STEIGER ®

AFS CONNECT ™ STEIGER ® SERIES TRACTORS 7 Models | 425 – 715 | 467–778 Peak HP *

THE BEST JUST GETS BETTER Case IH Steiger series tractors are the go-to tractors for producers wanting a reliable, efficient, and powerful four-wheel drive tractor to meet their varied and demanding needs. And for the 2024 model year, the best just gets better. Our most powerful tractor is now even MORE powerful and MORE efficient.

“ I was very impressed with the 645 Wheeled Steiger tractor and how it handled. It had no problems pulling through the wet spots. In my opinion probably the best four-wheel drive wheeled tractor I’ve ever had the opportunity to run. ” Grant Roder, Producer in Osnabrock, ND

FACTORY WARRANTY 3 YEAR

2,000 HOUR

*See specs for details. **Warranty available for model year 2024 Steiger series tractors.

STEIGER SERIES TRACTOR

The Steiger Family�� 4 – 5 Get MORE with Steiger�� 6 – 7 Steiger Wheeled�� 8 – 11 Steiger Rowtrac�� 12 – 15 Steiger Quadtrac�� 16 – 19 Operator Environment�� 20 – 21 Operator Environment�� 22 – 23 AFS Technology�� 24 – 25 Specifications�� 26 – 31

CONFIGURED FOR ANY OPERATION

425 / 475 / 525 / 555 / 595 / 645 | 467 – 699 PEAK HP* WHEELED

TRANSMISSION:

• PowerDrive Transmission • CVXDrive Transmission: 425 / 475 / 525 / 555

CONFIGURATIONS:

• Row Crop Narrow-Frame, High-Horsepower or Heavy-Duty Wheeled Scraper

ROWTRAC

425 / 475 / 525 | 467 – 578 PEAK HP*

TRANSMISSION:

• PowerDrive Transmission or CVXDrive

CONFIGURATIONS:

• Ag Rowtrac

QUADTRAC

475 / 525 / 555 / 595 / 645 / 715 | 522 – 778 PEAK HP*

TRANSMISSION:

• PowerDrive Transmission • CVXDrive Transmission: 475 / 525 / 555

CONFIGURATIONS:

• Ag Quadtrac or Heavy-Duty Quadtrac Scraper

*See specs for details.

MORE STEIGER THAN MEETS THE EYE Match the horsepower you need with wheeled, Rowtrac or Quadtrac configurations, along with either a CVXDrive ™ continuously variable transmission or PowerDrive transmission. CVXDRIVE CONTINUOUSLY VARIABLE TRANSMISSION MODELS: 425 / 475 / 525 / 555 425 – 555 HP | 614 PEAK HP

POWERDRIVE POWERSHIFT TRANSMISSION MODELS: 425 / 475 / 525 / 555 / 595 / 645 / 715 425 – 715 HP | 778 PEAK HP The rugged and proven 16-speed PowerDrive powershift transmission delivers ultra-smooth shifting, reducing operator fatigue and provides optimal power transfer for maximum productivity.

CVXDrive transmission automatically selects the most efficient transmission range when the desired speed is set, eliminating the need for manual shifting and clutching and making it user-friendly for even inexperienced operators.

FIRST-CLASS POWER AND PERFORMANCE

All new for 2024, more environmentally sustainable Stage V emissions compliance yields 1% to 2% more fuel savings. Steiger tractors are powered by a proven Case IH FPT 13-liter engine with either a Tier 4 B/Final - Stage V SST electronic variable geometry turbocharger (models 425, 475, 525) or Tier 4 B/Final - Stage V TST two-stage turbo charger (models 555, 595, 645, 715). And now, the next generation Steiger model 715 comes with a 16-liter engine for even more Steiger power.

STRONG

SMART

• 13-liter engines with FPT technology provide leading fuel efficiency while maximizing power. • 16-liter Cursor two-stage turbo (TST) engine with 715 hp (527 kW) rated, 778 hp (572 kW) peak power. • Up to 10 percent power growth to maximize performance in the toughest conditions. • Steiger 555, 595, 645 and 715 models feature a two-stage turbocharger system with separate cooling system, delivering 40 percent more torque response under load.

