Techtop Catalog

TEFC – ALUMINUM

Frame: 143T–286T 3Ф Volt: 230/460V

RPM: 3600/1800/1200 Encl: (TEFC) IP 55

HP: 1–30 Pole: 2/4/6

Multiplier Code: AG

RRESTOR RC *Shaft Grounding Installed

List Price Rigid Base C-Face

Sync Speed

HP

Model No.

3600

GX3-AL-TF-143T-2-B-D-1

$430

$483

STANDARD FEATURES • NEMA Premium Efficiency • Dual Voltage - Three Phase 230/460V • 3600/1800/1200 RPM - 2/4/6 Pole • Inverter Duty -15:1 Constant Torque (MG1 Part 31) • Totally Enclosed Fan Cooled IP 55 Protection • VPI Lap wound Stator with Anti-fungal Coating

1

1800

GX3-AL-TF-143T-4-B-D-1

$430

$483

1200

GX3-AL-TF-145T-6-B-D-1

$499 $453

$538 $506

3600 GX3-AL-TF-143T-2-B-D-1.5

1.5

1800 GX3-AL-TF-145T-4-B-D-1.5

$468

$521

1200 GX3-AL-TF-182T-6-B-D-1.5

$682

$762

3600

GX3-AL-TF-145T-2-B-D-2

$502

$555

2

1800

GX3-AL-TF-145T-4-B-D-2

$501

$554

1200

GX3-AL-TF-184T-6-B-D-2

$785

$850

3600

GX3-AL-TF-182T-2-B-D-3

$684

$770

• Double Lip Oil Seal on DE & ODE • Internal Shaft Grounding Brush

3

1800

GX3-AL-TF-182T-4-B-D-3

$671

$758

1200

GX3-AL-TF-213T-6-B-D-3

$991

$1,086

• 1.25 SF - 143T and Up • 50 Hz Capable at 1.0 SF • 40° C Ambient Temperature Rating • 1045 Carbon Steel Shaft • Multi-mount Frame with Removable Feet • Oversized Drive End Bearing • One-Way Brass Condensation Drains • Aluminum Conduit Box 90° Rotatable • Class F Insulation System with Class H Stator • F1, F2, F3 Box Position Convertible (Shipped F1) • Class 1, Division 2, Group C & D Compliant* • Installation up to 3300 ft Altitude • 36 Month Warranty from Purchase Date • Marine Duty Compliant * Requires removal of internal Grounding Brush. Note requirement on your order.

3600

GX3-AL-TF-184T-2-B-D-5

$750

$834

5

1800

GX3-AL-TF-184T-4-B-D-5

$757

$842

1200

GX3-AL-TF-215T-6-B-D-5

$1,293 $1,373

3600 GX3-AL-TF-213T-2-B-D-7.5 $1,023 $1,159 1800 GX3-AL-TF-213T-4-B-D-7.5 $1,068 $1,173 1200 GX3-AL-TF-254T-6-B-D-7.5 $1,536 $1,694

7.5

3600

GX3-AL-TF-215T-2-B-D-10

$1,173 $1,309

10

1800

GX3-AL-TF-215T-4-B-D-10

$1,221 $1,361

1200

GX3-AL-TF-256T-6-B-D-10

$1,995 $2,153

3600

GX3-AL-TF-215T-2-B-D-15

$1,791 $1,862

3600

GX3-AL-TF-254T-2-B-D-15

$1,763 $1,920

15

1800

GX3-AL-TF-254T-4-B-D-15

$1,766 $1,924

1200

GX3-AL-TF-284T-6-B-D-15

$2,495 $2,697

3600

GX3-AL-TF-256T-2-B-D-20

$2,049 $2,206

20

1800

GX3-AL-TF-256T-4-B-D-20

$2,069 $2,226

1200

GX3-AL-TF-286T-6-B-D-20

$2,852 $3,054

3600 GX3-AL-TF-284TS-2-B-D-25 $2,441 $2,644 1800 GX3-AL-TF-284T-4-B-D-25 $2,470 $2,672 3600 GX3-AL-TF-286TS-2-B-D-30 $2,919 $3,122 1800 GX3-AL-TF-286T-4-B-D-30

25

30

$2,911 $3,113 Continued on back

info@techtopind.com www.techtopind.com

2815 Colonnades Court Peachtree Corners, GA 30071

Tel: 1–855–TECHTOP Fax: 1–866–204–1498
