EN50155 Railway/Ethernet Switches & Extenders
802.3at PoE+
L2+ Ring
Model
IGS-5227-4MP2MT IGS-604HPT-M12 IGS-604HPT-RJ IGS-5226-4P2T IGS-5227-6MT-X IGS-5227-6MT IGS-5227-6T
Product Image
6 x M12, 8-pin A-coded connector
6 x M12, 8-pin X-coded connector
6 x M12, 8-pin A-coded connector 6 x Waterproof RJ45
10/100/ 1000BASE-T
6 x Waterproof RJ45
1000 mini-GBIC
-
-
-
-
-
-
-
Hardware
100BASE-FX
-
-
-
-
-
-
-
Switch Fabric
12Gbps
12Gbps
12Gbps
12Gbps
12Gbps
12Gbps
12Gbps
DI & DO
-
-
-
-
-
-
-
Inputs
Dual 24~48V DC Dual 48~56V DC Dual 48~56V DC Dual 48~56V DC Dual 9~48V DC Dual 9~48V DC Dual 9~48V DC
5-pin M23 male connector
Power
Connector
5-pin A-Coded M12 male connector
5-pin A-Coded M12 male connector
Consumption
160 watts
160 watts
160 watts
160 watts
10 watts
10 watts
10 watts
Dimensions (W x D x H)
163 x 103 x 53 mm 163 x 103 x 53 mm 163 x 103 x 53 mm 163 x 103 x 53 mm 163 x 103 x 53 mm 163 x 103 x 53 mm 163 x 103 x 53 mm
Mechanical
Enclosure
IP67 aluminum IP67 aluminum IP67 aluminum IP50 metal
IP67 aluminum IP67 aluminum IP67 aluminum
Mounting
DIN-rail, wall-mountable
DIN-rail, wall-mountable
Operating Temperature
-40~75 degrees C -40~75 degrees C -40~75 degrees C -40~75 degrees C -40~75 degrees C -40~75 degrees C -40~75 degrees C
Environment
Operating Humidity
5% to 95%RH (non-condensing)
5% to 95%RH (non-condensing)
Emissions
FCC Class A, CE Class A
FCC Class A, CE Class A
Regulatory
IEC60068-2-32 (Free Fall), IEC60068-2-27 (Shock), EC60068-2-6 (Vibration)
Stability
IEC60068-2-32 (Free Fall), IEC60068-2-27 (Shock), EC60068-2-6 (Vibration)
PoE Standard
802.3af/802.3at
802.3af/802.3at
802.3af/802.3at
802.3af/802.3at
-
-
-
PoE Port
4
4
4
4
-
-
-
PoE Budget
144 watts
144 watts
144 watts
144 watts
-
-
-
PoE
PSE Type
End-span
End-span
End-span
End-span
-
-
-
Power Pin Assignment
1/2(+), 3/6(-)
1/2(+), 3/6(-)
1/2(+), 3/6(-)
1/2(+), 3/6(-)
-
-
-
IP Interfaces
8 VLAN
8 VLAN
8 VLAN
8 VLAN
8 VLAN
8 VLAN
8 VLAN
Routing Tables
32
32
32
32
32
32
32
Layer 3 Features
Routing Protocols
IPv6/IPv4 Static Routing
IPv6/IPv4 Static Routing
Accelerated Hardware
-
-
-
-
-
-
-
Port-based VLAN/IEEE 802.1Q VLAN/Q-in-Q/ Private VLAN/MAC-based VLAN/Protocol-based VLAN/Voice VLAN/MVR
802.1Q VLAN/Q-in-Q/Private VLAN/MAC-based VLAN, Protocol-based VLAN/Voice VLAN/MVR
VLAN
IGMP Snooping
v1/v2/v3/query
v1/v2/v3/query
v1/v2/v3/query
v1/v2/v3/query
v1/v2/v3/query
v1/v2/v3/query
v1/v2/v3/query
Spanning Tree 802.1w/802.1s Data Redundancy ERPS Ring < 20ms ERPS Ring < 20ms ERPS Ring < 20ms ERPS Ring < 20ms ERPS Ring < 20ms ERPS Ring < 20ms ERPS Ring < 20ms QoS Port-based/802.1P/IP DSCP Policy-based/Voice VLAN Security 802.1x, Static MAC, MAC filter, Port Security and IP Security Traffic Control In/out rate limit, storm control 802.1w/802.1s 802.1w/802.1s 802.1w/802.1s 802.1w/802.1s 802.1w/802.1s 802.1w/802.1s
Protocol
Interface
Web, telnet, SSH and SSL
Web, telnet, SSH and SSL
SNMP
v1, v2c, v3 and trap
v1, v2c, v3 and trap
Management
Alarm
Power and port alarm
Power alarm
Power and port alarm
System Log
System Log and remote Syslog
System Log and remote Syslog