• Service data can be wirelessly sent to your local Case IH dealer for remote diagnostics and quicker response time. • APM technology allows Steiger tractors to shift automatically to adjust to the load on the machine. • The engine-mounted fuel filter has been moved to a location near the air conditioning compressor for improved access. • Engine compression brake included on EVERY Steiger.

 16L engine

PROVEN

SIMPLE

• Designed and tested at the Case IH Fargo, North Dakota, facility and in the field and on the farm by our engineers, who are also customers. • Case IH Patented SCR Technology has continued to provide simplified compliance and longer oil change intervals for over 13 years. • Steiger has a track record of over 65 years providing the power, dependability, and flexibility that our customers demand.

• Patented Selective Catalytic Reduction (SCR) meets

Tier 4 B/Final - Stage V emission standards without compromising engine performance. • Does not require additional emission components such as Cooled Exhaust Gas Recirculation (CEGR) technology. • SCR technology provides simplified emission compliance.

 13L engine

WHEELED

425 / 475 / 525 / 555 / 595 / 645 | 467 – 699 PEAK HP*

Steiger chassis accommodates the industry’s largest tires, enhancing overall performance. Along with top-rated fuel efficiency, Steiger tractors ensure maximum productivity, dependable power, advanced hydraulics, and an unrivaled turning radius, to help conquer even the most demanding tasks effortlessly.

STANDARD FEATURES:

• PowerDrive Transmission • Category 4 Drawbar: 6,000 lb. • 4 Rear Remotes • Engine Brake Option

OPTIONAL FEATURES:

• CVXDrive Transmission: 425 / 475 / 525 / 555 • Category 4 Drawbar: 11,000 lb. (Option 1) or Category 5 Drawbar: 15,000 lb. (Option 2) • Up to 8 Rear Remotes • 3-Point Hitch • Second AFS Pro 1200 Display • Premium Sound Package

CONFIGURATIONS:

• Row Crop Narrow-Frame Models: 425 / 475 / 525 • High-Horsepower Wide-Frame Models: 555 / 595 / 645 • Heavy-Duty Wheeled Scraper Models: 555 / 595 / 645

*See specs for details.

STEIGER WHEELED Steiger 4WD wheeled tractors are ideal for pulling large planters and strip-till rigs to pushing silage and towing grain carts. Plus, get more traction and less compaction with a longer wheelbase and the tallest row crop tire option in the industry.

PATENTED SCR SYSTEM

Eliminates the need for engine regeneration and provides increased fuel efficiency.

NEW FRONT CAB ROOF MOUNTED LED LIGHTS

New customizable LED lights provide enhanced front and side visibility giving operators the freedom to program them to meet their operations’ specific needs.

POWERDRIVE POWERSHIFT TECHNOLOGY

The time-tested and fluid-efficient PowerDrive powershift does more than just shift gears. With the latest Steiger enhancements, it takes 20 percent less time to shift from first gear to 16th gear, saving you fuel, lowering operating costs and reducing fatigue. And during shuttle operation, a producer can change direction 38 percent faster than before.

PROVEN ENGINES

The Case IH FPT engine has passed every challenge and is built with efficiency in mind. Case IH FPT 13-L engines incorporate patented fluid-saving SCR-only technology for greater productivity that produce more power using less fuel. And, with 600 hour oil-change intervals, achieve greater fluid efficiency and lower operating costs.

STANDARD ADVANCED STEERING SYSTEM

Now standard on every Steiger tractor, the advanced steering system significantly reduces operator input, enhancing control both on the road and in the field. This innovation ensures smoother operation, increased predictability, and an impressive turning radius. It not only minimizes fatigue by demanding less input from producers but also acquires guidance lines 20 percent faster than the previous system, delivering a smoother steering experience – more like that of a car.

STRUCTURAL STEEL FUEL TANK

Every Steiger fuel tank is made of durable structural steel, unlike competitive offerings. This important design difference adds additional weight and strength to the Steiger chassis.

HEAVY-DUTY AXLES

Greater strength and durability are built into Case IH Steiger tractors. With 5.5-inch diameter axles and 18-bolt hubs, Steiger tractors feature unparalleled braking and hydraulic pressure for feel and modulation. Axles can carry up to 67,000 pounds of gross vehicle operating weight. These new heavier bar axles are standard on ag and scraper versions of the Steiger 595 and 645 tractor models.

