Adande Product Guide Brochure

Product Guide

CONTENTS

Brand Information��3

What makes Adande Different? Traditional Vs Adande Technology��4

Unrivaled Temperature Stability ��6

Fundamentals�� 7

Adande Units Side Engine Unit (VCS) ��9 Slimline Side Engine Unit (VLS)��10 Rear Engine Unit (VCR)��11 Compact Unit (VCC)��12 Matchbox System Unit (VCM)��12 Accessories�� 13

Technical Data��14

Stoddart's Brand Range��15

ADANDE

REFRIGERATED DRAWERS

Adande’s patented refrigerated drawers are unique to the marketplace, making sure the cold air is retained when you open a drawer, allowing your food to stay fresher for longer.

15°C (for serving)

12°C

4°C

2°C

-1°C

-15°C

ADANDE DIFFERENT? WHAT MAKES

It’s an Adande ® ; it works like no other fridge or freezer!

When Adande developed their patented ‘hold the cold’ technology, it was the first significant innovation in refrigeration for over 70 years. Adande are not the same as other drawer units; they’re not the same as door operated ones either.

You can’t compare a Combi with a Standard Oven, neither can you compare an Adande ® with any traditionally made unit, and here’s why….

Adande ® Technology

Traditional Design

Adande® Drawer Seal

Traditional Drawer Seal

Expensive to maintain due to the high cost of having to replace them often

Adande magnetic heated seals are hidden and out of harm’s way, reducing wear and tear and protecting them from accidental damage

Even with doors or drawers shut, any small cuts, tears, or food deposits on the seals can cause bacterial infiltration and continuous loss of cold air Danger of cross contamination from fingers & food debris - Seals have the highest bacterial count in a kitchen environment!

Easy to clean

Guaranteed for 2 years

Traditional Condensers

Adande® Condensers

View from inside cabinet

Condensers are typically located at a low level and exposed, which is a prime area for dirt & grime - blocking condensers, disrupting airflow & using more energy! Unless brush cleaned often, airborne contaminants, such as fat & flour, clog up the condenser, burning out fan motors and even compressors

Housed internally affording protection

Cleaning is less frequent and much easier because fats and cooking oils present in kitchens do not reach the condenser

Low chance of condenser blocking reduces incidence of compressor failure

Partially blocked condensers make the compressor work harder, resulting in higher power consumption

ADANDE DIFFERENT? WHAT MAKES

Traditional Drawer

Adande® Insulated Container

ONLY the rigid insulated container is cooled with- in the cabinet & when the drawer is opened it ‘holds the cold’ within; saving significant energy when com- pared to traditional refrigeration drawers

As the whole internal cabinet is cooled, when the drawer is opened the cold air ‘drops out’

Thin, brittle uninsulated plastic containers, metal containers or drawers just do not ‘hold the cold’

Large storage capacity with food accessible in full plan view when open

Stable temperatures are critical to prolonging the shelf life of food, how-ever, the design of traditional cabinets does not allow stable temperatures

Grooves help cold air circulation - no need to leave air gaps between items of food

Easy to lift out for deep cleaning, or to wipe clean while remaining in situ

No need to tilt - easy to lift out and back in

Adande® Drawer Runner

Traditional Runner

Hygienic because food cannot come into contact with the runners as these are external to the insulated container

Drawer runners must be fixed into the insulated cabinet wall, making them inherently weak, and in need of frequent replacement

Do not ice up allowing flexible operation as BOTH fridge & freezer

Exposed to freezing temperatures, they accumulate ice, seize up & performance is hindered

Runners are incredibly strong and robust, having been tested to 200,000 openings

Runners inside the insulated cabinet with the food is unhygienic

Back of Traditional Drawer Unit

Adande® Back of Unit

Smooth and flush - No tangling of wires

Key components vulnerable to damage

No unnecessary obstructions

Not easily situated into most kitchen environments

No dirt traps, easier cleaning, less snags

Fully modular - drawer units can be removed or added

UNRIVALLED TEMPERATURE STABILITY ADANDE Results from respected test facilities show that Adande has clear performance advantages over tradi- tional refrigeration drawers Fresh food storage temperature • Starting set point temperature in both appliances: 5˚C • Under-counter fridge air temperature above 8˚C for more than 4 hours on three occasions - outside Food Safety regulation • Adande drawer temperature very stable

