,000 400 2,000 10,000
Summit
Compair
Hydraulic
Gardner Denver
Ingersoll-Rand
450 2,250 500 2,500 600 3,000 800 4,000 1000 5,000 1200 6,000 1400 7,000 1600 8,000 1800 9,000 2000 10,000
9,000 9,000 7,000 6,000 4,000 4,000
14,000 24,000 33,000 13,000 22,000 31,000 11,000 18,000 26,000 8,000 14,000 19,000 7,000 11,000 16,000
Food grade
Kaeser
Sullair
Width (in)
Depth (in)
Height (in)
Weight (lbs)
Unit
6,000 5,000 4,000 4,000
9,000 13,000 8,000 11,000 7,000 10,000
Super-Pak 1 32 Super-Pak 2 40 Super-Pak 3 48 Super-Pak 4 48
52 48 48 48 15
45 45 45 45 31
750
6,000 6,000
9,000 8,000
1,500 2,250 3,000
* Unit life numbers in this chart assume rotary screw compressors with 2 ppm oil carryover running 8,000 hrs/yr. Unit life may vary due to differences in air compressor oil consumption rates, age, and maintenance of compressor. For use with reciprocating compressors, consult factory to calculate unit life.
SP-Pump*
15
21
CORRECTION FACTORS ROTARY SCREW COMPRESSORS (2 ppm carryover) Unit Life: [hours from above] x [CF from right] Example: Super-Pak 3 at 450 hp running 8,000 hrs/yr Unit Life: 24,000 x 1 = 24,000 hours †
* SP-Pump is enclosed in a 15-gallon container and requires 110 volts on a non-GFI outlet
Hrs/yr runtime Life Correction Factor (CF)
8,000 6,000 4,000 2,000
1 1.33 2
4
† To calculate unit life in months: [Unit Life] / 8,000 * 12
Clean Resources | 1540 Louis Bork Drive, Batavia, IL 60510 | 800-566-0402 | cleanresources.com
v14.1 2-18-2025