MORE POWER TO THE GROUND

It’s one thing to produce a lot of horsepower. But, what really matters, and where the Steiger lineup excels, is moving this power efficiently throughout the tractor and, ultimately, to the ground and implement being pulled. Superior tractive capabilities using automatic differential locks reduce slippage in difficult field conditions .

ROWTRAC

425 / 475 / 525 | 467 – 578 PEAK HP*

When traction and agronomic advantage are essential to your operation, the Steiger Rowtrac tractor is the right choice. Rowtrac models provide 50/50 weight splits for low ground pressure to increase yields, plus can easily maneuver through fields for post emergence work.

STANDARD FEATURES:

• PowerDrive Transmission • Category 4 Drawbar: 6,000 lb. • 4 Rear Remotes • Engine Brake Option

OPTIONAL FEATURES:

• CVXDrive Transmission • Category 4 Drawbar: 11,000 lb. (Option 1) or Category 5 Drawbar: 15,000 lb. (Option 2) • Up to 8 Rear Remotes • 3-Point Hitch • Second AFS Pro 1200 Display • Premium Sound Package

CONFIGURATIONS:

• Ag Rowtrac

*See specs for details.

STEIGER ROWTRAC The Steiger Rowtrac is available in 425, 475 and 525 models and with either the PowerDrive or CVXDrive transmission options. Rowtrac models provide 50/50 weight splits for low ground pressure to increase yields, plus the added value of the ability to do post emergence work activities.

LARGER ENGINE AIR INTAKE

Improves engine efficiency and provides longer air filter life.

TRI-STRIPE DECAL

The tri-stripe design reminds us of three key points found in every Steiger: easy-to-use technology, ultimate comfort with ergonomic control and superior power to the ground .

LED GRILLE MOUNTED WORK LIGHTS

Operate whenever you need to with lights that provide superior visibility at night.

FRONT AND REAR CAMERAS

All Steiger tractors come camera ready with optional front and rear cameras . These cameras improve visibility with multiple feeds.

APM TRANSMISSION MODE

The Automatic Productivity Management (APM) system helps maintain speed by automatically upshifting and downshifting as the load changes.

Row Crop Spacing Rowtrac Operating Width Rowtrac Track Widths

20-inch rows

Standard 80 in.

18 in.

LED LIGHTS

22-inch rows

88 in.

18 in.

New customizable LED lights provide enhanced front and side visibility giving operators the freedom to program them to meet their operations’ specific needs.

30-inch rows

120 in.

18, 21, 24 in.

40-inch rows

Standard 80 in.

18, 21, 24, 30 in.

HEAVY DUTY THREE-POINT HITCH OPTION

Three-point hitch option can lift up to 21,902 lb.

SELF TENSIONING TRACK SYSTEM

The self tensioning track system is built into the suspension mounts on each undercarriage and provides longer track life

EXCLUSIVE 21-INCH TRACK OPTION

An EXCLUSIVE 21-inch track option for Rowtrac tractors, available factory fit from Case IH, provides a great post-emergence crop activity option.

FASTER ROAD SPEED

Improved track and roller wheel design enables road travel speeds up to 25 mph .

LARGER FUEL TANK

The Steiger Rowtrac tractor features a large 340 gallon fuel tank allowing producers to work longer days for increased productivity.

STEIGER 715 NEW STYLING

QUADTRAC

475 / 525 / 555 / 595 / 645 / 715 | 522 – 778 PEAK HP*

More than 25 years of industry-leading track technology featuring four positive-drive tracks with independently oscillating undercarriages. Designed to maintain constant contact with the ground for a smooth ride, superior flotation and optimal traction.

STANDARD FEATURES:

• PowerDrive Transmission • Category 4 Drawbar: 6,000 lb. • 4 Rear Remotes • Engine Brake Option • Self-Tensioning Track Design

OPTIONAL FEATURES:

• CVXDrive Transmission: 475 / 525 / 555 • Category 4 Drawbar: 11,000 lb. (Option 1) or Category 5 Drawbar: 15,000 lb. (Option 2) • Up to 8 Rear Remotes • 3-Point Hitch • Second AFS Pro 1200 Display • Premium Sound Package

CONFIGURATIONS:

• Ag Quadtrac • Heavy-Duty Quadtrac Scraper Models: 555 / 595

*See specs for details.

