HIGH-PERFORMANCE OIL-WATER SEPARATORS FOR AIR COMPRESSORS
CRP SERIES
SMART-PAK SERIES
THE NEXT GENERATION MOLECULAR FILTRATION SYSTEM • Compression-fit manifold for precise filtration control • Timer drain for improved flow of condensate through the media bed • Antimicrobial sanitation of discharge hose to prevent algae growth • Twelve available inlets (increased from six) • Efficiently & effectively removes all oils, including glycol-based lubricants • No maintenance or messy bag change-outs • Cradle-to-grave warranty • No exposure to mold, bacteria or e-coli
Life Span* (Months /Hours † )
Unit
IDC 350 CRP 500 CRP 750 CRP 1000 CRP 1500 CRP 2000
12/8,000 12/8,000 12/8,000 12/8,000 12/8,000
12/8,000 *Months or Hours whichever occurs first † See complete lifespan chart on page 2.
The Super-Pak by Clean Resources offers large compressed air systems a strong, reliable oil-water separator. Standard systems are designed for 4,000 – 10,000 CFM applications. SUPER-PAK SERIES
SUPER (CFM)
Life Span (Hours † )
4,000 5,000 6,000 7,000 8,000 9,000
19,000 16,000 13,000 11,000 10,000
FOR LARGE COMPRESSED AIR SYSTEMS Small footprint for large HP systems shipping on a super duty 48” x 48” pallet • Ships from the factory pre-plumbed, primed, and leak tested • Three layers of redundancy • System capacity functions on all compressor lubricants, including glycol lubricants • Custom decompression chamber/pump system • No messy bag change-outs • No exposure to mold, bacteria or e-coli • System monitoring for timely change-out • 110v Power required
9,000
10,000 8,000 † Numbers above are for the SUPER-PAK 4. See complete lifespan chart on page 2.
MICRO SERIES
DESIGNED FOR SMALLER COMPRESSED AIR SYSTEMS This system is designed as an economical solution for small compressed air systems up to 125 psi (up to 175 psi with inline regulator installed). The MICRO line also includes a factory-installed and plumbed wall bracket, reducing installation time. Replacement cartridges provide straightforward, no mess maintenance and offer the lowest life cycle cost in the industry.
MICRO (CFM)
Life Span* (Months /Hours † )
50
12/2,000
100 8/2,000 *Months or Hours whichever occurs first † See complete lifespan chart on page 2.
PRODUCT DIMENSIONS AND LIFESPANS
GUARANTEED PERFORMANCE Clean Resources guarantees properly sized and installed products will reduce the contaminants in your compressor condensate to 10 ppm or less for the life of the unit. If your unit fails while operating in approved conditions and has been properly sized and installed, we will replace the failed unit on a pro-rated schedule.
Width (in)
Depth (in)
Height (in)
Weight (lbs)
Width (in)
Depth (in)
Height (in)
Weight (lbs)
Unit
Unit
IDC 350 CRP 500 CRP 750
12 14.5
23 48 48 48 57 57
50
SUPER-PAK 1 32 SUPER-PAK 2 40 SUPER-PAK 3 48 SUPER-PAK 4 48 MICRO 50 12 MICRO 100 17
52 48 48 48
45
750
16 16
15 15 15 20 20
110 125 150 310 370
45 1,500 45 2,250 45 3,000
CRP 1000 16 CRP 1500 22 CRP 2000 22
5 5
19 19
3 6
MICRO Series
CRP Series
SUPER Series
50
100 IDC 350 500
750
1000 1500 2000
1
2
3
4
Capacity
1 pt/min
1 qt/min
1 GPM
2 GPM
3 GPM
5 GPM
HP ACFM
Unit Life in Hours*
5
20 30 40 75
5,000 10,000
7.5
3,000 3,000 1,000
7,000 5,000
10 15 20 25 30 40 50 60 75
3,000 32,000 2,000 24,000 2,000 19,000
100 125 150 200 250 300 375 500 600 750
16,000 32,000
13,000 24,000 32,000
10,000 19,000 25,000 32,000 9,000 16,000 21,000 26,000 7,000 13,000 17,000 21,000 5,000 10,000 13,000 16,000
100 125 150
4,000
8,000 11,000 13,000 30,000
6,000 5,000 4,000
8,000 11,000 24,000 30,000 30,000
200 1000 250 1250 300 1600 350 1900 400 2200 450 2350 500 2500 600 3000 800 4000 1000 5000 1200 6000 1400 7000 1600 8000 1800 9000 2000 10000
6,000 5,000 4,000
8,000 18,000 22,000 22,000 33,000 6,000 15,000 18,000 18,000 27,000
5,000 11,000 14,000 14,000 21,000 35,000 4,000 10,000 12,000 12,000 18,000 29,000
4,000
8,000 10,000 10,000 15,000 25,000
8,000 7,000 6,000 5,000 4,000 3,000 3,000 2,000 2,000 2,000
9,000 9,000 7,000 6,000 4,000 4,000 3,000 3,000 2,000 2,000
9,000 14,000 24,000 33,000 9,000 13,000 22,000 31,000 7,000 11,000 18,000 26,000
6,000 4,000 4,000
8,000 14,000 19,000 7,000 11,000 16,000
6,000 5,000 4,000 4,000
9,000 13,000 8,000 11,000 7,000 10,000 6,000 9,000 6,000 8,000
CORRECTION FACTORS ROTARY SCREW COMPRESSORS (2 ppm carryover) Unit Life: [hours from above] x [CF from below] Example: IDC 350 at 40 hp running 6,000 hrs/yr Unit Life: 13,000 x 1.33 = 17,290 hours †
* Unit life numbers in this chart assume rotary screw compressors with 2 ppm oil carryover running 8,000 hrs/ yr. Unit life may vary due to differences in air compressor oil consumption rates, age, and maintenance of compressor. For use with reciprocating compressors, consult factory to calculate unit life.
RECIPROCATING COMPRESSORS (8 ppm carryover) Unit Life: [hours from above] x 0.25 x [CF from below] Example: IDC 350 at 20 hp running 4,000 hrs/yr Unit Life: 24,000 x 0.25 x 2 = 12,000 hours †
Hrs/yr runtime
8,000 6,000 4,000 2,000
SMART GREEN — End-of-Life Solutions
Life Correction Factor (CF)
1 1.33 2
4
† To calculate unit life in months: [Unit Life] / 8,000 * 12
We’re committed to reducing our carbon footprint and want to make it easy for you to do the same. Our Smart Green recycling program offers free end-of-life recycling for registered units, in hopes to prevent them from ending up in landfills like many competitive oil-water separators. Clean Resources will even cover the cost of the recycle processing fees for end users that use our Green End-of-Life Solution. You can learn more at recycleoilsep.com.
Clean Resources | 1540 Louis Bork Drive, Batavia, IL 60510 | 800-566-0402 | cleanresources.com | sales@cleanresources.com
v3.0 9-25-2024