Air Temperature stability

Peaks show typical drawer/door opening

Automatic defrosts

Adande ® Vs. Under-counter chiller

Optimum holding temperature range

-0

-1

5 Hour Sample

-2

0.0 0.5 1.0 1.5 2.0 2.5 3.0 3.5 4.0 4.5

Time (h)

Under-counter Fridge (°C)

Adande (°C)

What this means for food held in a restaurant fridge Trials simulating restaurant conditions were done to compare Adande with traditional units; the results were dramatic!

Adande ®

Traditional

Visibly Shrunk & Mouldy

Fresh

Frozen food quality is also preserved better in freezer mode

FUNDAMENTALS REFRIGERATED DRAWER SYSTEMS

Adande is an award winning and innovative refrigerated drawer system which overcomes many of the short-comings of traditional refrigerated drawer designs. The system is modular and extremely flexible, allowing you to bring refrigeration to the point of use, for example as a chef base, a preparation station, or as bulk storage.

The Adande system can be configured to suit any application:

• Each drawer is capable of being individually set as a fridge OR freezer at temperatures between +15°C to -22°C • The system offers dramatic improvements in energy efficiency and food holding quality due to its unique design, which holds the cold air in when the drawer is opened • Drawer modules are available in 4 footprints (side, rear engines, compact or matchbox), and can be configured 1-2 drawers high (excluding compact) • Side engine drawer modules are now available in two heights allowing a wider range of overall finished heights. These are the standard VCS height and the new slimline VLS heights • Drawer modules can be finished with a variety of top and base options to suit your application • Heat shield top can with stand temperature upto 200°C

FOOTPRINT - SELECT FOR YOUR APPLICATION Side Engine VCS/VLS 1100W x 700D Rear Engine VCR 878W x 885D Compact VCC 450W x 800D

Matchbox Side Engine VCM 1100W x 700D

Code Explanation

Footprint

Quantity

Base Configuration

Top Configuration

VCS (Side Engine)

Roller (R)

Cover Top (T)

VLS (Slimline Side Engine)

Standard Castors (C)

Solid Work Top (W)

VCR (Rear Engine)

High Castors (HC)

Heatshield Top (HS)

VCC (Compact)

Adjustable Legs (L)

VCM (Matchbox)

Plinth Slides (P)

Eg.

VCS 2 C W

FUNDAMENTALS REFRIGERATED DRAWER SYSTEMS

CUSTOMISING YOUR KITCHEN

The Adande Drawer system provides Chefs with an incredible amount of flexibility. Part of this flexibility comes from being able to customise your unit with different base and top options to create different working heights, weight loadings, and manoeuvrability.

• Different base and top configurations will create different finished working heights and will create different maximum weight loadings to the top surface • Kitchen aisle space should allow for drawer units to be rolled out for cleaning and maintenance (up to 900mm for rear engine units). Units must be installed so they are removable and should not be built in. • Kitchen aisle space should allow for drawers to be opened fully and worked around. Drawers extend out 725mm in the fully open position. • Hard-wired, gas and plumbed equipment cannot be directly installed onto the Adande unit. This equipment must be installed above the Adande unit using an independent equipment stand We know how temperature affects your food. With Adande, you're in control

1 Available in 4 different configurations: HS Heat Shield Top W Work Top T Cover Top

Available in configurations from single drawer units up to double drawer units all with independently controlled temperatures from freezer to fridge. Utilise one as a chiller, and the other as a freezer.

Available in 4 different configurations:

Standard Castor - best for free standing double drawer units.

High Castor - best for single drawer units.

Roller - best for under counter units

Plinth - Slides; best for plinth mount 2 drawer setups

Legs - Adjustable; best for slimline single drawer units

Drawer setups will suit any given application with a range of accessories available.