STEIGER QUADTRAC

AFS VECTOR PRO RECEIVER

Consolidated components improve guidance consistency and line acquisition .

Case IH Quadtrac technology features four individually driven, positive drive, oscillating tracks. Each track maintains constant contact with the ground for a smooth ride, optimal ground pressure, superior flotation and better traction.

INTUITIVE CVXDRIVE CONTROLS

EXCLUSIVE split throttle design for CVXDrive models is simple and easy to use. Set your engine RPM and the CVXDrive transmission allows the engine to work throughout the entire range to achieve the perfect balance of power and efficiency.

TRI-STRIPE DECAL

Updated styling reflects the latest design seen only on new Case IH tractors and reminds us of three key points found in every Steiger: easy-to-use technology, ultimate comfort with ergonomic control and superior power to the ground .

CVXDRIVE TRANSMISSION

Steiger was the first and is still the only articulated high-horsepower four wheel drive tractor with a continuously variable transmission . Available in 17 configurations with up to 614 peak horsepower.

LED GRILLE MOUNTED WORK LIGHTS

Operate whenever you need to with lights that provide superior visibility at night.

DUAL TURBOCHARGERS WITH DEDICATED CHARGE AIR COOLERS

Steiger 555, 595, and 645 13L engines feature dual turbochargers with a dedicated air cooler after each turbo. This industry exclusive air to water intake air cooling design increases cooling efficiency providing a shorter path for engine intake air, which results in a faster response under load. The two-stage turbocharger system provides high boost in all operating conditions.

LED LIGHTS

New customizable LED lights provide enhanced front and side visibility , allowing the operator the freedom to customize which lights should be on or off as needed for their operation.

POWER ADJUSTABLE MIRRORS

Electronic telescoping mirrors are controlled from the tractor cab for effortless adjustments.

360-DEGREE EGRESS LIGHTING

Located at every angle around the tractor to give you better visibility upon exiting the cab in low light situations.

TRI-POINT OSCILLATION

Unlike the competition’s gudgeon bearing system, the heavy-duty Tri-point oscillation on the Steiger series tractor provides the perfect mix of strength and balance when transferring power to the ground and maintaining ground contact with reduced slip. This consistent ground contact makes Steiger ideal for various tasks like tillage, planting, nutrient placement and land leveling.

CAST UNDERCARRIAGE SYSTEM

Heavy-duty cast undercarriage designed by Case IH engineers for the rugged frame of Steiger tractors for enhanced durability and reliability.

EXCLUSIVE TRACK TECHNOLOGY

STANDARD 4-POINT CAB SUSPENSION

Self-adjusting tracks eliminates the need for tools and keeps you up and running.

Stabilizes font-to-back, side-to-side and up-and-down motions creating a smooth ride regardless of terrain.

AN OPERATOR ENVIRONMENT ABOVE THE REST

Case IH engineers used years of research and input from our most qualified experts — you. The result is an interior that blends simplicity, control and luxury like you’ve never experienced in a tractor cab before.

Pre-programmed hot keys EXCLUSIVE front and rear independent, automatic differential locks Nine programmable hot key button provides more shortcut options Configurable hot keys 1–4 Configurable hot keys 5–8 Configurable, color-coded electro-hydraulic remote (EHR) levers 12-in. AFS Pro 1200 display with touch screen and Bluetooth ® capabilities — powered by the new AFS Vision Pro operating system that is just like using a smartphone or tablet

MULTIFUNCTION HANDLE

Puts 95% of the commonly used controls at your fingertips.

EXCLUSIVE SPLIT THROTTLE

Available with CVXDrive transmission and allows the operator to set upper and lower engine RPMs to keep you in total control.

MULTICONTROL ARMREST

Proven design now features an encoder for total control at your fingertips.

AFS Pro 1200 Display Redesigned MultiFunction Handle Color-Coded, Configurable, Electro-Hydraulic Remotes (EHR)

Luxury Leather, Heated/Ventilated Seat with 40-Degree Swivel Molded Floor Mat New Wider, Larger Windshield Wipers

Not Shown: RAM ® Device Mounts USB, 3 Pin, System Data, and Power Ports

Luxury Leather Instructor Seat Storage/Cup Holder

Screen Control Encoder Knob Leather MultiControl Armrest

Telescoping Steering Wheel with Memory Lock Instrument Cluster with Key Machine Information

A CAB BUILT FOR YOU

Engineers have focused on where you spend your time to create an environment designed for you. The new cab roof styling gives the new Steiger tractors a refined look, with enhanced lighting for overall improved visibility.

– Integrated overhead grab rails on all four sides of cab – Overhead right-hand console from the widely-popular Magnum ™ tractor

– Integrated RAM Mount rails in the headliner and right front cab post contribute to easier mounting of displays and accessories – New left hand entry door handle offers less resistance when opening the door – A new premium sound option that includes an amplifier, integrated tweeters and a 6.5-inch subwoofer with ported box

– Exposed speaker grills increase sound quality – Clear site lines and new lighting options with higher output and a 360-degree lighting package

– All cab and exterior lights are LED – New updated cab headliner improves the look and quality of cab interior

THE AFS CONNECT APP

View and monitor your equipment and field information in one place, all on your mobile device or tablet.

PRODUCTIVITY, CONNECTIVITY AND PROFITABILITY Understanding every aspect of your operation is the key to improving your bottom line. With AFS Connect, view your equipment data and agronomic layers in one place to help you make informed decisions — both in the planning stages for the year and those critical in-season pivots. Plus, with the AFS Connect app, you can successfully manage your operation anytime, anywhere.

KEEP MOVING IN SEASON

PLAN YOUR SEASON

WORK SMARTER BY TRACKING EQUIPMENT

Using all the tools available to you keeps your operation running at top speed. • Review planting and as-applied data through the AFS Connect mobile app to keep an eye on certain areas all season long. • Add AFS AccuSync ™ to share coverage maps and guidance lines between multiple machines working in the same field, to reduce skips and overlaps for added efficiency. • View and share reports and other relevant information with your trusted advisor or Case IH dealership.

Having every pass planned before the year starts can help when it’s time to get to the field to begin the work.

Knowing the status of all your equipment helps you cover more acres in a day. • Track equipment location with minute-by-minute updates to plan your next move. • Receive push notifications when a tractor enters or exits a set geofence for up-to-date status on job completion. • View and compare machine information, such as operating speed and fuel usage, to learn how machines are being used in the field. • Access the AFS Pro 1200 display remotely with Remote Display Viewing to coach operators through setup and operation.

• Review previous years’ data to develop your approach for a new season.

• Develop tillage prescriptions for AFS Soil Command ™ equipped tools to work every acre exactly how you want. • Send set up data, guidance lines and prescriptions to connected equipment.

• AFS Connect gives the user the ability to make informed management decisions through data visualization. • Add a second AFS Pro 1200 customizable display to view equipment and implement functions with ease. • AFS AccuSync allows you to easily share real-time data between multiple pieces of equipment in the same field for a fully connected operation and increased productivity. • AFS Vector Pro receiver delivers robust positioning options, from sub-inch to <40 inches accuracy, to meet guidance needs. • New modem lending to greater connectivity options. • ISOBUS Class 3 technology allows for compatible tractor and implement control through AFS Pro 1200 display. • Receive machine software updates automatically. • AFS AccuGuide ™ increases productivity by managing passes across the field and headland turns. A TECHNOLOGY BEAST STEIGER

• AFS AccuTurn ™ Pro incorporates Headland Management Control II to make seamless one button press end of row turns for more repeatable operation.

425 WHEELED NARROW

475 WHEELED NARROW

525 WHEELED NARROW

MODEL

POWER

Tier 4 B/Final - Stage V with SST electronic variable turbo charger

Engine Type

Engine HP1

425

475

525

Maximum Engine HP 2

467

522

578

PTO HP 3

409

462

516

Cylinders / Valves / Displacement

6 cyl./24/13L (787 cu. in.)