VCS2.CW model shown

ADANDE

SIDE ENGINE UNIT (VCS)

Model

Base Configuration Top Configuration Surface Height

Max Weight Loading

Standard Height (VCS) Single Drawer Side Engine Units

VCS1.RW

Roller

Solid Work Top

458mm

300kg

VCS1.RHS

Roller

Heatshield Top

500mm

285kg

VCS1.CW

Standard Castor

Solid Work Top

502mm

300kg

VCS1.CHS

Standard Castor

Heatshield Top

545mm

300kg

VCS1.HCHS

High Castor

Heatshield Top

624mm

235kg

723mm drawer opening

700mm deep

1100mm wide

Storage Capacity Per Unit 4 x 100mm deep 6 x 65mm deep 1/1 GN Pans

Double Drawer Units - Side Engine

VCS2.PT

Plinth Slides

Cover Top

816mm

0kg

VCS2.RT

Roller

Cover Top

846mm

0kg

VCS2.RW

Roller

Solid Work Top

854mm

230kg

VCS2.CT

Standard Castor

Cover Top

890mm

0kg

VCS2.RHS

Roller

Heatshield Top

895mm

230kg

VCS2.CW

Standard Castor

Solid Work Top

900mm

230kg

700mm deep

1100mm wide

Storage Capacity Per Unit 8 x 100mm deep 12 x 65mm deep 1/1 GN Pans

723mm drawer opening

SLIMLINE SIDE ENGINE UNIT (VLS) ADANDE

Max Weight Loading

Model

Base Configuration Top Configuration Surface Height

Slimline Height (VLS) Single Drawer Side Engine Units

VLS1.CHS

Standard Castor

Heatshield Top

487mm

300kg

VLS1.HCHS

High Castor

Heatshield Top

567mm

235kg

VLS1.LHS

Adjustable Leg

Heatshield Top

540mm

300kg

700mm deep

1100mm wide

723mm drawer opening

Storage Capacity Per Unit (VLS1) 2 x 100mm deep 4 x 65mm deep 1/1 GN Pans

Double Drawer Units - Side Engine

Available in 3 different configurations, Adande double drawer units can utilise either 2 slimline drawers (VLS), 2 x Standard height drawers (VCS) or a combination of 1 of each drawer (VNS), providing a wider variety of finished heights

VLS2.PT

Plinth slides

Cover Top

699mm

0kg

VLS2.CT

Standard Castor

Cover Top

772mm

0kg

VLS2.CW

Standard Castor

Solid Work Top

784mm

230kg

VNS2.PT

Plinth Slides

Cover Top

757mm

0kg

VNS2.CT

Standard Castor

Cover Top

833mm

0kg

700mm deep

1100mm wide

Storage Capacity Per Unit (VLS2) 4 x 100mm deep 8 x 65mm deep 1/1 GN Pans Storage Capacity Per Unit (VNS2) Slimline: 2 x 100mm deep 4 x 65mm deep 1/1 GN Pans Standard: 4 x 100mm deep 6 x 65mm deep 1/1GN Pans

723mm drawer opening

ADANDE

REAR ENGINE UNIT (VCR)

Base Configuration

Max Weight Loading

Model

Top Configuration Surface Height

Single Drawer Units - Rear Engine

VCR1.RW

Roller

Solid Work Top

458mm

285kg

VCR1.RHS

Roller

Heatshield Top

500mm

285kg

VCR1.CW

Standard Castor

Solid Work Top

502mm

300kg

VCR1.CHS

Standard Castor

Heatshield Top

545mm

300kg

VCR1.HCHS

High Castor

Heatshield Top

624mm

235kg

885mm deep

723mm drawer opening

Storage Capacity Per Unit 4 x 100mm deep 6 x 65mm deep 1/1 GN Pans

878mm wide

Double Drawer Units - Rear Engine

VCR2.PT

Plinth Slides

Cover Top

815mm

0kg

VCR2.RT

Roller

Cover Top

846mm

0kg

VCR2.CW

Standard Castor

Solid Work Top

900mm

230kg

878mm wide

885mm deep

Storage Capacity Per Unit 8 x 100mm deep 12 x 65mm deep 1/1 GN Pans

723mm drawer opening

COMPACT UNIT (VCC) ADANDE MATCHBOX SYSTEM UNIT (VCM)