ELECTRICAL

Alternator / Battery / Battery Isolator

12V 240 amp standard (12V 330 amp optional)/three 950 cranking amps/Yes

TRANSMISSION / PTO

Standard

PowerDrive full-powershift 16F / 2R with 16 Hi (25 mph / 40 kph)

Optional

CVXDrive CVT (25 mph / 40 kph)

PTO Speed

1,000

AXLES

Axle Diameter

5.0 in. (127 mm) bar with 4 gear planetary

Axle Width

120 in. (3 048 mm)

148 in. (3 759 mm)

Wheelbase

HYDRAULICS / HITCH

Rear Remotes (Standard / Optional)

4/upto8

Hydraulic Pump PowerDrive (Standard / Optional)

42 gpm (159 L/min.)/57 gpm (216 L/min.)

Hydraulic Pump CVXDrive

57 gpm (216 L/min.)

Total Tractor Hydraulic Flow with Parallel/Twin Flow Pumps

113 gpm (428 L/min.)

Available Flow at Single Remote Valve

35 gpm (132 L/min.)

3-Point Hitch Category

Cat. 4N

21,903 lb. (97.4 kN)

Hitch Lift Capacity

CAPACITIES

Fuel Tank

310 gal. (1 170 L)

Diesel Exhaust Fluid Tank

42 gal. (159 L)

DIMENSIONS & WEIGHTS

Drawbar (Standard / Option 1 / Option 2)

Cat. 4: 6,000 lb. (2 722 kg)/Cat. 4: 11,000 lb. (4 990 kg)/Cat. 5: 15,000 lb. (6 804 kg)

Base / Max. Gross

40,800 lb. (18 507 kg) / 56,000 lb. (25 401 kg)

1Rated 2,100 engine rpm ISO per ECE R120 (CV) 21,900 engine rpm ISO per ECE R120 (CV) 31,000 PTO rpm ISO per ECE R120 (CV)–Power boost available during mobile PTO/hydraulics/transport operation * convertible to Cat. 3 26

555 WHEELED HIGH-HORSEPOWER WIDE FRAME

595 WHEELED HIGH-HORSEPOWER WIDE FRAME

645 WHEELED HIGH-HORSEPOWER WIDE FRAME

MODEL

POWER

Tier 4 B/Final - Stage V with TST two-stage turbo charger

Engine Type

Engine HP1

555

595

645

Maximum Engine HP 2

614

656

699

PTO HP 3

537

Cylinders / Valves / Displacement

6 cyl./24/13L (787 cu. in.)

ELECTRICAL

Alternator / Battery / Battery Isolator

12V 240 amp standard (12V 330 amp optional)/three 950 cranking amps/Yes

TRANSMISSION / PTO

Standard

PowerDrive full-powershift 16F / 2R with 16 Hi (25 mph / 40 kph)

Optional

CVXDrive CVT (25 mph / 40 kph)

N/A

PTO Speed

1,000

AXLES

Axle Diameter

5.0 in. (127 mm) bar

5.5 in. (140 mm) axle bar with 3 gear compound planetary

Axle Width

120 in. (3 048 mm)

154 in. (3 912 mm)

Wheelbase

HYDRAULICS / HITCH

Rear Remotes (Standard / Optional)

4/upto8

Hydraulic Pump PowerDrive (Standard / Optional)

42 gpm (159 L/min.)/57 gpm (216 L/min.)

Hydraulic Pump CVXDrive

57 gpm (216 L/min.)

N/A

Total Tractor Hydraulic Flow with Parallel/Twin Flow Pumps

113 gpm (428 L/min.)

Available Flow at Single Remote Valve

35 gpm (132 L/min.)

3-Point Hitch Category

Cat. 4N*

22,750 lb. (101.20 kN)

Hitch Lift Capacity

CAPACITIES

Fuel Tank

455 gal. (1 722 L)

Diesel Exhaust Fluid Tank

66 gal. (250 L)

DIMENSIONS & WEIGHTS

Drawbar (Standard / Option 1 / Option 2)

Cat. 4: 6,000 lb. (2 722 kg) / Cat. 4: 11,000 lb. (4 990 kg) / Cat. 5: 15,000 lb. (6 804 kg)

Base / Max. Gross

46,340 lb. (21 012 kg)/60,000 lb. (27 215 kg)

50,328 lb. (22 828 kg)/67,000 lb. (30 390 kg)

MODEL

425 ROWTRAC

475 ROWTRAC

525 ROWTRAC

POWER

Tier 4 B/Final - Stage V with SST electronic variable turbo charger

Engine Type

Engine HP1

425

475

525

Maximum Engine HP 2

467

522

578

PTO HP 3

409

462

516

Cylinders / Valves / Displacement

6 cyl./24/13L (787 cu. in.)

ELECTRICAL

Alternator / Battery / Battery Isolator

12V 240 amp standard (12V 330 amp optional)/three 950 cranking amps/Yes

TRANSMISSION / PTO

Standard

PowerDrive full-powershift 16F / 2R with 16 Hi (25 mph / 40 kph)

Optional

CVXDrive CVT (25 mph / 40 kph)

PTO Speed

1,000

AXLES

Axle Diameter

flanged

Axle Width (Standard/Optional)

80 in. (2 032 mm), 88 in. (2 235 mm) or 120 in. (3 048 mm)

160 in. (4 064 mm)

Wheelbase

HYDRAULICS / HITCH

Rear Remotes (Standard / Optional)

4/upto8

Hydraulic Pump PowerDrive (Standard / Optional)

42 gpm (159 L/min.)/57 gpm (216 L/min.)

Hydraulic Pump CVXDrive

57 gpm (216 L/min.)

Total Tractor Hydraulic Flow with Parallel/Twin Flow Pumps

113 gpm (428 L/min.)

Available Flow at Single Remote Valve

35 gpm (132 L/min.)

3-Point Hitch Category

Cat. 4N

21,903 lb. (9 934 kg)

Hitch Lift Capacity

CAPACITIES

Fuel Tank

340 gal. (1 287 L)

Diesel Exhaust Fluid Tank

42 gal. (159 L)

DIMENSIONS & WEIGHTS

Drawbar (Standard / Option 1 / Option 2)

Cat. 4: 6,000 lb. (2 722 kg)/Cat. 4: 11,000 lb. (4 990 kg)/Cat. 5: 15,000 lb. (6 804 kg)

Base/Max. Gross (Rowtrac)

52,200 lb. (23 678 kg)/60,000 lb. (27 215 kg)

MODEL

475 QUADTRAC

525 QUADTRAC

555 QUADTRAC

POWER

Tier 4 B/Final - Stage V with SST electronic variable turbo charger

Tier 4 B/Final - Stage V with TST two-stage turbo charger

Engine Type

Engine HP1

475

525

555

Maximum Engine HP 2

522

578

614

PTO HP 3

462

516

537

Cylinders / Valves / Displacement

6 cyl./24/13L (787 cu. in.)

ELECTRICAL

Alternator / Battery / Battery Isolator

12V 240 amp standard (12V 330 amp optional)/three 950 cranking amps/Yes

TRANSMISSION / PTO

Standard

PowerDrive full-powershift 16F / 2R with 16 Hi (25 mph / 40 kph)

Optional

CVXDrive CVT (25 mph / 40 kph)

PTO Speed

1,000

AXLES

Axle Diameter

flanged

Axle Width

88 in. (2 235 mm)

154 in. (3 912 mm)

Wheelbase

HYDRAULICS / HITCH

Rear Remotes (Standard / Optional)

4/upto8

Hydraulic Pump PowerDrive (Standard / Optional)

42 gpm (159 L/min.)/57 gpm (216 L/min.)

Hydraulic Pump CVXDrive

57 gpm (216 L/min.)

Total Tractor Hydraulic Flow with Parallel/Twin Flow Pumps

113 gpm (428 L/min.)

Available Flow at Single Remote Valve

35 gpm (132 L/min.)