Base Configuration

Max Weight Loading

Model

Top Configuration Surface Height

Compact Single Drawer Unit

VCC1.SCW

Small Castor

Solid Work Top

845mm

200kg

VCC1.GCW

Standard Castor

Solid Work Top

900mm

200kg

NOTE: Not suitable for Plinth Mounting

800mm deep

728mm drawer opening

450mm wide

Storage Capacity Per Unit 60 Litres

Not GN Compatible

Matchbox System - Double Drawer Unit

Storage Capacity - 8 x 1/1 GN (100mm deep) or 12 x 1/1 GN (65mm deep)

VCM2.RT

Roller

Cover Top

846mm

0kg

VCM2.CW

Standard Castor

Solid Work Top

900mm

200kg

700mm deep

1100mm wide

20mm wide

732mm drawer opening

Storage Capacity Per Unit 8 x 100mm deep 12 x 65mm deep 1/1 GN Pans

732mm drawer opening

ACCESSORIES ADANDE

• Simply slot into the insulated bin grooves • Ideal for separating loose product Drawer Dividers Model

Dimensions W x D x H (mm)

Details

SPAE.103437

To suit VCS / VCR / VCM drawers only

SPAE.106122

To suit VLS Slimline drawers only

SPAE.104043

To suit VCC drawers only

GN Pan Racks

• Helps chefs organise, stack and store GN ingredient pans to suit their menu and operational requirements • 1 x GN pan rack fills half a drawer

SPAE.RG

To suit VCS / VCR / VCM drawers only

Equipment Stands • Stand to suit modular equipment installed above an Adande refrigerated drawer, ensuring the drawer can be moved inependently of the equipment above for servicing and running of services • Stand incorporates insulation to protect Adande below • Designed to suit a variety of modular equipment - installed on legs • NOTE: Stoddart does not recommend installing modular equipment directly on top of an Adande drawer

SPAE.ST.1200.850.600 Multi-purpose Equipment Stand To suit VCS1.RT (450mm) / VCS1.CT (494mm)

1200 x 850 x 600 (height +/- 15mm)

Suits most 900mm deep European modular equipment, including Giorik

SPAE.ST.1200.750.600 Multi-purpose Equipment Stand To suit VCS1.RT (450mm) / VCS1.CT (494mm)

1200 x 750 x 600 (height +/- 15mm)

Suits most 700mm deep European modular equipment, including Giorik, American Range, Truheat & B&S

SPAE.ST.1200.750.505 Multi-purpose Equipment Stand To suit VCS1.RT (450mm)

1200 x 750 x 505 (height +/- 15mm)

Suits Waldorf, Blueseal, Garland, Cobra, Goldstein & Luus equipment

SPAE.ST.1305SG

Synergy Equipment Stand To suit VCS1.RT (450mm) / VCS1.CT (494mm) Suits Synergy Grill

1305 x 742 x 570 (height +/- 15mm)

Levelling Wedges

SPAE.HAW

Pack of 4 wedges for levelling of unit

95 x 50 x 3

TECHNICAL DATA REFRIGERATED DRAWER SYSTEMS

Technical Data

+15°C to - 22°C set point by user. Each drawer independently controlled

Temperature Flexibility

Operating Temperature

Tested to Climate Standard #5

Defrost

Automatic Electric (No drainage required)

Mains

230V AC 50 Hz

Supply Cord

1 x 10 Amp power supply for 1, 2 and 3 drawers

Casing Material

Food service grade stainless steel

Drawer Material

ABS plastic, zero ODP PU foam

113kg Compact drawer 115kg Single drawer 175kg Two drawer

Average Unit Weights

WARRANTY 2

Years All Parts & Labour incl. Seals

Years Extended * Parts Only

Register your Adande within 90 days of Purchase to extend your standard 2 year warranty to 5 years*, free of charge. *Terms & Conditions Apply Adande Refrigerated Drawers come with a 2 year manufacturer’s Parts and Labour warranty from the date of purchase. You simply need to register within 90 days of purchase and Stoddart will extend the manufacturer’s warranty to 5 years on all parts except Seals, Displays and Container, free of charge. For all purchases after 1 October 2018.

If you do not register, your manufacturer’s warranty will be 2 years Parts and Labour from the date of purchase.

To register go to, http://www.stoddart.com.au/warranty-registration/Adande