3-Point Hitch Category

Cat. 4N*

22,250 lb. (10 092 kg)

Hitch Lift Capacity

CAPACITIES

Fuel Tank

470 gal. (1 779 L)

Diesel Exhaust Fluid Tank

85 gal. (322 L)

DIMENSIONS & WEIGHTS

Drawbar (Standard / Option 1 / Option 2)

Cat. 4: 6,000 lb. (2 722 kg)/Cat. 4: 11,000 lb. (4 990 kg)/Cat. 5: 15,000 lb. (6 804 kg)

Base / Max. Gross

53,700 lb. (23 358 kg)/67,000 lb. (30 390 kg)

55,200 lb. (25 038 kg) / 67,000 lb. (30 390 kg)

MODEL

595 QUADTRAC

645 QUADTRAC

715 QUADTRAC

POWER

Tier 4 B/Final - Stage V with TST two-stage turbo charger

Engine Type

Engine HP1

645

715

595

699

778

Maximum Engine HP 2

656

PTO HP 3

537

Cylinders / Valves / Displacement

6 cyl./24/13L (787 cu. in.)

6-cyl. / 24 / 16L (970 cu. in.)

ELECTRICAL

Alternator / Battery / Battery Isolator

12V 240 amp standard (12V 330 amp optional)/three 950 cranking amps/Yes

TRANSMISSION / PTO

Standard

PowerDrive full-powershift 16F / 2R with 16 Hi (26.5 mph / 42.6 kph)

Optional

N/A

PTO Speed

1,000

AXLES

Axle Diameter

flanged

Axle Width

88 in. (2 235 mm)

154 in. (3 912 mm)

Wheelbase

HYDRAULICS / HITCH

Rear Remotes (Standard / Optional)

4/upto8

Hydraulic Pump PowerDrive (Standard / Optional)

42 gpm (159 L/min.)/57 gpm (216 L/min.)

57 gpm (216 L/min.)

Hydraulic Pump CVXDrive

57 gpm (216 L/min.)

Total Tractor Hydraulic Flow with Parallel/Twin Flow Pumps

113 gpm (428 L/min.)

Available Flow at Single Remote Valve

35 gpm (132 L/min.)

3-Point Hitch Category

Cat. 4N

22,250 lb. (99 kN)

Hitch Lift Capacity

CAPACITIES

Fuel Tank

470 gal. (1 779 L)

520 gal. (1 968 L)

Diesel Exhaust Fluid Tank

85 gal. (322 L)

DIMENSIONS & WEIGHTS

Drawbar (Standard / Option 1 / Option 2)

Cat. 4: 6,000 lb. (2 722 kg)/Cat. 4: 11,000 lb. (4 990 kg)/Cat. 5: 15,000 lb. (6 804 kg)

Cat. 5: 15,000 lb. (6 804 kg)

Base / Max. Gross

56,800 lb. (25 764 kg) / 67,000 lb. (30 390 kg)

61,200 lb. (27 760 kg) / 72,000 lb. (32 659 kg)

THE NEXT GENERATION OF STEIGER IS HERE

SAFETY NEVER HURTS!™ Always read the Operators Manual before operating any equipment. Inspect equipment before using it, and be sure it is operating properly. Follow the product safety signs, and use any safety features provided. CNH Industrial America LLC reserves the right to make improvements in design and changes in specifications at any time without notice and without incurring any obligation to install them on units previously sold. Specifications, descriptions and illustrative material herein are as accurate as known at time of publication, but are subject to change without notice. Availability of some models and equipment builds varies according to the country in which the equipment is used.

©2024 CNH Industrial America LLC. All rights reserved. Case IH is a trademark registered in the United States and many other countries, owned by or licensed to CNH Industrial N.V., its subsidiaries or affiliates. Any trademarks referred to herein, in association with goods and/or services of companies other than CNH Industrial America LLC, are the property of those respective companies. Printed in U.S.A. www.caseih.com CIH24010401

Page 1 Page 2 Page 3 Page 4 Page 5 Page 6 Page 7 Page 8 Page 9 Page 10 Page 11 Page 12 Page 13 Page 14 Page 15 Page 16 Page 17 Page 18 Page 19 Page 20 Page 21 Page 22 Page 23 Page 24 Page 25 Page 26 Page 27 Page 28 Page 29 Page 30 Page 31 Page 32

www.redlineequipment.com

Made with FlippingBook - professional solution for displaying marketing and sales documents online
